Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, Ca 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
SSR20C120CT Series
20 A / 1200 V
Schottky Silicon Carbide
Centertap Rectifier
FEATURES:
1200 Volt Silicon Carbide Schottky Rectifier
Average Output Current: 20 Amps
No Reverse Recovery
No Forward Recovery
No Switching Time Change Over Temperature
Small Package Size
Cerpack: 1.1 gr (typ); TO-257: 3.2 gr (typ);
TO-254: 6.3 gr (typ)
TX, TXV, and Space Level Screening Available.
Consult Factory
Designer’s Data Sheet
Part Number / Ordering Information
1/
SSR20C __ __ __ __ __
│ │ │ │ └
Screening
2/
│ │ │ │
__
= Not Screened
TX = TX Level
│ │ │ │
TXV = TXV Level
│ │ │ │
S = S Level
│ │ │ │
│ │ │ └
Lead Bend Options
│ │ │
__
= Straight Leads
DB = Down Bend
│ │ │
UB = Up Bend
│ │ │
│ │ └
Package
G = Cerpack
│ │
M = TO-254
│ │
J = TO-257
│ └
Configuration
CT = Centertap
└
Voltage
080 = 800 V
100 = 1000 V
120 = 1200 V
MAXIMUM RATINGS
3/
Peak Repetitive and Peak Reverse Voltage
Average Rectified Forward Current
(Resistive Load, 60 Hz, Sine Wave)
Peak Surge Current
(8.3 ms Pulse, Half Sine Wave, T
A
= 25
o
C)
Operating & Storage Temperature
Junction Temperature
Maximum Thermal Resistance
(Junction to Case)
CERPACK (G)
TO-254 (M)
SSR20C080CT
SSR20C100CT
SSR20C120CT
Per Leg
Total
Symbol
V
RRM
V
R
I
O
I
FSM
T
OP
& T
stg
T
J
R
JC
Value
800
1000
1200
10
20
60
-55 to +250
-55 to +250
1.5
TO-257 (J)
Units
Volts
Amps
Amps
o
o
o
C
C
C/W
Notes:
1/ For ordering information, price, and availability, contact factory.
2/ Screening based on MIL-PRF-19500. Screening flows available on request.
3/ Per leg. Unless otherwise specified, all electrical characteristics @25ºC.
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: SH0029D
DOC
Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, Ca 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
ssdi@ssdi-power.com *
www.ssdi-power.com
SSR20C120CT Series
Symbol
I
F
= 2.0 A
I
F
= 5.0 A
I
F
= 10 A
T
A
= -55ºC, I
F
= 5 A
T
A
= 150 ºC, I
F
= 5 A
ELECTRICAL CHARACTERISTICS
3/
Instantaneous Forward Voltage Drop
(T
A
=25ºC, 300 - 500
sec
pulse)
Instantaneous Forward Voltage Drop
(300 - 500
sec
pulse)
Reverse Leakage Current
(Rated V
R
, T
A
= 25ºC, 300
sec
pulse minimum)
Reverse Leakage Current
(Rated V
R
, T
A
= 150ºC, 300
sec
pulse minimum)
Junction Capacitance
(V
R
= 10V, f = 1MHz, T
A
= 25
o
C)
CASE OUTLINE: Cerpack (G)
Min
––
––
––
––
––
––
––
––
Typ
1.06
1.25
1.53
1.25
1.45
10
15
375
Max
1.20
1.50
1.80
1.60
1.80
50
250
450
Units
V
DC
V
DC
A
A
pF
V
F1
V
F2
V
F3
V
F4
V
F5
I
R1
I
R2
C
J
PIN ASSIGNMENT
Package
Cerpack (G)
TO-254 (M)
TO-257 (J)
Pin 1
Anode
Anode
Anode
Pin 2
Anode
Cathode
Cathode
Pin 3 (Tab)
Cathode
Anode
Anode
Available Part Numbers:
SSR20C080CTG,SSR20C100CTG, SSR20C120CTG
SSR20C080CTM, SSR20C080CTMDB, SSR20C080CTMUB
SSR20C100CTM, SSR20C100CTMDB, SSR20C100CTMUB
SSR20C120CTM, SSR20C120CTMDB, SSR20C120CTMUB
SSR20C080CTJ, SSR20C080CTJDB, SSR20C080CTJUB
SSR20C100CTJ, SSR20C100CTJDB, SSR20C100CTJUB
SSR20C120CTJ, SSR20C120CTJDB, SSR20C120CTJUB
Notes:
*Pulse Test: Pulse Width = 300
sec,
Duty Cycle = 2%
1/ For ordering information, price, and availability, contact factory.
Bottom View
2/ Screening based on MIL-PRF-19500. Screening flows available on request.
3/ Per leg. Unless otherwise specified, all electrical characteristics @25ºC.
CASE OUTLINE: TO-254 (M)
CASE OUTLINE: TO-257 (J)
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: SH0029D
DOC
