Ribbon-Lead Inductors
R*
Actual Size
Military Specifications
MS21367 (LT10K)
Physical Parameters
Inches
A
0.065 Max.
B
0.100 ± 0.010
C
0.100 ± 0.010
D
0.210 Min.
E
0.012 ± 0.002 (Typ.)
F
0.095 ± 0.015
G
0.002 +0.001-0.000
Weight Max.
(Grams) 0.03
Current Rating at 90°C Ambient
15°C Rise
Operating Temperature Range
–55°C to +105°C
Maximum Power Dissipation at 90°C
0.0205 Watts
Notes 1)
L, Q and SRF measured on Boonton Q and RX
meters using special test fixtures. Details for fixtures
available.
2)
Part number and quantity will appear on
package as units are too small for legible marking.
Core Material
Iron (LT10K)
Mechanical Configuration 1)
Units are epoxy
encapsulated.
2)
Leads are tin/lead plated Beryllium
Copper
3)
Gold Plated leads available on special order.
4)
RoHS compliant part available by ordering 100R Series.
Packaging
Bulk only
Made In the U.S.A.
-150N
-220N
-330N
-470N
-680N
-101N
-121M
-151M
-181M
-221M
-271M
-331M
-391M
-471M
-561M
-681M
-821M
-102M
-122K
-152K
-182K
-222K
-272K
-332K
-392K
-472K
-562K
-682K
-822K
-103K
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
MS21367 - SERIES
0.015
±30%
0.022
±30%
0.033
±30%
0.047
±30%
0.068
±30%
0.100
±30%
0.12
±20%
0.15
±20%
0.18
±20%
0.22
±20%
0.27
±20%
0.33
±20%
0.39
±20%
0.47
±20%
0.56
±20%
0.68
±20%
0.82
±20%
1.00
±20%
1.20
±10%
1.50
±10%
1.80
±10%
2.20
±10%
2.70
±10%
3.30
±10%
3.90
±10%
4.70
±10%
5.60
±10%
6.80
±10%
8.20
±10%
10.0
±10%
100 IRON CORE (LT10K)
40
50.0
250
0.065
40
50.0
250
0.090
40
50.0
250
0.115
40
50.0
250
0.120
40
50.0
250
0.150
40
50.0
250
0.170
35
25.0
250
0.140
40
25.0
250
0.160
40
25.0
250
0.190
40
25.0
250
0.21
40
25.0
250
0.24
40
25.0
250
0.25
40
25.0
200
0.28
40
25.0
175
0.31
40
25.0
170
0.45
40
25.0
165
0.62
35
25.0
160
0.65
35
25.0
135
0.73
35
7.9
120
1.00
32
7.9
110
1.20
32
7.9
95
1.50
35
7.9
80
1.70
35
7.9
70
2.00
37
7.9
65
2.20
37
7.9
60
2.80
40
7.9
55
3.10
40
7.9
50
3.30
40
7.9
45
3.80
40
7.9
43
5.00
40
7.9
40
5.60
492
418
370
360
324
304
335
313
287
274
256
251
237
225
185
159
155
145
125
114
102
96
89
84
75
71
69
64
56
53
Millimeters
1.65 Max.
2.54 ± 0.254
2.54 ±0 .254
5.33 Min.
0.30 ± 0.05
2.41 ± 0.381
0.05 +0.025-0.000
Parts listed above are QPL/MIL qualified
Optional Tolerances: J = 5% H = 3% G = 2% F = 1%
*Complete part # must include series # PLUS the dash #
For surface finish information, refer to www.delevanfinishes.com
