LARGE ALUMINUM ELECTROLYTIC CAPACITORS
GF
Screw Terminal Type, Long Life
Series
Screw terminal series in more compact case sizes
High reliability, long life guaranteed for 5000 hours load life at 85 C
The only 500WV is assured 2000 hours at 85 C)
Ideally suited for use in industrial robots, tooling machines, inverters,
telecommunication equipment, measuring instruments and etc.
Item
Operating temperature range
Capacitance tolerance
Leakage current max.
Dissipation factor
Low temperature characteristics
(Impedance ratio at 120Hz)
Load life
(after application of the rated
voltage for 5000 hours at 85 C)
Shelf life (at 85 C)
-25 ~ +85 C
20% at 120Hz, 20 C
I=3 CV ( A) (after 5 minutes)
0.20 max. at 120Hz, 20 C
Z-25 C / Z+20 C
8
Less than specified value
Within 20% of initial value
Less than 200% of specified value
Characteristics
Leakage current
Capacitance change
tan
500WV products are for 2000 hours.
After 1000 hours no load test, leakage current, capacitance and tan are same as load life value.
DRAWING
Bottom plate
Insulating sleeve
Unit : mm
D 2 max.
P 1
Safety vent
L 3 max.
6.0
1
M5 Hexagon head bolt
TWO LEGS ANGLE
THREE LEGS ANGLE
120
T
3.5
U
4.5
B
A 1
A
B
1
T
U
TWO LEGS ANGLE SIZE TABLE
D
51
63.5
B
33.6
40.8
A
39.9
46.8
T
6
6
U
14
14
30
30
P
22
28.6
THREE LEGS ANGLE SIZE TABLE
D
51
63.5
76.2
89
B
32.9
38.4
44.5
50.8
A
38.9
45.3
51.5
61
T
7
7
8
8
U
12
14
16
16
60
60
60
60
P
22
28.6
31.8
31.8
LARGE ALUMINUM ELECTROLYTIC CAPACITORS
GF
series
DIMENSIONS & MAXIMUM PERMISSIBLE RIPPLE CURRENT
WV
350
F
1000
51
120
4.2
400
450
500
1200
63.5
100
4.5
1500
63.5
100
5.1
1800
51
110
6.0
51
130
6.4
63.5
110
6.4
63.5
120
6.0
2200
63.5
140
7.0
2700
51
130
7.1
63.5
110
7.1
63.5
130
7.5
76.2
120
7.5
3300
63.5
100
7.5
63.5
130
8.3
76.2
110
8.0
76.2
140
8.8
3900
63.5
100
8.2
76.2
100
8.4
76.2
130
9.3
4700
76.2
100
9.3
76.2
130
10.2
76.2
150
10.8
5600
76.2
110
10.5
76.2
150
11.8
76.2
160
12.1
6800
76.2
130
12.3
76.2
160
13.4
89
150
14.3
8200
76.2
160
14.7
89
150
15.7
89
160
16.1
10000
89
150
17.3
89
160
17.8
Ripple current (A rms) at 85 C, 120Hz
Case size
D
L (mm)
12000
89
160
19.5
PERMISSIBLE RIPPLE CURRENT MULTIPLIERS
Frequency
Coefficient
50Hz
0.8
120Hz
1.0
300Hz
1.1
1kHz
1.3
3kHz
1.4
