SPNO/SPDT
TYPE 124
DC POWER
CONTACTORS
Single Pole Normally Open, or Single Pole Double Throw Contacts.
Dust Resistant and Endcaps are Isolated from Bracket
SPECIFICATIONS
Dimensions, 24-05,-4,-7 . . . .
Dimensions, 24-305,-34 . . . . . . . . . .
Weight
, 24-05,-4,-7
. . . . . . . . . .
Weight
, 24-305,-34
. . . . . . . . . . . . . . . . .
Temperature Range . . . . . . . . . . . . . . . . . . . . . .
Terminations, Contacts . . . . . . . . . . . . . . . . . . . .
Terminations, Coil . . . . . . . . . . . . . . . . . . . . . . . .
3.56”L x 3.3”W x 2.9”H
4.69”L x 3.3”W x 2.9”H
6.0 oz.
9.0 oz.
-40° to +49°F
5 6
/
”-24
UNF-2A thread
#0-32 UNF-2A thread
Recommended Mounting . . . . . . . . . . . . . . . . . . . . . . . Vertical plane with coil terminals up
Hardware Torque, Contact Terminal . . . . . . . . . . . . . . . 60 in. lbs. max.
Hardware Torque, Coil Terminal . . . . . . . . . . . . . . . . . . 2-8 in. lbs.
Caution:
A back-up wrench must be used to hold the bottom nut stationary.
Terminal
Type
➀
4
4
6
4
6
Bracket
Style
Standard
Standard
Standard
Standard
Standard
Coil
Coil
Contact Rating (Amps) – Inductive Load
Voltage Resistance Contact Voltage
Normally Open
Normally Closed
D.C.
(Ohms)
➁
Material
D.C.
Continuous Inrush Continuous Inrush
2
3.2
Silver Alloy
2
00
400
–
–
24
53.0
Silver Alloy
24
00
400
–
–
24
53.0
Silver Alloy
24
00
400
50
00
36
20.0
Silver Alloy
36
00
400
–
–
36
20.0
Silver Alloy
36
00
400
50
00
Type 124
RELAYS and
TRANSFORMERS
Model
Number
124-105111
124-114111
124-314111
124-117111
124-317111
Duty
Cycle
Continuous
Continuous
Continuous
Continuous
Continuous
➀
“4” = Isolated Coil, SPNO
“6” = Isolated Coil, SPDT
➁
Coil resistance in Ohms @ 25°C
➂
Inrush Current: Current applied within the first 1/2 second of contact closure
TYPE 586
Single Pole Normally Open, or Single Pole Double Throw Contacts.
Water Resistant and Case is Isolated from Bracket
SPECIFICATIONS
Dimensions, 586-4,-7 . . . . . . . . . . .
Dimensions, 586-37 . . . . . . . . . . . . . . . . .
Weight
, 586-4,-7
. . . . . . . . . . . . . . . . .
Weight
, 586-37
. . . . . . . . . . . . . . . . . . . . . . . . .
Temperature Range . . . . . . . . . . . . . . . . . . . . . .
Terminations, Contacts . . . . . . . . . . . . . . . . . . . .
Terminations, Coil . . . . . . . . . . . . . . . . . . . . . . . .
3.69”L x 3.30”W x 2.90”H
4.6”L x 3.30”W x 2.90”H
24.0 oz.
26.0 oz.
-40° to +49°F
5 6
/
”-24
UNF-2A thread
#0-32 UNF-2A thread
Recommended Mounting . . . . . . . . . . . . . . . . . . . . . . . Vertical plane with coil terminals up
Hardware Torque, Contact Terminal . . . . . . . . . . . . . . . 60 in. lbs. max.
Hardware Torque, Coil Terminal . . . . . . . . . . . . . . . . . . 2-8 in. lbs.
Terminal
Type
➀
4
4
4
4
4
6
6
Bracket
Style
Standard
Standard
Standard
Standard
Standard
Standard
Standard
Coil
Coil
Contact Rating (Amps) – Inductive Load
Voltage Resistance Contact Voltage
Normally Open
Normally Closed
D.C.
(Ohms)
➁
Material
D.C.
Continuous Inrush➂ Continuous Inrush➂
2
2.0
Silver Alloy
2
200
600
–
–
5
32.8
Silver Alloy
5
200
600
–
–
24
84.0
Silver Alloy
24
200
600
–
–
36
89.0
Silver Alloy
36
200
600
–
–
48
336.0
Silver Alloy
36
200
600
–
–
24
84.0
Silver Alloy
24
200
600
00
200
36
20.0
Silver Alloy
36
200
600
00
200
Type 586 SPNO
Model
Number
586-105111
586-108111 ➃
586-114111
586-117111
586-120111
586-314111
586-317111
Duty
Cycle
Continuous
Continuous
Continuous
Continuous
Continuous
Continuous
Continuous
➀
“4” = Isolated Coil, SPNO
“6” = Isolated Coil, SPDT
➁
Coil resistance in Ohms @ 25°C
➂
Inrush Current: Current applied within the first 1/2 second of contact closure
➃
Ideal for 2V charging systems
NOTE:
CAUTION must be used in coil selection for use in 2 volt
sytems where battery charging may expose coil to continuous,
higher-than-rated voltage. 5 volt coils are recommended.
White-Rodgers will not be responsible for consequences of misap-
plied solenoids.
