DC COMPONENTS CO., LTD.
R
RC201
THRU
RC207
RECTIFIER SPECIALISTS
TECHNICAL SPECIFICATIONS OF
SINGLE-PHASE SILICON BRIDGE RECTIFIER
VOLTAGE RANGE - 50 to 1000 Volts
CURRENT - 2.0 Amperes
FEATURES
* Surge overload ratings to 50 Amperes peak
* Ideal for printed circuit board assembly
RC-2
MECHANICAL DATA
*
*
*
*
*
*
Case: Molded plastic
Epoxy: UL 94V-0 rate flame retardant
Lead: MIL-STD-202E, Method 208 guaranteed
Polarity: As marked
Mounting position: Any
Weight: 1.88 grams
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25 C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
SPACING
Dimensions in inches and (millimeters)
o
SYMBOL
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Bridge Input Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Output Current at T
A
= 25 C
Peak Forward Surge Current 8.3 ms single half sine-wave
superimposed on rated load (JEDEC Method)
Maximum Forward Voltage Drop per element at 1.0A DC
Maximum DC Reverse Current at Rated
DC Blocking Voltage per element
I
2
t Rating for Fusing (t<8.3ms)
Typical Junction Capacitance ( Note1)
Typical Thermal Resistance (Note 2)
Operating Temperature Range
Storage Temperature Range
NOTES : 1.Measured at 1 MH
Z
and applied reverse voltage of 4.0 volts
@T
A
= 25
o
C
@T
A
= 100 C
o
o
RC201
50
35
50
RC202
100
70
100
RC203
200
140
200
RC204
400
280
400
2.0
50
1.1
10
RC205
600
420
600
RC206
800
560
800
RC207
1000
700
1000
UNITS
Volts
Volts
Volts
Amps
Amps
Volts
uAmps
A
2
Sec
pF
0
V
RRM
V
RMS
V
DC
I
O
I
FSM
V
F
I
R
500
I
2
t
C
J
RθJ A
T
J
T
STG
10
25
40
-55 to + 125
-55 to + 150
C/W
0
0
C
C
2. Thermal Resistance from Junction to Ambient and from junction to lead mounted on P.C.B. with 0.47 x 0.47" (12x12mm) copper pads.
