CXOQ/CXOQHG OSCILLATOR
400 kHz to 100 MHz
One of the World’s Smallest and Highest Precision
Crystal Oscillators
DESCRIPTION
Technological advancements permit 2.5 mm x 2.0 mm
CXOQ quartz oscillator to have design-in capabilities of
withstanding high shock applications. Additionally, the ultra-
miniature CXOQ takes advantage of Statek’s well known
reliability and impeccable quality.
FEATURES
DIMENSIONS
High shock survival
High frequency stability
Low acceleration sensitivity (HG version)
CMOS and TTL compatible
Low power consumption
Full military testing per MIL PRF 55310 available
Optional output enable/disable with Tri-State
Low EMI emission
Hermetically sealed ceramic package
Designed, manufactured and tested in the USA
APPLICATIONS
4
TOP
A
3
C
B
3
BOTTOM
D
4
E
1
2
2
1
TYPICAL
DIM
A
B
inches
0.098
0.079
mm
2.50
2.00
0.89
1.02
0.67
0.57
MAXIMUM
inches
0.102
0.083
0.039
0.048
0.027
0.023
mm
2.60
2.10
1.00
1.22
0.69
0.59
Military
Medical
Industrial
0.035
C
(SM1)
C
(SM3/SM5)
0.040
D
E
0.026
0.022
SUGGESTED LAND PATTERN
0.114 (2.9)
PIN CONNECTIONS
1. Output Enable/Disable (E) or no connection (N)
2. Ground (Connected to Lid)
3. Output
4. V
DD
0.094 (2.4)
0.025 (0.64)
0.038
(0.975)
inches (mm)
0.037
(0.95)
10190 Rev A1
S
YS
TEM
C
ERT
I
F
I
C
AT
N
IO
STATEK CORPORATION 512 N. MAIN ST., ORANGE, CA 92868 714-639-7810 FAX: 714-997-1256
www.statek.com
IS
O
01
90
SPECIFICATIONS
ABSOLUTE MAXIMUM RATINGS
Specifications are typical at 25
O
C unless otherwise noted.
Specifications are subject to change without notice. Tighter
specifications are available. Please contact factory.
Frequency
Supply Voltage
1
Calibration Tolerance
2
Frequency Stability
Over Temperature
3
Supply Current (Typical)
400 kHz to 100 MHz
1.8V to 5.0 V ± 10%
± 100 ppm to ± 30 ppm
± 50 ppm for Commercial
± 100 ppm for Industrial
± 100 ppm for Military
1.8 V
24 MHz
1.5 mA
32 MHz
2.0 mA
50 MHz
3.0 mA
15 pF
5 ms MAX
10 ns MAX
45% MIN/55% MAX
5 ppm
5,000 g, 0.3 ms,
1
/
2
sine
HG: 20,000 g
20 g, 10-2,000 Hz swept sine
-10
O
C to 70
O
C
-40
O
C to 85
O
C
-55
O
C to 125
O
C
(Commerical)
(Industrial)
(Military)
Supply Voltage V
DD
-0.5 V to 5.0 V
Storage Temperature
-55
O
C to 125
O
C
Maximum Process Temperature 260
O
C for 20 seconds
ENABLE/DISABLE OPTIONS (E/N)
3.3 V
3.0 mA
5.0 mA
6.0 mA
Statek offers two enable/disable options: E and N. The
E-version has a Tri-State output and stops oscillating
internally when the output is put into the high Z state.
The N-version does not have PIN 1 connected internally
and so has no enable/disable capability. The following
table describes the Enable/Disable option E.
ENABLE/DISABLE OPTION E
FUNCTION TABLE
Output Load (CMOS)
Start-up Time
Rise/Fall Time
Duty Cycle
4
Aging, first year
Shock, survival
5
Vibration, survival
6
Operating Temp. Ranges
Enable (Pin 1 High*) Disable (Pin 1 Low)
Output
Oscillator
Current
Frequency Output
Oscillates
Normal
High Z State
Stops
Very Low
*
When PIN 1 is allowed to float, it is held high by an internal pull-up resistor.
PACKAGING OPTIONS
CXOQ
- Tray Pack
- 12 mm tape, 7” or 13” reels
Per EIA 481 (see Tape and Reel data sheet
#10109)
1. Contact factory for available other voltages.
2. Tighter tolerances available.
3. Does not include calibration tolerances. Tighter tolerances available
4. Tighter duty cycles are available.
5. Higher shock available, contact factory for requirements above 20,000 g.
6. Per MIL-STD-202G, Method 204D, Condition D. Random vibration testing also
available.
Note: All parameters are measured at ambient temperature with a 10 M , 15 pF load.
HOW TO ORDER CXOQ/CXOQHG SURFACE MOUNT CRYSTAL OSCILLATORS
CXOQ
HG
HG = High
Shock
otherwise
leave blank
4
Supply Voltage
1 = 1.8 V
2 = 2.5 V
3 = 3.0 V
4 = 3.3 V
5 = 5.0 V*
S
“S” if Special or
custom design;
otherwise blank
N
Enable/Disable
Option
E or N
SM3
Terminations
Blank = SM1
= Gold Plated
(Lead Free)
SM3 = Solder Dipped
SM5 = Solder Dipped
(Lead Free)
32.0M
Frequency
K = kHz
M = MHz
,
100
Calibration
Tolerance
@ 25
0
C
(in ppm)
/
100
Frequency
Stability over
Temp. Range
(in ppm)
/
/
Temp. Range:
C = -10
O
C to +70
O
C
I
= -40
O
C to +85
O
C
I
M = -55
O
C to +125
O
C
S = Customer Specified
OR
/
/
200
Total
Frequency
Tolerance
(in ppm)
*5.0 V offered in Disable (N) option only.
/
I
Temp. Range:
C = -10
O
C to +70
O
C
I
= -40
O
C to +85
O
C
M = -55
O
C to +125
O
C
S = Customer Specified
10190 Rev A1
S
YS
C
ERT
I
F
I
C
TEM
AT
N
IO
STATEK CORPORATION 512 N. MAIN ST., ORANGE, CA 92868 714-639-7810 FAX: 714-997-1256
www.statek.com
IS
O
01
90
