Spezifikation für Freigabe / specification for release
Kunde / customer
:
Artikelnummer / part number
:
Bezeichnung :
description :
74489440018
SPEICHERDROSSEL WE-TDC 8038
COUPLED INDUCTOR WE-TDC 8038
DATUM / DATE : 2010-08-31
A
Mechanische Abmessungen / dimensions:
A
C
E
D
F
1
Marking
B
4
3
2
8038
A
B
C
D
E
F
1
Start
3
8,0 ± 0,3
8,0 ± 0,3
3,8 ± 0,3
3,2 typ.
2,4 typ.
1,0 typ.
4
Finish
2
L2
L1
mm
mm
mm
mm
mm
mm
start of winding
B
Elektrische Eigenschaften / electrical properties:
Eigenschaften / properties
Induktivität (je Wicklg.) /
inductance (each wdg.)
DC-Widerstand (je Wicklg.) /
DC-resistance (each wdg.)
DC-Widerstand (je Wicklg.) /
DC-resistance (each wdg.)
Nennstrom (je Wicklg.)
(1)
/
rated Current (each wdg.)
(1)
Sättigungsstrom (je Wicklg.) /
saturation current (each wdg.)
Eigenres.-Frequenz /
self-res.-fequency
Nennspannung /
rated Voltage
(1)
C
Lötpad / soldering spec.:
Wert / value
Einheit / unit
tol.
+/-30%
typ.
max.
typ.
typ.
typ.
max.
2
3
1,4
1
4
6,2
3,6
Testbedingungen /
test conditions
100 kHz / 5mA
@ 20°
C
@ 20°
C
∆
T = 40 K
∆
L/L < 10%
[mm]
L
1,
L
2
R
DC1,2 typ
R
DC1,2 max
I
N1,
I
N2
I
sat
SRF
U
DC
1,8
25,5
31
2,85
5,8
60
80
µH
mΩ
mΩ
A
A
MHz
V
Stromfluss durch beide Wicklungen verursacht
∆T
/
both windings driven by rated current will occur
∆T
D
Prüfgeräte / test equipment:
WAYNE KERR 3260B
für/for L
0
; I
SAT
Agilent N5776A
für/for I
DC;
GMC Metrahit 27I
für/for R
DC
Agilent E4991A
für/for SRF
E
Testbedingungen / test conditions:
Luftfeuchtigkeit / humidity:
Umgebungstemperatur / temperature:
33%
+20°
C
F
Werkstoffe & Zulassungen / material & approvals:
Basismaterial / base material:
Draht / wire:
Endoberfläche / finishing electrode:
Ferrit/ ferrite
Class H
Ag/Ni/Sn
G
Eigenschaften / general specifications:
Betriebstemp. / operating temperature: -40° - +125°
C
C
Umgebungstemp. / ambient temperature: -40° - +85°
C
C
It is recommended that the temperature of the part does
not exceed 125° under worst case operating conditions.
C
Freigabe erteilt / general release:
Kunde / customer
..................................................................................
..................................................................................
Datum / date
Unterschrift / signature
Würth Elektronik
............................................
ALa
Name
Version 1
Änderung / modification
10-08-31
...............................................
Geprüft / checked
Kontrolliert / approved
Datum / date
Würth Elektronik eiSos GmbH & Co. KG
D-74638 Waldenburg · Max-Eyth-Strasse 1 · Germany · Telefon (+49) (0) 7942 - 945 - 0 · Telefax (+49) (0) 7942 - 945 - 400
http://www.we-online.de
SEITE 1 VON 3
Spezifikation für Freigabe / specification for release
Kunde / customer
:
Artikelnummer / part number
:
Bezeichnung :
description :
74489440018
SPEICHERDROSSEL WE-TDC 8038
COUPLED INDUCTOR WE-TDC 8038
DATUM / DATE : 2010-08-31
H
Induktivitätskurve / Inductance curve:
Induktivität vs Strom (typ.)/
Inductance vs Current (typ.)
2,00
1,80
1,60
1,40
1,20
L (µH)
1,00
0,80
0,60
0,40
0,20
0,00
0,00
2,00
4,00
6,00
8,00
10,00
12,00
14,00
Current (A)
Freigabe erteilt / general release:
Kunde / customer
..................................................................................
..................................................................................
Datum / date
Unterschrift / signature
Würth Elektronik
............................................
ALa
Name
Version 1
Änderung / modification
10-08-31
...............................................
Geprüft / checked
Kontrolliert / approved
Datum / date
Würth Elektronik eiSos GmbH & Co. KG
D-74638 Waldenburg · Max-Eyth-Strasse 1 · Germany · Telefon (+49) (0) 7942 - 945 - 0 · Telefax (+49) (0) 7942 - 945 - 400
http://www.we-online.de
SEITE 2 VON 3
Spezifikation für Freigabe / specification for release
Kunde / customer
:
Artikelnummer / part number
:
Bezeichnung :
description :
74489440018
SPEICHERDROSSEL WE-TDC 8038
COUPLED INDUCTOR WE-TDC 8038
DATUM / DATE : 2010-08-31
I
Rollenspezifikation / tape and reel specification:
øC
D
E
F
Gurtspezifikation / Tape specification:
A
XXX
XXX
B
A
G
I
H
End
A
B
C
D
E
F
G
H
I
8,4
16,0
1,5
4,0
2,0
7,5
12,0
4,1
0,4
± 0,1
± 0,3
+ 0,1
± 0,1
± 0,1
± 0,1
± 0,1
± 0,1
± 0,05
mm
mm
mm
mm
mm
mm
mm
mm
mm
Start
no component /
160 mm min.
components
no components /
100 mm min.
400 mm min.
cover tape
feeding direction
a
b
d
Rollenspezifikation / Reel specification:
a
178,0 ± 2,0
b
21,00 ± 0,8
c
13,00 ± 0,5
d
50,00 ± 1,0
mm
mm
mm
mm
Øc
Freigabe erteilt / general release:
Kunde / customer
..................................................................................
..................................................................................
Datum / date
Unterschrift / signature
Würth Elektronik
............................................
ALa
Name
Version 1
Änderung / modification
10-08-31
...............................................
Geprüft / checked
Kontrolliert / approved
Datum / date
This electronic component has been designed and developed for usage in general electronic equipment. Before incorporating this component into any equipment where higher safety and reliability is especially required or if there
is the possibility of direct damage or injury to human body, for example in the range of aerospace, aviation, nuclear control, submarine, transportation, (automotive control, train control, ship control), transportation signal, disaster
prevention, medical, public information network etc, Würth Elektronik eiSos GmbH must be informed before the design-in stage. In addition, sufficient reliability evaluation checks for safety must be performed on every electronic
component which is used in electrical circuits that require high safety and reliability functions or performance.
Würth Elektronik eiSos GmbH & Co. KG
D-74638 Waldenburg · Max-Eyth-Strasse 1 · Germany · Telefon (+49) (0) 7942 - 945 - 0 · Telefax (+49) (0) 7942 - 945 - 400
http://www.we-online.de
SEITE 3 VON 3
