Aluminum Electrolytic Capacitors
LONG LIFE, LOW IMPEDANCE, HIGH TEMPERATURE, RADIAL LEADS,
POLARIZED ALUMINUM ELECTROLYTIC CAPACITORS
RoHS
FEATURES
Compliant
• LONG LIFE AT 105
O
C (4000 ~ 10,000 hrs.)
• HIGH CAPACITANCE (UP TO 18,000µF)
• LOW IMPEDANCE
NRE-HL Series
includes all homogeneous materials
*See Part Number System for Details
CHARACTERISTICS
Rated Voltage Range
Rated Capacitance Range
Operating Temperature Range
Capacitance Tolerance
Max. Leakage Current After 2 Minutes
Maximum Tanδ @120Hz/20°C
W.V. (Vdc)
Low Temperature Stability
Z -25°C/+20°C
(Impedance Ratio @ 120Hz)
Z -40°C/+20°C
Load Life @ 105°C
6.3V ~ 10V 16V ~ 100V
4,000 hrs
6,000 hrs
8,000 hrs
5,000 hrs
7,000 hrs
10,000 hrs
Appearance
Capacitance Change
Tan
δ
Leakage Current
Appearance
6.3
4
8
6.3 ~ 100Vdc
6.8 ~ 18,000µF
-40°C ~ +105°C
±20% (M)
0.01CV or 3µA whichever is greater
(See Specifications Tables)
10
16
25
35
50
63
3
2
2
2
2
2
6
4
3
3
3
3
Allowable Change
No Notable Changes (except sleeving)
Within ±25% of initial measured value
Less than 200% of specificed value
Less than the specificed maximum value
No Notable Changes (except sleeving)
Within ±25% of initial measured value
Less than 200% of specificed value
Less than the specificed maximum value
100
2
3
Case Size
5mm ~ 6.3mm
8mm ~ 10mm
12.5mm ~ 18mm
Shelf Life
After storage for 1,000 hours @ 105°C
Capacitance Change
Tan
δ
Leakage Current
LEAD SPACING AND DIAMETER (mm)
Case Dia. (Dφ)
Lead Space (F)
Lead Dia. (dφ)
Dim.
β
5
6.3
2.0 2.5
0.5
8
3.5
1.5
12.5
5.0
0.6
10
16
7.5
0.8
2.0
18
PART NUMBERING SYSTEM
NRE-HL 101 M 25V 8X11 TB F
DIMENSIONS (mm)
Polarity Marking
Sleeve
+
dφ ± 0.05
F ± 0.5
-
L +
β
max.
15mm Min.
Series
4mm
Min.
Dφ ±
α
RoHS Compliant
TB = Tape & Box*
Case Size (DφxL)
Working Voltage (Vdc)
Tolerance Code (M=20%)
Cap. Code: First 2 characters significant
Third character is multiplier
*see tape specification for details
RIPPLE CURRENT FREQUENCY
CORRECTION FACTOR
Capacitance Value
6.8µF ~ 33µF
39µF ~ 270µF
330µF ~ 680µF
820µF ~ 1800µF
2200µF ~ 18000µF
120Hz
0.42
0.50
0.55
0.60
0.70
1KHz
0.70
0.73
0.77
0.80
0.85
Drawing is representative of parts as supplied in bulk or
straight lead format, please see taping specification for details
on taped format packaging.
10KHz 100KHz
0.90
1.00
0.92
1.00
0.94
1.00
0.96
1.00
0.98
1.00
PRECAUTIONS
Please review the notes on correct use, safety and precautions found at
https://www.niccomp.com/resource/files/aluminum/AlumApplInfoCautions.pdf
If in doubt or uncertainty, please review your specific application - process details
with NIC’s technical support personnel: tpmg@niccomp.com
