ZML-132-04-GD datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> ZML-132-04-GD

ZML-132-04-GD: Description64 CONTACT(S), MALE, STRAIGHT BOARD STACKING CONNECTOR, SOLDER, ROHS COMPLIANT; CategoryThe connector The connector; File Size781KB，1 Pages; ManufacturerSAMTEC; Websitehttp://www.samtec.com/; Environmental Compliance

Download Datasheet Parametric View All

ZML-132-04-GD Overview

64 CONTACT(S), MALE, STRAIGHT BOARD STACKING CONNECTOR, SOLDER, ROHS COMPLIANT

ZML-132-04-GD Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Objectid	1616013796
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
Connector type	BOARD STACKING CONNECTOR
Contact to complete cooperation	GOLD (10) OVER NICKEL (50)
Contact completed and terminated	GOLD FLASH OVER NICKEL (50)
Contact point gender	MALE
Contact material	NOT SPECIFIED
DIN compliance	NO
Filter function	NO
IEC compliance	NO
JESD-609 code	e4
MIL compliance	NO
Manufacturer's serial number	ZML
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation method	STRAIGHT
Installation type	BOARD
Number of rows loaded	2
Options	GENERAL PURPOSE
Terminal pitch	1.27 mm
Termination type	SOLDER
Total number of contacts	64

Preview

Download Datasheet

View All

F-213-1

ZML–132–54–L–D–650–SM

ZML–105–03–G–D

(1,27 mm) .050"

ZML–120–04–G–D

ZML SERIES

SHROUDED ELEVATED STACKER

SPECIFICATIONS

For complete speciﬁcations and

recommended PCB layouts

see www.samtec.com?ZML

Insulator Material:

Black LCP

Terminal Material:

Phosphor Bronze

Plating:

Au or Sn over

50µ" (1,27 µm) Ni

Current Rating:

1A per contact

Operating Temp Range:

-55°C to +105°C with Tin;

-55°C to +125°C with Gold

RoHS Compliant:

Yes

Mates with:

SMS, RSM

APPLICATIONS

SMS

(2,54 mm)

.100"

BOARD

SPACE

ZML

APPLICATIONS

ZML Style -01

mated with SMS

ZML Style -02

mated with SMS

ZML Style -03

mated with SMS

ZML Style -04

mated with SMS

BOARD

SPACE

(13,72)

.540

(15,11)

.595

(17,53)

.690

(20,57)

.810

Processing:

Lead-Free Solderable:

Yes

SMT Lead Coplanarity:

(0,10 mm) .004" max (05-20)

(0,15 mm) .006" max (32)

Surface

Mount or

Through-hole

(1,27 mm)

.050"

(7,62 mm)

.300"

ZML

NO. PINS

PER ROW

LEAD

STYLE

Specify

LEAD

STYLE

from

chart

PLATING

OPTION

BODY

HEIGHT

TAIL

STYLE

–L

= 10µ"

(0,25 µm)

Gold on post,

Matte Tin

on tail

05, 08,

10, 20, 32

(Call Samtec for other sizes)

(Leave blank for

Through-hole)

(Leave

blank for

Through-

hole)

–“XXX”

= –SM Body Height

(Specify board space “B”

in inches from lead

style charts.)

THROUGH-HOLE

–SM

= Surface

Mount

No. of Positions x (1,27) .050 + (3,18) .125

No. of Positions x (1,27) .050 + (0,64) .025

(1,27) .050

–G

= 10µ"

(0,25 µm)

Gold on post,

Gold ﬂash

on tail

SURFACE MOUNT

LEAD POST

STYLE HEIGHT

(A)

–53

–54

(3,05)

.120

(5,84)

.230

(2,54)

.100

(6,60) (9,40)

.260 .370

(3,56) .140

(0,46) .018 SQ TYP

(2,54)

.100

BODY

LEAD

HEIGHT

STYLE

(C)

Note:

Other

Gold plating

(12,83) .505

–01

options available.

(14,22) .560

–02

Contact Samtec.

(16,64) .655

–03

(19,69) .775

–04

BODY

HEIGHT

(B)

(13,46) (20,19)

.530 to .795

(13,46) (17,40)

.530 to .685

(9,65)

.380

(5,84)

.230

Note:

For added mechanical

stability, Samtec recommends

mechanical board spacers be

used in applications with gold or

selective gold plated connectors.

Contact ipg@samtec.com for

more information.

Note:

This Series is

non-standard, non-returnable.

(2,54)

.100

(2,54)

.100

(0,38)

.015

(3,05)

.120

(3,81)

.150

(7,62) .300

(0,51) .020

DIA TYP

(1,25)

.050

TYP

THROUGH-

HOLE

SURFACE MOUNT

WWW.SAMTEC.COM
