SM Crystal for Wireless
Specifications
GSX-333
Parameters
Frequency range:
12.0 ~ 54.0MHz
54.0 ~ 125MHz (3rd overtone)
Calibration tolerance:
±10ppm
±15ppm
±20ppm
Other values (±7.5 ~ ±100ppm)
±10ppm
±15ppm
±20ppm
±30ppm
Other values (±7.5 ~ ±100ppm)
Product
GSX-333
M
N
B
D
E
S
specify
F
3
1
P
2
specify
1
P
2
3
specify
1
2
B
3
4
specify
Option
Codes
3.30
(max)
Temperature stability:
2.60
(max)
0.70
(max)
SOLDER PAD LAYOUT
0.70
1
4
1.20
2
1.00
3
1
2
1.20
0.30
4
3
1.20
Operating temperature range:
-10 to +60°C
-20 to +70°C
-25 to +75°C
-30 to +80°C
-40 to +85°C
Other values
Storage temperature range:
-40 to +85°C
Circuit condition:
8pF
9pF
12pF
16pF
18pF
Series resonant
Other values
Fundamental
3rd overtone
1.40
1.40
TOP VIEW
PAD
1
2
3
4
CONNECTION
Crystal
Ground & lid
Crystal
Ground & lid
NOTE: Chamfer normally on pad 4, but
Oscillation mode:
Features
Good frequency perturbation
Metal lid can be grounded to minimise EMI
Seam sealed for excellent long-term stability
Ultra-miniature for maximum space saving
Ideal for Bluetooth / Wireless applications
Equivalent series resistance (max):
100Ω max (12.0 ~ 15.99MHz)
60Ω max (16.0 ~ 19.99MHz)
50Ω max (20.0 ~ 54.0MHz, fund)
100Ω max (54.0 ~ 99.99MHz, 3rd OT)
80Ω max (100 ~ 125MHz, 3rd OT)
Frequency perturbation:
±1ppm max
Ageing:
±1ppm max first year
10μW
Test drive level:
Bluetooth Applications
Frequency
12.0MHz
16.0MHz
26.0MHz
Specification
8pF, 10.5ppm/pF typ pullability
9pF, 9ppm/pF typ pullability
9pF, 16.5ppm/pF typ pullability
IC
CSR
CSR
CSR
Part No
MA07080*
MA06152*
MA05768*
Soldering condition:
260°C, 10 sec x2 max
Standard.
Optional - Please specify required code(s) when ordering
Ordering Information
Product name + option codes + frequency
eg:
GSX-333/111NF 16.0MHz
10/10/10/9-F
GSX-333/1P3AF 26.0MHz
10/15/30/10-F
Option code X (eg GSX-333/X) denotes a custom specification.
±10ppm temperature stability may not be available over -30+80°C.
Check with our sales office before ordering.
* Qualified for use with CSR chipset solutions. Golledge is a global supply partner for CSR
GPS / Mobile Applications
Frequency
20.0MHz
16pF
Specification
IC / Appln
Part No
MA06153
Tel:
+44 1460 256 100
20 Feb 2014
Fax:
+44 1460 256 101
E-mail:
sales@golledge.com
Web:
www.golledge.com
Product Information
Construction
GSX-333
Ceramic body with gold-plated pads
Metal lid, seam sealed
Composition
RoHS
2002/95/EC
This product is lead-free, and is fully compliant with
the RoHS directive 2002/95/EC
Pb
LeadFree
Packaging & Handling
Production quantities supplied on T&R, 3k pcs per reel.
Small quantities may be supplied on tape (no reel), or in bulk.
Soldering Profile
°C
10s max
Marking
FREQUENCY
T zDC
Year
Code
Marking type: Laser
DC = Date code in YW, as shown below
Example: “zd” = 2012 week 30
Week codes:
A ~ Z: weeks 1 to 26
a ~ z: weeks 27 to 52
260
200
2009 2010 2011 2012
2013 2014 2015 2016
Z
z
Z
z
100
5°C/s max
5°C/s max
Tape & Reel Specification
4.0 2.0
±0.05
1.50Ø
1.75
0
Preheat
140~160°C
60~90s max
Heat
> 200°C
50~60s max
Slow
cooldown
Time
0.3
Maximum solder resistance: 260
°
C x 10 secs x 2.
5°
±0.05
MARK
5.5
3.8
12.0
±0.3
1.1
2.8
4.0
3.0
120°
1.50
20.2Ø
330Ø
FEED
12.4
-0.0
+2.0
13Ø
100Ø
Not to scale. Dimensional tolerances ±0.1mm unless otherwise stated.
Tel:
+44 1460 256 100
24 May 2011
Fax:
+44 1460 256 101
E-mail:
sales@golledge.com
Web:
www.golledge.com
