Aluminum Electrolytic Capacitors
SEA Series
Features
‧85℃,
2,000 hours assured, standard miniature type with
7 ~ 9mm height for compact circuits
‧RoHS
Compliance
Specifications
Items
Category Temperature Range
Capacitance Tolerance
Leakage Current (at 20℃)
Performance
-40℃ ~ +85℃
±20%
I = 0.01CV or 3 (μA) whichever is greater (after 2 minutes)
Where, C = rated capacitance in
μF
V = rated DC working voltage in V
Rated Voltage
Tanδ (max)
4
0.35
6.3
0.23
10
0.20
16
0.16
25
0.14
35
0.12
50
0.10
63
0.10
SEA
Sleeve & Marking Color: Blue & Black
(at 120Hz, 20℃)
Tanδ (at 120Hz, 20℃)
Low Temperature
Characteristics (at 120Hz)
Impedance ratio shall not exceed the values given in the table below.
Rated Voltage
4
6.3
10
16
25
35
Z(-25℃)/Z(+20℃)
7
4
3
3
2
2
Impedance
Ratio
Z(-40℃)/Z(+20℃)
14
10
8
6
4
4
50
2
4
63
2
4
Endurance
Shelf Life Test
Test Time
2,000 Hrs
Capacitance Change
Within ±20% of initial value
Tanδ
Less than 200% of specified value
Leakage Current
Within specified value
* The above Specifications shall be satisfied when the capacitors are restored to 20℃ after the rated voltage applied with rated
ripple current for 2,000 hours at 85℃.
Test time: 500 hours; other items are the same as those for the Endurance.
Freq.(Hz)
Cap.(μF)
Under 47
100 to 1,000
60 (50)
0.70
0.80
120
1.00
1.00
500
1.20
1.10
1k
1.30
1.15
10k up
1.45
1.20
Ripple Current &
Frequency Multipliers
Diagram of Dimensions
φ
d
L+
α
max
φ
D+
β
max
Lead Spacing and Diameter
φD
P
φd
4
1.5
0.45
1.0
0.5
5
2.0
6.3
2.5
0.5
8
3.5
10
5.0
0.6
1.5
Unit: mm
P
±
0.5
Sleeve
15 min
4 min
α
β
Dimension & Permissible Ripple Current
V. DC
Dimension:
φD
× L(mm)
Ripple Current: mA/rms at 120 Hz, 85°C
10V (1A)
mA
4V (0G)
6.3V (0J)
16V (1C)
φD×L
mA
25V (1E)
φD×L
mA
35V (1V)
φD×L
mA
50V (1H)
φD×L
4×7
4×7
4×7
5×7*
6.3×7*
6.3×7
8×7*
8×7
8×9
mA
10
15
18
23
34
53
76
85
130
63V (1J)
φD×L
4×7
4×7
4×7
5×7*
6.3×7*
8×7*
8×7
8×7
10×9
mA
11
17
21
26
40
70
80
95
170
mA
mA
φD×L
φD×L
Contents
φD×L
1
010
2.2
2R2
3.3
3R3
4.7
4R7
10
100
22
220
4×7
31
4×7
33
330
4×7
32
4×7
32
4×7
47
470
4×7
38
4×7
38
5×7*
100
101
5×7
61
6.3×7*
75
6.3×7
220
221
6.3×7
90
6.3×7
99
8×7
330
331
8×7
129
8×7
156
8×7
470
471
8×7
154
8×7
175
8×9
1,000
102
8×9
200
10×9
205
Note: Case size in mark of “ * ” is available to product down size.
μF
32
35
47
80
140
165
215
4×7
5×7*
5×7
6.3×7*
6.3×7
8×7
8×9
10×9
25
39
43
59
90
146
185
255
4×7
5×7*
6.3×7
6.3×7
8×7
8×9
10×9
26
41
53
65
125
190
265
4×7
5×7*
6.3×7*
8×7*
8×7*
8×7
10×9
22
30
47
71
83
115
215
Part Numbering System
SEA series
470μF
±20%
6.3V
Bulk Package
Gas Type
8φ×7L
Pb-free and PET
coating case
Lead Wire and
Coating Type
SEA
Series
471
Capacitance
M
Capacitance
Tolerance
0J
Rated
Voltage
BK
-
0807
Case Size
Lead Configuration
Rubber Type
& Package
Note: For more details, please refer to “Part Numbering System (Radial Type)” on page 10.
120
All product specifications in the catalog are subject to change without notice. (CAT. 2014E1)
