TAZ Series
Including CWR09 and COTS-Plus
The TAZ part has fully molded, compliant
leadframe construction designed for use in
applications utilizing solder (Reflow, Wave
or Vapor Phase), conductive adhesive or
thermal compression bonding techniques.
Each chip is marked with polarity, capaci-
tance code and rated voltage.
The series comprises eight case sizes
(see dimensional chart below) with the
new V case enabling capacitance values
to 470 µF. The C case, with its non-stan-
dard aspect ratio, is retained as a QPL
(Qualified Product List) only special.
CASE DIMENSIONS:
millimeters (inches)
Case
Code
A
Length L
Width W
±0.38 (0.015) ±0.38 (0.015)
2.54 (0.100)
3.81 (0.150)
3.81 (0.150)
5.08 (0.200)
5.59 (0.220)
6.73 (0.265)
7.24 (0.285)
6.93 (0.273)
1.27 (0.050)
1.27 (0.050)
2.54 (0.100)
2.54 (0.100)
2.54 (0.100)
2.79 (0.110)
3.81 (0.150)
5.97 (0.235)
Height H
±0.38 (0.015)
1.27 (0.050)
1.27 (0.050)
1.27 (0.050)
1.27 (0.050)
1.78 (0.070)
2.79 (0.110)
2.79 (0.110)
3.45 (0.136)
Term. Width W
1
1.27±0.13
(0.05±0.005)
1.27±0.13
(0.05±0.005)
2.41+0.13/-0.25
(0.095+0.005/-0.01)
2.41+0.13/-0.25
(0.095+0.005/-0.01)
3.30±0.13
(0.13±0.005)
2.67±0.13
(0.105±0.005)
3.68+0.13/-0.51
(0.145+0.005/-0.02)
3.05±0.13
(0.120±0.005)
Term. Length A
±.13 (.005)
0.76 (0.030)
0.76 (0.030)
0.76 (0.030)
0.76 (0.030)
0.76 (0.030)
1.27 (0.050)
1.27 (0.050)
1.4 (0.055)
S min
0.38 (0.015)
1.65 (0.065)
1.65 (0.065)
2.92 (0.115)
3.43 (0.135)
3.56 (0.140)
4.06 (0.160)
3.38 (0.133)
H
B
S
L
A
W
1
W
D
E
F
G
H
V
MARKING
(White marking on black body)
Polarity Stripe (+)
Capacitance Code
Rated Voltage
Case sizes A through E share a common (0.050" nom) height profile, compatible with PCMCIA type II applications. These
allow downsizing in all portable applications, ranging from sub-miniature hard-disc drive (HDD)/computer to portable
communications/GPS systems. The F case at 0.070" nom offers the versatility of a low profile design, while allowing
capacitance ratings to 100 µF for low voltage filtering applications.
Cases G, H and V also offer lower profile and greater volumetric efficiency than their nearest EIA sized counterparts
(ref. CWR11). These are especially suited to power supply applications. The V case is a new addition to the series
designed to maximize capacitance/voltage ratings while achieving minimum ESR levels and maximum power dissipation.
The regular configuration allows for banking (brickwalling) applications where maximum capacitance with minimal ESR
and inductance are required in a limited board space.
20
TAZ Series
Including CWR09 and COTS-Plus
Technical Data:
Capacitance Range:
Capacitance Tolerance:
Rated DC Voltage: (V
R
)
Category Voltage: (V
C
)
Surge Voltage: (V
C
)
Unless otherwise specified, all technical
0.1 to 470 µF
±20%, ±10%, ±5%
4
6
10
15
2.7
4
7
10
5.2
8
13
20
3.5
5
9
12
-55°C to +125°C
data relate to an ambient temperature of 25°C
85°C:
125°C:
85°C:
125°C:
Operating Temperature Range:
20
13
26
16
25
17
33
21
35
23
46
28
50
33
65
40
CWR09 - MIL-PRF-55365/4
Fully qualified to MIL-PRF-55365/4, this series represents
the most flexible of surface mount form factors, offering eight
case sizes (A through H). This series is fully interchangeable
with CWR06 conformal types, while offering the advantages
