Type 330
–55 °C to 105 °C Ultra-Long-Life, Switching Power Grade Radial
High Ripple and Ultra-Long Life
The Type 330 is the ultra-long-life version of the Type 300 capacitor.
With an astonishing, 50,000-hour expected life operating
continuously at full load and 65 ºC the 330 is the choice for power
supply outputs and UPS battery stiffening. The exceptionally low
ESRs enable high ripple-current capability. With series inductance
of 12 to 16 nH and ripple currents to 16 amps one of these
capacitors can save by replacing three or four of the 12.5 mm
diameter capacitors routinely at the output of switching power
supplies. Type 330 R delivers even lower ESR and higher ripple.
Type 330 has three leads for rugged, reverse-proof mounting. Two
leads are available as Types 331 and 331R.
Highlights
Specifications
Operating Temperature:
Rated Voltage:
Capacitance:
Capacitance Tolerance:
Leakage Current:
Cold Impedance:
Ripple Current Multipliers:
• Expected Life > 20 years @ 45 °C
• Ripple Current to 16 amps
• ESRs to 6
mΩ
• > 90% capacitance at –40 °C
• Replaces multiple capacitors
–55 °C to +105 °C
6.3 to 250 Vdc
270 µF to 33,000 µF
6.3 to 100 Vdc; –10 + 75%, 160 to 250 Vdc; –10 + 50%
≤ 0.5 √CV µA, 4 mA max, 5 min.
–55 °C multiple of 25 °C Z ≤ 4 for 6.3 & 7.5 V, 3 for 10 to 50 V,
2 for > 50 V
Ambient Temperature
45 °C
1.66
55 °C
1.52
65 °C
1.37
75 °C
1.20
85 °C
1.00
95 °C
0.75
105 °C
0.36
Frequency
50 Hz 60 Hz 120 Hz
.77” Diameter
6.3 & 7.5 V
10 to 40 V
50V
63 & 75 V
100 to 250 V
.895” Diameter
6.3 & 7.5 V
10 to 40 V
50V
63 & 75 V
100 to 250 V
1.02” Diameter
6.3 & 7.5 V
10 to 40 V
50V
63 & 75 V
100 to 250 V
0.84
0.81
0.76
0.77
0.76
0.88
0.86
0.81
0.81
0.81
1.00
1.00
1.00
1.00
1.00
1.12
1.15
1.23
1.23
1.24
1.17
1.22
1.35
1.35
1.37
1.19
1.25
1.42
1.42
1.44
1.20
1.26
1.44
1.44
1.46
0.82
0.80
0.75
0.75
0.76
0.86
0.84
0.80
0.80
0.81
1.00
1.00
1.00
1.00
1.00
1.14
1.17
1.27
1.26
1.25
1.20
1.25
1.42
1.40
1.38
1.23
1.29
1.50
1.48
1.46
1.24
1.30
1.52
1.50
1.48
0.82
0.78
0.76
0.74
0.76
0.86
0.83
0.81
0.80
0.81
1.00
1.00
1.00
1.00
1.00
1.15
1.20
1.25
1.28
1.24
1.21
1.30
1.38
1.43
1.37
1.24
1.35
1.45
1.52
1.44
1.25
1.36
1.47
1.54
1.46
360 Hz 1 kHz 5 kHz 10 kHz & up
Complies with the EU Directive
2002/95/EC requirement
restricting the use of Lead (Pb),
Mercury (Hg), Cadmium (Cd),
Hexavalent chromium (Cr(VI)),
PolyBrominated Biphenyls
(PBB) and PolyBrominated
Diphenyl Ethers (PBDE).
Load Life:
Shelf Life:
10,000 h at full load at 85 °C
∆ Capacitance ±20%
ESR 200% of limit
DCL 100% of limit
500 h at 105 °C, capacitance, ESR and DCL, initial requirements
