Snap-In Aluminum Electrolytic Capacitors
ELH, +85°C
Overview
Applications
Typical applications include general purpose power
electronics, UPS, SMPS, and battery chargers.
The KEMET ELH aluminum electrolytic snap-in capacitors
are designed with snap-lock terminals for printed circuit
board mounting. The case is aluminum with an insulated
sleeve and safety vent at the bottom.
Benefits
•
•
•
•
Suited for high quality, high reliability applications
Operating temperature of up to 85°C
2,000 hour operating life
RoHS compliant and lead-free
Click image above for interactive 3D content
Open PDF in Adobe Reader for full functionality
Part Number System
ELH
Series
Snap-In
Aluminum
Electrolytic
159
Capacitance Code
(pF)
First two digits
represent
significant
figures for
capacitance
values. Last
digit specifies
the number
of zeros to be
added.
M
Tolerance
M = ±20%
6R3 = 6.3
010 = 10
016 = 16
025 = 25
035 = 35
050 = 50
063 = 63
080 = 80
100 = 100
6R3
Rated Voltage
(VDC)
160 = 160
180 = 180
200 = 200
250 = 250
350 = 350
400 = 400
420 = 420
450 = 450
500 = 500
A
Electrical
Parameters
A = Standard
Q1
Size Code
See Dimension
Table
AA
Packaging
See Ordering
Options Table
Ordering Options Table
Packaging Type
Lead Length (mm)
Lead and
Packaging Code
AA
AV
Standard Bulk Packaging Options
Bulk (box)
Bulk (box)
5.8 ± 1.0
4.0 ± 1.0
Built Into Tomorrow
© KEMET Electronics Corporation • KEMET Tower • One East Broward Boulevard
Fort Lauderdale, FL 33301 USA • 954-766-2800 • www.kemet.com
A4018_ELH • 2/17/2021
1
Snap-In Aluminum Electrolytic Capacitors – ELH, +85°C
Dimensions – Millimeters
SIDE VIEW
L
D
LL
TERMINAL DETAIL
0.8 ±0.1
3 ±0.5
0.8 ±0.1
TERMINAL
END VIEW
PCB LAYOUT
5.8±1
1.5 ±0.1
1.5 ±0.1
P
Size Code
Q7
Q1
Q2
Q3
Q4
Q5
Q6
R7
R1
R2
R3
R4
R5
R6
S1
S2
S3
S4
S5
S6
T1
T2
T3
T4
T5
T6
T8
D
Nominal
22
22
22
22
22
22
22
25
25
25
25
25
25
25
30
30
30
30
30
30
35
35
35
35
35
35
35
Tolerance
+1.0/−0
+1.0/−0
+1.0/−0
+1.0/−0
+1.0/−0
+1.0/−0
+1.0/−0
+1.0/−0
+1.0/−0
+1.0/−0
+1.0/−0
+1.0/−0
+1.0/−0
+1.0/−0
+1.0/−0
+1.0/−0
+1.0/−0
+1.0/−0
+1.0/−0
+1.0/−0
+1.0/−0
+1.0/−0
+1.0/−0
+1.0/−0
+1.0/−0
+1.0/−0
+1.0/−0
Nominal
20
25
30
35
40
45
50
20
25
30
35
40
45
50
25
30
35
40
45
50
25
30
35
40
45
50
60
L
Tolerance
+2.0/−0
+2.0/−0
+2.0/−0
+2.0/−0
+2.0/−0
+2.0/−0
+2.0/−0
+2.0/−0
+2.0/−0
+2.0/−0
+2.0/−0
+2.0/−0
+2.0/−0
+2.0/−0
+2.0/−0
+2.0/−0
+2.0/−0
+2.0/−0
+2.0/−0
+2.0/−0
+2.0/−0
+2.0/−0
+2.0/−0
+2.0/−0
+2.0/−0
+2.0/−0
+2.0/−0
Nominal
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
p
Tolerance
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
© KEMET Electronics Corporation • KEMET Tower • One East Broward Boulevard
Fort Lauderdale, FL 33301 USA • 954-766-2800 • www.kemet.com
A4018_ELH • 2/17/2021
2
Snap-In Aluminum Electrolytic Capacitors – ELH, +85°C
Environmental Compliance
As an environmentally conscious company, KEMET is working continuously with improvements concerning the environmental
effects of both our capacitors and their production. In Europe (RoHS Directive) and in some other geographical areas like
China, legislation has been put in place to prevent the use of some hazardous materials, such as lead (Pb), in electronic
equipment. All products in this catalog are produced to help our customers’ obligations to guarantee their products and fulfill
these legislative requirements. The only material of concern in our products has been lead (Pb), which has been removed
from all designs to fulfill the requirement of containing less than 0.1% of lead in any homogeneous material. KEMET will
closely follow any changes in legislation world wide and make any necessary changes in its products, whenever needed.
Some customer segments such as medical, military and automotive electronics may still require the use of lead in electrode
coatings. To clarify the situation and distinguish products from each other, a special symbol is used on the packaging labels
for RoHS compatible capacitors.
Due to customer requirements, there may appear additional markings such as lead free (LF) or lead-free wires (LFW) on the
label.
Performance Characteristics
Item
Capacitance Range
Capacitance Tolerance
Rated Voltage
Life Test
Operating Temperature
Leakage Current
6.3 – 100 VDC
820 – 120000 µF
±20% at 120 Hz/20°C
160 – 500 VDC
Performance Characteristics
47 – 2,200 µF
2,000 hours (see conditions in Test Methods & Performance)
−40°C to +85°C
−25°C to +85°C
I = 0.02 CV (mA) or 3 mA, whichever is smaller
C = rated capacitance (µF), V = rated voltage (VDC). Voltage applied for 5 minutes at 20°C.
Compensation Factor of Ripple Current (RC) vs. Frequency
Rated Voltage (VDC)
6.3 – 100
160 – 250
350 – 450
500
50 Hz
0.88
0.75
0.74
0.72
60 Hz
0.90
0.78
0.76
0.74
120 Hz
1.00
1.00
1.00
1.00
1 kHz
1.15
1.30
1.35
1.20
10 kHz
1.16
1.50
1.45
1.30
© KEMET Electronics Corporation • KEMET Tower • One East Broward Boulevard
Fort Lauderdale, FL 33301 USA • 954-766-2800 • www.kemet.com
A4018_ELH • 2/17/2021
3
Snap-In Aluminum Electrolytic Capacitors – ELH, +85°C
Test Method & Performance
Conditions
Temperature
Test Duration
Ripple Current
Voltage
Load Life Test
85°C
2,000 hours
Maximum ripple current specified at 120 kHz 85°C
specified in table
The sum of DC voltage and the peak AC voltage
must not exceed the rated voltage of the capacitor
Shelf Life Test
85°C
1,000 hours
No ripple current applied
No voltage applied
Performance
Capacitance Change
Dissipation Factor
Leakage Current
The following specifications will be satisfied when the capacitor is restored to 20°C:
Within ±20% of the initial value
Does not exceed 200% of the specified value
Does not exceed specified value
Does not exceed 200% of the specified value
Shelf Life
The capacitance, ESR and impedance of a capacitor will not change significantly after extended storage periods, however,
the leakage current will very slowly increase.
KEMET's E aluminum electrolytic capacitors should not be stored in high temperatures or where there is a high level of
humidity. The suitable storage condition for KEMET's E aluminum electrolytic capacitors is +5 to +35°C and less than 75%
in relative humidity. KEMET's E aluminum electrolytic capacitors should not be stored in damp conditions such as water,
saltwater spray or oil spray. KEMET's E aluminum electrolytic capacitors should not be stored in an environment full of
hazardous gas (hydrogen sulphide, sulphurous acid gas, nitrous acid, chlorine gas, ammonium, etc.) KEMET's E aluminum
electrolytic capacitors should not be stored under exposure to ozone, ultraviolet rays or radiation.
If a capacitor has been stored for more than 18 months under these conditions and it shows increased leakage current,
then a treatment by voltage application is recommended.
Re-Age (Reforming) Procedure
Apply the rated voltage to the capacitor at room temperature for a period of one hour, or until the leakage current has fallen
to a steady value below the specified limit. During re-aging a maximum charging current of twice the specified leakage
current or 5 mA, whichever is greater, is suggested.
© KEMET Electronics Corporation • KEMET Tower • One East Broward Boulevard
Fort Lauderdale, FL 33301 USA • 954-766-2800 • www.kemet.com
A4018_ELH • 2/17/2021
4
Snap-In Aluminum Electrolytic Capacitors – ELH, +85°C
Table 1 – Ratings & Part Number Reference
Rated
Voltage
(VDC)
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
16
16
16
Surge
Voltage
(VDC)
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
20
20
20
Rated
Capacitance
120 Hz 20°C
(µF)
15,000
18,000
22,000
27,000
33,000
39,000
18,000
22,000
27,000
33,000
39,000
47,000
56,000
27,000
33,000
39,000
47,000
56,000
68,000
82,000
33,000
39,000
47,000
56,000
68,000
82,000
100,000
120,000
12,000
15,000
18,000
22,000
27,000
33,000
15,000
18,000
22,000
27,000
33,000
39,000
47,000
22,000
27,000
33,000
39,000
47,000
56,000
68,000
33,000
39,000
47,000
56,000
68,000
82,000
8,200
10,000
12,000
Case Size
DxL
(mm)
22 x 25
22 x 30
22 x 30
22 x 35
22 x 40
22 x 50
25 x 25
25 x 25
25 x 30
25 x 35
25 x 40
25 x 45
25 x 50
30 x 25
30 x 30
30 x 30
30 x 35
30 x 40
30 x 45
30 x 50
35 x 25
35 x 25
35 x 30
35 x 30
35 x 35
35 x 40
35 x 45
35 x 50
22 x 25
22 x 30
22 x 35
22 x 40
22 x 45
22 x 50
25 x 25
25 x 25
25 x 30
25 x 35
25 x 40
25 x 45
25 x 50
30 x 25
30 x 30
30 x 30
30 x 35
30 x 40
30 x 45
30 x 50
35 x 25
35 x 30
35 x 30
35 x 35
35 x 40
35 x 50
22 x 25
22 x 30
22 x 30
DF
120 Hz 20°C
(tanδ %)*
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
55
55
55
55
55
55
55
55
55
55
55
55
55
55
55
55
55
55
55
55
55
55
55
55
55
55
55
55
55
RC
120 Hz 85°C (A)
2.44
2.60
3.06
3.49
3.97
4.56
2.62
3.07
3.52
4.02
4.50
5.09
5.71
3.57
4.05
4.46
5.06
5.70
6.48
7.32
4.10
4.51
5.03
5.75
6.42
7.29
8.31
8.60
2.40
2.75
3.15
3.55
4.05
4.60
2.75
3.05
3.50
4.00
4.55
5.10
5.75
3.55
4.05
4.50
5.05
5.70
6.45
7.05
4.50
5.05
5.65
6.40
7.10
7.50
2.60
2.70
2.90
LC
20°C 5 minutes
(mA)
1.9
2.3
2.8
3.0
3.0
3.0
2.3
2.8
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
2.4
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
2.6
3.0
3.0
Part Number
( ) Represents
Part Number Options
ELH159M6R3AQ1(1)
ELH189M6R3AQ2(1)
ELH229M6R3AQ2(1)
ELH279M6R3AQ3(1)
ELH339M6R3AQ4(1)
ELH399M6R3AQ6(1)
ELH189M6R3AR1(1)
ELH229M6R3AR1(1)
ELH279M6R3AR2(1)
ELH339M6R3AR3(1)
ELH399M6R3AR4(1)
ELH479M6R3AR5(1)
ELH569M6R3AR6(1)
ELH279M6R3AS1(1)
ELH339M6R3AS2(1)
ELH399M6R3AS2(1)
ELH479M6R3AS3(1)
ELH569M6R3AS4(1)
ELH689M6R3AS5(1)
ELH829M6R3AS6(1)
ELH339M6R3AT1(1)
ELH399M6R3AT1(1)
ELH479M6R3AT2(1)
ELH569M6R3AT2(1)
ELH689M6R3AT3(1)
ELH829M6R3AT4(1)
ELH10KM6R3AT5(1)
ELH12KM6R3AT6(1)
ELH129M010AQ1(1)
ELH159M010AQ2(1)
ELH189M010AQ3(1)
ELH229M010AQ4(1)
ELH279M010AQ5(1)
ELH339M010AQ6(1)
ELH159M010AR1(1)
ELH189M010AR1(1)
ELH229M010AR2(1)
ELH279M010AR3(1)
ELH339M010AR4(1)
ELH399M010AR5(1)
ELH479M010AR6(1)
ELH229M010AS1(1)
ELH279M010AS2(1)
ELH339M010AS2(1)
ELH399M010AS3(1)
ELH479M010AS4(1)
ELH569M010AS5(1)
ELH689M010AS6(1)
ELH339M010AT1(1)
ELH399M010AT2(1)
ELH479M010AT2(1)
ELH569M010AT3(1)
ELH689M010AT4(1)
ELH829M010AT6(1)
ELH828M016AQ1(1)
ELH109M016AQ2(1)
ELH129M016AQ2(1)
Rated
Voltage
Surge
Voltage
Rated
Capacitance
Case
Size
DF
RC
LC
Part
Number
(1) Insert packaging code. See Ordering Options Table for available options.
* When capacitance exceeds 1,000 µF, the DF value (%) is increased by 2% for every additional 1,000 µF.
© KEMET Electronics Corporation • KEMET Tower • One East Broward Boulevard
Fort Lauderdale, FL 33301 USA • 954-766-2800 • www.kemet.com
A4018_ELH • 2/17/2021
5
京公网安备 11010802033920号
EEWORLD
