158X Series
Type X2 Suppressor Capacitors
Metallized Polyester / Radial Leads
•
Radial Leads
in Two Lengths
•
UL and CSA Approved
•
Flame Retardant Case
Meets UL94V-0
•
Potting End Fill
Meets UL94V-0
•
Used in applications where
damage to the capacitor will
not lead to the danger of
electrical shock
•
Lead Material
Tinned Copper Clad Steel
GENERAL
SPECIFICATIONS
.
Operating Temperature:
-40 °C to +100 °C
Voltage Range:
275/250 VAC, 60 Hz
Capacitance Range:
0.01 µF to 2.2 µF
Capacitance Tolerance:
±20% (Standard)
±10% (Special)
Dissipation Factor (DF)
tg
δ
0.01 Max at 1,000 ± 100kHz
Insulation Resistance (IR)
(@ 500 VDC and 20 °C)
Terminal to Terminal:
≤0.33µF
15,000 MΩ min
≥0.47µF
5,000 MΩ x µF min
Both Terminals to Body:
100,000 MΩ min
Maximum Pulse Rise Time
µF
.010
.022
.033
.047
.068
.100
V/µs
2800
2400
2400
2000
2000
1600
µF
0.22
0.47
0.68
1.00
1.50
2.20
V/µs
1200
1000
1000
800
800
600
International Approvals
Safety Agency
UL
UL
CSA
VDE
SEMKO
FIMKO
DEMKO
NEMKO
Standard
UL-60384-14
UL-60384-14
C22 2, No. 1-98/No.8 (250VAC)
IEC384-14 II
EN 132400
IEC384-14 II
EN 132400
IEC384-14 II
EN 132400
IEC384-14 II
EN 132400
IEC384-14 II
EN 132400
File Number
E171988
E223166
1572961
109365
9817262
11141
9817262
P98101124
Outline Dimensions
Ratings
Inches
Catalog
Part Number
158X103
158X123
158X153
158X183
158X223
158X273
158X333
158X393
158X473
158X563
158X683
158X823
158X104
158X124
158X154
158X184
158X224
158X274
158X334
158X394
158X474
158X564
158X684
158X824
158X105
158X125
158X155
158X185
158X225
Cap
(µF)
0.010
0.012
0.015
0.018
0.022
0.027
0.033
0.039
0.047
0.056
0.068
0.082
0.100
0.120
0.150
0.180
0.220
0.270
0.330
0.390
0.470
0.560
0.680
0.820
1.000
1.200
1.500
1.800
2.200
L
Length
0.669
0.669
0.669
0.669
0.669
0.669
0.669
0.669
0.669
0.669
0.669
0.669
0.669
0.984
0.984
0.984
0.984
1.181
0.984
1.181
1.181
1.181
1.181
1.201
1.201
1.614
1.614
1.614
1.614
T
Thickness
0.197
0.197
0.197
0.197
0.197
0.197
0.197
0.217
0.217
0.256
0.256
0.256
0.315
0.256
0.256
0.315
0.315
0.354
0.394
0.433
0.433
0.531
0.531
0.630
0.630
0.610
0.610
0.689
0.689
H
Height
0.472
0.472
0.472
0.472
0.472
0.472
0.472
0.492
0.492
0.531
0.531
0.591
0.591
0.630
0.630
0.689
0.689
0.669
0.768
0.866
0.866
0.965
0.965
1.102
1.102
1.102
1.102
1.280
1.280
S
Spacing
0.591
0.591
0.591
0.591
0.591
0.591
0.591
0.591
0.591
0.591
0.591
0.591
0.591
0.886
0.886
0.886
0.886
1.083
0.886
1.083
1.083
1.083
1.083
1.083
1.083
1.476
1.476
1.476
1.476
Ød
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.031
0.031
0.031
0.031
0.031
0.031
0.031
0.031
0.031
0.031
0.031
0.031
0.031
0.031
0.031
0.031
0.039
0.039
0.039
0.039
0.039
0.039
L
Length
17.0
17.0
17.0
17.0
17.0
17.0
17.0
17.0
17.0
17.0
17.0
17.0
17.0
25.0
25.0
25.0
25.0
30.0
25.0
30.0
30.0
30.0
30.0
30.5
30.5
41.0
41.0
41.0
41.0
T
Thickness
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.5
5.5
6.5
6.5
6.5
8.0
6.5
6.5
8.0
8.0
9.0
10.0
11.0
11.0
13.5
13.5
16.0
16.0
15.5
15.5
17.5
17.5
Complies with the EU Directive 2002/95/
EC requirement restricting the use of
Lead (Pb), Mercury (Hg), Cadmium
(Cd), Hexavalent chromium (Cr(VI)),
PolyBrominated Biphenyls (PBB) and
PolyBrominated Diphenyl Ethers (PBDE).
Millimeters
H
Height
12.0
12.0
12.0
12.0
12.0
12.0
12.0
12.5
12.5
13.5
13.5
15.0
15.0
16.0
16.0
17.5
17.5
17.0
19.5
22.0
22.0
24.5
24.5
28.0
28.0
28.0
28.0
32.5
32.5
S
Spacing
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
22.5
22.5
22.5
22.5
27.5
22.5
27.5
27.5
27.5
27.5
27.5
27.5
37.5
37.5
37.5
37.5
Ød
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
1.0
1.0
1.0
1.0
1.0
1.0
NOTE: If ±10% tolerance is required, add 'K' to end of Catalog Number
NOTE: Parts are normally supplied with leads 30mm minimum
To order short leads, 3.5mm minimum length, add 'S' to end of Catalog Part Number.
CDE Cornell Dubilier
•
1605 E. Rodney French Blvd.
•
New Bedford, MA 02744
•
Phone: (508)996-8561
•
Fax: (508)996-3830
•
www.cde.com
158X Series
Type X2 Suppressor Capacitors
