MEDER electronic AG
Friedrich-List-Strasse 6
78234 Engen-Welschingen
Phone.:
Fax:
eMail:
Internet:
+49 (0) 7733 / 9487-0
+49 (0) 7733 / 9487-32
info@meder.com
www.meder.com
type:
DIP15-2A72-21L
part number:
3215272021
dimensions
(tolerance ± 0,1mm)
layout
21L
pitch
2,54 /
top view
marking
Type
data-code EN 60062
coil data
coil resistance
nominal voltage
pull-in voltage
drop-out voltage
coil voltage
coil voltage
nominal power
condition
at 20°C
Min.
1800
Typ.
15,0
Max.
2200
10,5
unit
W
VDC
VDC
VDC
VDC
VDC
mW
2,2
at 20°C
at 60°C
determined with
nominal voltage and rated current
44,0
28,5
113
contact data 72 (Form A/Dry)
contact material
rated power
switching voltage
switching current
carry current
static contact resistance
Insulation resistance
breakdown voltage
capacitance
each combination of the switching voltage
and current must not exceed the given
rated power
Ruthenium
15
200
1,0
1,25
150
10
10
250
0,3
W
VDC
A
A
mW
W
VDC
pF
initial values measured with 1,4 x AT
pull-in
RH
W
45%
without test coil
relay data
insulation resistance coil-contact
insulation voltage coil-contact
shock
vibration
operate time inclusive bounce
release time
10
11
1,5
½ sine wave, duration 11ms
50 – 2000Hz
measured at 1,4 x AT
pull-in
150
10
0,5
0,1
W
kVDC
g
g
ms
ms
general data
operating temperature
storing temperature
soldering temperature
cleaning
material of case
material of pins
-20
-35
10 sec. at
70
95
260
fully sealed
mineral-filled epoxy
Cu-alloy tinned
°C
°C
°C
modifications in the sense of technical progress are reserved
index 00
2001-10-11
