XTH, XTK, XTL, XTM, XTV
www.vishay.com
Vishay
Wet Tantalum Capacitors
Cylindrical Body, Hermetically Sealed
FEATURES
• High temperature
• High voltage
• High capacitance
• Withstands high frequency vibration to 2000 Hz
• Hermetically sealed
• Long shelf life
• DSCC drawings 04032 and 04033
Available
Available
PERFORMANCE CHARACTERISTICS
Operating Temperature:
-55 °C to +175 °C with proper
derating
Voltage Range:
8 V
DC
to 630 V
DC
at 85 °C
Reverse Voltage:
None
Capacitance Range:
2 μF to 2200 μF
Tolerance Range:
-15 % to +50 % (standard for XTK, XTM, XTV)
-15 % to +75 % (standard for XTH, XTL)
± 20 % (special order)
• Various termination options: Standard 100 % nickel
(RoHS compliant), tin/lead (Sn/Pb) available
• Mounting: Arrays and assemblies
• Material categorization: For definitions of compliance
please see
www.vishay.com/doc?99912
Note
*
This datasheet provides information about parts that are
RoHS-compliant and/or parts that are non-RoHS-compliant. For
example, parts with lead (Pb) terminations are not RoHS-compliant.
Please see the information/tables in this datasheet for details.
ORDERING INFORMATION
XTV
MODEL
XTH
XTK
XTL
XTM
XTV
126
CAPACITANCE
CODE
This is
expressed
in picofarads.
The first two
digits are
the significant
figures. The
third is the
number of
zeros to follow.
T
CAPACITANCE
TOLERANCE
T = -15 %
to +50 %
(XTK, XTM,
XTV standard)
U = -15 %
to +75 %
(XTH, XTL
standard)
M = ± 20 %
(special order)
630
DC VOLTAGE
RATING
This is
expressed
in volts. To
complete the
three-digit
block, zeros
precede the
voltage rating.
P
CASE CODE
P = Polar
(case negative)
R = Reverse
polarity
(case positive)
0
INSULATION
0 = Uninsulated
(standard)
4 = Teflon
(+175 °C limit)
A
TERMINAL
CONFIGURATION
See Styles
RoHS
COMPLIANT
Blank = 100 %
nickel (RoHS
compliant design)
8 = 60/40 solder
(tin/lead
termination
design)
Note
• For styles, terminal configurations, mounting methods and hardware, please see pages following Standard Ratings table
DIMENSIONS
in inches [millimeters]
XTH-XTL-XTV
H
(+)
D
Case
negative
5/16 ± 1/16
XTK-XTM
D
2.250
± 0.250
(+)
H
2.250
± 0.250
(-)
0.281
± 0.062
0.281
± 0.062
TYPE
XTK - XTM
XTL - XTH
XTV
D
0.656
0.875
1.125
H
0.438 to 1.781
0.540 to 4.062
0.600 to 2.810
Note
• For insulated parts, add 0.015" [0.38] to the diameter. The insulation shall lap over the ends of the capacitor body.
Revision: 07-Feb-14
Document Number: 42077
1
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
XTH, XTK, XTL, XTM, XTV
www.vishay.com
Vishay
SIZE
MAX.
RIPPLE
120 Hz
APPROX.
RMS
D
H
WEIGHT
-55 °C +0.031 +0.062
TO
-0.015 -0.062
+175 °C
(g)
14
15
14
15
48
50
60
82
14
15
26
32
48
50
68
82
14
15
26
32
14
15
26
32
48
50
68
82
14
15
26
(mA)
137
213
137
213
550
550
694
694
137
213
328
390
550
550
694
694
137
213
328
390
137
213
333
375
427
550
694
694
137
213
333
0.656 0.438 XTK706(1)008P0A
0.656 0.562 XTM147(1)008P0A
0.656 0.438 XTK506(1)010P0A
0.656 0.562 XTM107(1)010P0A
1.125 0.600 XTV587(1)012P0A
1.125 0.600 XTV857(1)012P0A
1.125 1.100 XTV118(1)012P0A
1.125 1.100 XTV228(1)012P0A
0.656 0.438 XTK356(1)018P0A
0.656 0.562 XTM706(1)018P0A
0.875 0.540 XTL127(1)018P0A
0.875 0.732 XTH247(1)018P0A
1.125 0.600 XTV397(1)018P0A
1.125 0.600 XTV567(1)018P0A
1.125 1.100 XTV907(1)018P0A
1.125 1.100 XTV188(1)018P0A
0.656 0.438 XTK286(1)020P0A
0.656 0.562 XTM566(1)020P0A
0.875 0.540 XTL107(1)020P0A
0.875 0.732 XTH207(1)020P0A
0.656 0.438 XTK206(1)030P0A
0.656 0.562 XTM406(1)030P0A
0.875 0.540 XTL756(1)030P0A
0.875 0.732 XTH157(1)030P0A
1.125 0.600 XTV257(1)030P0A
1.125 0.600 XTV377(1)030P0A
1.125 1.100 XTV657(1)030P0A
1.125 1.100 XTV138(1)030P0A
0.656 0.438 XTK206(1)035P0A
0.656 0.562 XTM406(1)035P0A
0.875 0.540 XTL606(1)035P0A
