High Performance Sensorless Motion Control IC

IRMCK203 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Parts packaging code	QFP
package instruction	TFQFP, TQFP80,.55SQ
Contacts	80
Reach Compliance Code	compli
ECCN code	EAR99
Analog Integrated Circuits - Other Types	AC MOTOR CONTROLLER
JESD-30 code	S-PQFP-G80
JESD-609 code	e0
length	12 mm
Number of functions	1
Number of terminals	80
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Maximum output current	0.03 A
Package body material	PLASTIC/EPOXY
encapsulated code	TFQFP
Encapsulate equivalent code	TQFP80,.55SQ
Package shape	SQUARE
Package form	FLATPACK, THIN PROFILE, FINE PITCH
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	3.3 V
Certification status	Not Qualified
Maximum seat height	1.2 mm
Maximum supply voltage (Vsup)	3.6 V
Minimum supply voltage (Vsup)	3 V
Nominal supply voltage (Vsup)	3.3 V
surface mount	YES
Temperature level	INDUSTRIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	GULL WING
Terminal pitch	0.5 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	NOT SPECIFIED
width	12 mm
Base Number Matches	1

Preview

Download Datasheet

View All

Data Sheet No. PD60225

revA

IRMCK203

High Performance Sensorless Motion Control IC

Features

Complete Sensorless control IC for Permanent

Magnet AC motors

No phase voltage feedback sensing required

Sinusoidal current waveform with Synchronously

Rotating Frame closed loop current control

High starting torque and smooth speed ramping

Direct interface to IR2175 current sensing high

voltage IC

Auto Retry at startup with configurable starting

torque

Versatile loss minimization Space Vector PWM

Serial communication interface (RS232C, RS422,

SPI)

I C serial interface to 1k bit serial EEPROM for

parameter storage for stand alone operation

Phase loss/Overcurrent/Overvoltage protection

7-bit discrete I/O for sequencing and status

monitor

Integrated brake IGBT control for dc bus voltage

limitation

ServoDesigner

Product Summary

Max Clock input

Sensorless control computation time

Speed operating range (typical)

Speed control resolution

Adjustable current limit at start-up

Programmable retry on start-up

33.3 MHz

10 µsec max

5% to 100%

15 bit full range

max 16 trials

Over current, speed, phase loss, dc bus fault protection

PWM carrier frequency

IR2175 Current feedback data resolution

Inverter leg current sensing (optional)

RS232C speed

Optional RS422 communication

Max SPI Clock

Package: QFP80

16 bit/33MHz

10bit

12bit

up to 57.6 Kbps

up to 1 Mbps

8 MHz

tool for easy operation

Parallel interface for microcontroller expansion

Description

IRMCK203 is a high performance digital motion control IC for Sensorless AC permanent magnet motor application. Control is

based on closed loop vector control for sinusoidal Back EMF motors. With IRMCK203, the users can readily build a high

performance Sensorless drive system without any programming effort and minimum start-up time. Built-in unique start-up and

ramping algorithm enables wide application. This IC is versatile enough that the users can configure and optimize system

performance according to the needs of each application. With International Rectifier iMOTION products including high voltage

ICs such as IR2175 current sensing IC and IRAM series of Intelligent IGBT module in combination with IRMCK203, the end

result is a fully optimized system with reduced electronics component counts. This simplifies the design for low cost Sensorless

drive modules. IRMCK203 can be easily adapted to various permanent magnet motors through ServoDesigner

tool, which is

the fully configurable graphic user interface tool.

This document is the property of International Rectifier and may not be copied or distributed without expressed consent.

IRMCK203

Overview

IRMCK203 is a new International Rectifier integrated circuit device designed for one-chip solution for complete

closed loop current and velocity control of a high performance Sensorless drive for PM motors. Unlike a traditional

microcontroller or DSP, IRMCK203 does not require any programming to complete complex Sensorless algorithm

development. Combined with International Rectifier's high voltage gate drive and current sensing IC, the user can

implement complete speed control of PM motors with minimum component count and virtually no design effort. In

addition to Sensorless closed loop speed control operation, features such as Start-up retry, Phase Loss detection,

Low Loss PWM, Regeneration Braking control and various drive protections are all implemented inside

IRMCK203. Analog and digital I/Os can also be configured. Host communication logic contains Asynchronous

Communication Interface for RS232C or RS422 communication interface, a fast slave SPI interface and an 8 bit

wide Host Parallel Interface. All communication ports have the same access capability to the host register set. The

users can write to, and read from the predefined registers to configure and monitor the drive through these

communication ports.

IRMCK203 Main functions

•

Complete closed loop current control based on Synchronously Rotating Frame Field Orientation (using Rotor

Angle Observer)

Closed loop velocity control based on estimated speed

Configurable parameters (PI controller gains, PI output limit range, current feedback

scaling, PWM carrier frequency) provide adaptation to various PM motors

Built-in Sensorless control logic for start-up, ramping, and running conditions

Auto Retry (programmable) on start-up with configurable torque current limit

Analog reference input (can be used for speed reference)

RS232C/RS422 reference input

Full dynamic braking control for DC bus voltage limitation

Cycle-by-cycle on/off Control for Brake IGBT

Loss minimization Space Vector PWM with deadtime insertion

Build-in two IR2175 current sensing IC interfaces

Phase Loss, Overcurrent (GATEKILL input), Overvoltage, Undervoltage, Overspeed protection

Low cost serial 12bit A/D interface with multiplexer and sample/hold circuit

Optional Inverter Leg (low side) current sensing in lieu of IR2175 IC

4 channel analog output (PWM)

Local EEPROM for startup initialization of internal data/parameters through host register interface

AT24C01A, 128X8

Versatile host communication interface

RS232C or RS422 host interface

Fast SPI slave host interface with multi-drop capability

Parallel Host interface (total 12 pins)

Multiplexed data/address bus

Address Enable

RD/WR

Discrete I/Os for Standalone mode operation

STARTSTOP (Input)

ESTOP (Input)

•

This document is the property of International Rectifier and may not be copied or distributed without expressed consent.

IRMCK203

Table of Contents

Overview........................................................................................................................................................................... 2

IRMCK203 Main functions .............................................................................................................................................. 2

IRMCK203 Block Diagrams............................................................................................................................................. 7

Basic Block Diagram .................................................................................................................................................... 7

Input/Output of IRMCK203.......................................................................................................................................... 8

Application Connections............................................................................................................................................. 12

IC Crystal Clock Circuitry .......................................................................................................................................... 13

PLL Clock Circuitry.................................................................................................................................................... 14

Low Pass Filter............................................................................................................................................................ 14

Implementing the Low Pass Filter Shield ............................................................................................................... 15

Cp Rp and Cs Component Values........................................................................................................................... 15

PLL Reset.................................................................................................................................................................... 15

DC Electrical Characteristics and Operating Conditions ................................................................................................ 16

Absolute Maximum Ratings........................................................................................................................................ 16

Recommended Operating Conditions ......................................................................................................................... 16

DC Characteristics ...................................................................................................................................................... 17

Common Quiescent and Leakage Current .................................................................................................................. 17

Input Characteristics – Non Schmitt Inputs ................................................................................................................ 17

Input Characteristics – Schmitt Inputs ........................................................................................................................ 17

Output Characteristics................................................................................................................................................. 17

Output Characteristics OSC2CLK .............................................................................................................................. 18

Pin and I/O Characteristic Table ................................................................................................................................. 19

Power Consumption .................................................................................................................................................... 21

AC Electrical Characteristics and Operating Conditions ................................................................................................ 22

System Level AC Characteristics................................................................................................................................ 22

Sync Pulse to Sync Pulse Timing............................................................................................................................ 22

FAULT and REDLED Response to GATEKILL ................................................................................................... 23

Host Interface AC Characteristics............................................................................................................................... 24

SPI Timing .............................................................................................................................................................. 24

Host Parallel Timing ................................................................................................................................................... 25

Host Parallel Read Cycle......................................................................................................................................... 25

Host Parallel Write Cycle........................................................................................................................................ 26

Discrete I/O Electrical Characteristics ........................................................................................................................ 27

Motion Peripheral Electrical Characteristics............................................................................................................... 28

PWM Electrical Characteristics .............................................................................................................................. 28

IR2175 Interface ..................................................................................................................................................... 28

Analog Interface Electrical Characteristics................................................................................................................. 29

ADC Timing............................................................................................................................................................ 29

PLL Interface Electrical Characteristics...................................................................................................................... 30

Appendix A Host Register Map .................................................................................................................................. 31

Register Access ........................................................................................................................................................... 31

Host Parallel Access................................................................................................................................................ 31

SPI Register Access ................................................................................................................................................ 31

RS-232 Register Access.......................................................................................................................................... 31

Write Register Definitions .......................................................................................................................................... 36

PwmConfig Register Group (Write Registers) ....................................................................................................... 36

CurrentFeedbackConfig Register Group (Write Registers) .................................................................................... 37

SystemControl Register Group (Write Registers)................................................................................................... 38

TorqueLoopConfig Register Group (Write Registers)............................................................................................ 38

VelocityControl Register Group (Write Registers)................................................................................................. 39

This document is the property of International Rectifier and may not be copied or distributed without expressed consent.

IRMCK203

FaultControl Register Group (Write Registers) ...................................................................................................... 40

SystemConfig Register Group (Write Registers).................................................................................................... 41

EepromControl Registers (Write Registers)............................................................................................................ 42

ClosedLoopAngleEstimator Registers (Write Registers)........................................................................................ 43

OpenLoopAngleEstimator Registers (Write Registers) .......................................................................................... 44

StartupAngleEstimator Registers (Write Registers)................................................................................................ 44

StartupRetrial Registers (Write Registers) .............................................................................................................. 45

PhaseLossDetect Registers (Write Registers) ......................................................................................................... 47

D/AConverter Registers (Write Registers) ............................................................................................................. 47

Factory Test Register (Write Register) ................................................................................................................... 48

Read Register Definitions ........................................................................................................................................... 49

SystemStatus Register Group (Read Registers) ...................................................................................................... 49

DcBusVoltage Register Group (Read Registers) .................................................................................................... 49

FocDiagnosticData Register Group (Read Registers)............................................................................................. 50

FaultStatus Register Group (Read Registers).......................................................................................................... 51

VelocityStatus Register Group (Read Registers) .................................................................................................... 52

CurrentFeedbackOffset Register Group (Read Registers) ...................................................................................... 53

EepromStatus Registers (Read Registers)............................................................................................................... 53

FOCDiagnosticDataSupplement Register Group (Read Registers) ........................................................................ 54

ProductIdentification Registers (Read Registers) ................................................................................................... 55

Factory Register (Read Register) ............................................................................................................................ 55

Appendix B Package ................................................................................................................................................... 56

This document is the property of International Rectifier and may not be copied or distributed without expressed consent.

Recommended Resources

What are the three changes in power distribution structure?

Low frequency microphone circuit diagram

Y3150 gear hobbing machine electrical schematic circuit

Sensor voltage and current conversion circuit

Circuit diagram of a regulated power supply with an output of 1A and 3.3V using M5237L external transistors.

6 LED driver circuit diagram

EEWORLD University - 3 ways to quickly adapt to changing Ethernet protocols: 3 ways to quickly adapt to changing Ethernet protocols : https://training.eeworld.com.cn/course/2143Can your designs quickly adapt to changing Ethernet protocols? Can you meet increasing performance r...; chenyy FPGA/CPLD

Ask about brushless motor drive: I would like to ask the teachers: I have a XXD 2450KV model aircraft brushless motor with three wires. I have built the motor drive circuit with 6 mosfets and related circuits, using fpga as the signa...; fatbobwang Motor Drive Control（Motor Control）

RT_THREAD static memory management: The following is a static memory pool management experimental program. In this program, a memory pool is first applied to the system and two static threads are initialized. 48 memory blocks are applie...; shilaike Embedded System

[Design Tools] Virtex-4 FPGA Embedded Tri-Mode Ethernet MAC User Guide [User Guide]: Virtex-4 FPGA Embedded Tri-Mode Ethernet MAC User Guide [User Guide] .[[i]This post was last edited by GONGHCU on 2012-3-31 23:20[/i]]...; GONGHCU FPGA/CPLD

2013 Electronic Competition National Award Review--Retest List--Question F: [i=s]This post was last edited by paulhyde on 2014-9-15 03:06[/i] [size=6][color=#ff00ff]2013 National Electronic Competition Award Review - Retest List - Question F[/color][/size][[i]This post was la...; lmx Electronics Design Contest

Download "Win the Big Data Explosion" to win Intel gifts!: For those who didn't win the gift in the last Intel white paper download event, don't miss it this time! This simple event allows you to get your favorite gift in a moment of leisure. What are you wai...; EEWORLD社区 RF/Wirelessly

Shortcut: E0 E1 E2 E3 E4 E5 E6 E7 E8 E9 EA EB EC ED EE EF EG EH EI EJ EK EL EM EN EO EP EQ ER ES ET EU EV EW EX EY EZ F0 F1 F2 F3 F4 F5 F6 F7 F8 F9 FA FB FC FD FE FF FG FH FI FJ FK FL FM FN FO FP FQ FR FS FT FU FV FW FX FY FZ G0 G1 G2 G3 G4 G5 G6 G7 G8 G9 GA GB GC GD GE GF GG GH GI GJ GK GL GM GN GO GP GQ GR GS GT GU GV GW GX GZ H0 H1 H2 H3 H4 H5 H6 H7 H8 HA HB HC HD HE HF HG HH HI HJ HK HL HM HN HO HP HQ HR HS HT HU HV HW HX HY HZ I1 I2 I3 I4 I5 I6 I7 IA IB IC ID IE IF IG IH II IK IL IM IN IO IP IQ IR IS IT IU IV IW IX J0 J1 J2 J6 J7 JA JB JC JD JE JF JG JH JJ JK JL JM JN JP JQ JR JS JT JV JW JX JZ K0 K1 K2 K3 K4 K5 K6 K7 K8 K9 KA KB KC KD KE KF KG KH KI KJ KK KL KM KN KO KP KQ KR KS KT KU KV KW KX KY KZ

Popular Components
