R1500F: Description0.5 A, SILICON, SIGNAL DIODE, DO-41; Categorysemiconductor Discrete semiconductor; File Size187KB，2 Pages; ManufacturerDCCOM [ DC COMPONENTS ]

Download Datasheet Compare View All

R1500F Overview

0.5 A, SILICON, SIGNAL DIODE, DO-41

Preview

Download Datasheet

View All

DC COMPONENTS CO., LTD.

R1200F

THRU

R3000F

RECTIFIER SPECIALISTS

TECHNICAL SPECIFICATIONS OF HIGH VOLTAGE FAST RECOVERY RECTIFIER

VOLTAGE RANGE - 1200 to 3000 Volts

CURRENT - 0.2 to 0.5 Ampere

FEATURES

*Fast switching

*Low leakage

*High current capability

*High surge capability

*High reliability

DO-41

MECHANICAL DATA

Case: Molded plastic

Epoxy: UL 94V-0 rate flame retardant

Lead: MIL-STD-202E, Method 208 guaranteed

Polarity: Color band denotes cathode end

Mounting position: Any

* Weight: 0.35 gram

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Ratings at 25

C ambient temperature unless otherwise specified.

Single phase, half wave, 60 Hz, resistive or inductive load.

For capacitive load, derate current by 20%.

Dimensions in inches and (millimeters)

SYMBOL

Maximum Recurrent Peak Reverse Voltage

Maximum RMS Volts

Maximum DC Blocking Voltage

Maximum Average Forward Rectified Current

at T

= 50

Peak Forward Surge Current, 8.3 ms single half sine-wave

superimposed on rated load (JEDEC Method)

Maximum Instantaneous Forward Voltage at 0.5A/0.2A DC

Maximum DC Reverse Current

at Rated DC Blocking Voltage T

= 25

Maximum Full Load Reverse Current Average, Full Cycle

.375* (9.5mm) lead length at T

= 55

Maximum Reverse Recovery Time (Note)

Operating and Storage Temperature Range

NOTES : Test Conditions: I

= 0.5A, I

= 1.0A, I

= 0.25A

trr

, T

STG

RRM

RMS

FSM

R1200F

1200

840

1200

R1500F R1800F R2000F R2500F R3000F

1500

1050

1500

500

2.5

5.0

100

500

-65 to + 175

4.0

5.0

1800

1260

1800

2000

1400

2000

2500

1750

2500

200

3000

2100

3000

UNITS

Volts

mAmps

Amps

Volts

uAmps

nSec

150
