Product Specification
C216x04 series
Crystal Clear Technology sdn. bhd.
16Jalan TP5—Taman Perindustrian Sime UEP
47600 Subang Jaya—Selangor DE
Malaysia. T: +603 80247099 F: +603 80247098
CRYSTAL CLEAR TECHNOLOGY SDN. BHD.
Spec. No: C216x04xxW00 REV. 1.0
1.0
Table of Contents
Page
1. Table of Contents
2. Record of revision
3. General specification
4. Absolute maximum ratings
5. Electrical characteristics
6. Environmental requirement
7. LCD specification
8. Interface
9. Timing characteristics / Timing diagrams
10. Power supply
11. Block diagram
12. Instructions
13. Quality assurance
14. Precautions in use LCM
15. Outline drawing
1
2
3
4
4
4
5~7
8
9 ~ 11
12
12
13 ~ 16
17 ~ 18
19 ~ 20
21
1
CRYSTAL CLEAR TECHNOLOGY SDN. BHD.
Spec. No: C216x04xxW00 REV. 1.0
2.0
Rev
1.0
Record of revision
Item
Page
Comment
Initial Release
Originator
Syam
Checked By
Azhar
Date
04/06/08
2
CRYSTAL CLEAR TECHNOLOGY SDN. BHD.
Spec. No: C216x04xxW00 REV. 1.0
3.0
General specification
Display format: 2 lines x 16 characters
Character font format: 5 x 8
Character size: 2.95mm x 5.55mm
View area: 61.0mm x 15.8mm
Active area: 56.2mm x 11.5mm
General dimensions: 84.0mm x 44.0mm
Controller/Driver: ST7066U-0A-B and ST7065C-B or equivalent
C
2 1 6
0 4
W
R
0 0
MODEL NUMBER
STD. CHARACTER : No. of line followed by no. of character
SERIES NUMBER FOR THIS STANDARD SPECIFICATION
BACKLIGHT MODE
L : Bottom Led Backlight (Yellow Green) W : Side Led Backlight (White)
N : No Backlight
R : Bottom Led Backligt (Red)
A : Bottom Led Backlight (Amber)
B : Side Led Backlight (Blue)
MODULE VERSION
SERIES NUMBER FOR THIS STANDARD SPECIFICATION
LCD MODE
Y : Yellow Green (STN)
G : Grey (STN)
B : Black & White (FSTN)
N : Negative (FSTN) Blue ( Single Retardation )
U : Negative (FSTN) Black/White ( Double Retardation )
S : Negative (STN)
VIEWING ANGLE
T : Top view ( 12 O'clock )
B : Bottom view ( 6 O'clock )
OPERATING TEMPERATURE
W : Wide Temperature ( -20°C to +70°C ), where storage temperature is (-30°C to +80°C)
BACKLIGHT TERMINAL
FOR BACKLIGHT REVERSE CONNECTION ONLY
IF NON-REVERSE PRODUCT (STANDARD DEFAULT), THIS SUFFIX IS BLANK.
SEMI - CUSTOMISE (MINOR CHANGES FROM STANDARD MODEL)
00 - STANDARD SPECIFICATION MODEL
REFER TO FACTORY FOR OTHER VERSIONS. TERMS AND CONDITIONS APPLY
3
CRYSTAL CLEAR TECHNOLOGY SDN. BHD.
Spec. No: C216x04xxW00 REV. 1.0
4.0
NO
1.
2.
3.
4.
Absolute maximum rating (at Vss = 0V, ambient temperature = 25°C)
ITEM
Power Supply voltage (Logic)
Power Supply voltage (LCD Driver)
Operating Temperature
Storage Temperature
SIMBOL
V
DD
– V
SS
V
DD
– V
0
T
op
T
st
MIN MAX
0
7
-
12
Refer page 3
Refer page 3
UNIT
V
V
°C
°C
5.0
NO
1.
2.
3.
4.
5.1
NO
1.
2.
3.
4.
5.
Electrical characteristics
ITEM
Power Supply
voltage (Logic)
Power Supply
voltage (V
LCD
)
Input Voltage
(except OSC1)
Current Supply
Backlight Options
COLOR
Yellow Green
White
Blue
Amber
Red
FORWARD VOLTAGE
(V)
Min
Typ.
Max
-
5.0
-
-
5.0
-
-
5.0
-
-
5.0
-
-
5.0
-
FORWARD CURRENT
(mA)
Min
Typ.
Max
-
100
150
-
30
40
-
30
40
-
100
150
-
100
150
MIN
BRIGHTNESS
(cd/m2) *
60
160
70
170
170
SYMBOL
CONDITION
-
25°C
-
-
V
DD
– V
SS =
5V
MIN
4.5
TYP
5.0
4.5±5%
MAX
UNIT
5.5
V
V
V
DD
0.6
2.0
V
V
mA
V
DD
– V
SS
V
DD
-V
0
V
IH
V
IL
I
DD
0.7V
DD
-0.3
1.0
-
-
1.3
*Note : 1. Brightness measured at backlight surface.
2. On LCD surface, brightness is only about 10% to 15% of backlight brightness.
3. Lifetime of backlight: For YG, Amber, Red = 50K hrs. For White, Blue = 20K hrs.
6.0
NO
1.
Environmental requirements
ITEM
Operating
Temperature
Storage Temperature
Operating Humidity
Cycle Test
Lifetime
CONDITION
Refer page 3
Refer page 3
5% to 95%RH
-20 ºC @ 30 min to 70 ºC @ 30min for 1 cycle
run for 10 cycles
50000 HOURS (excluding backlight)
2.
3.
4.
5.
Note: The background on LCD has the possibility to be changed in different temperature range.
4
