PIN
RECEPTACLES
FOR .015” - .025” DIAMETER PINS
8964
8964-0-15-XX-30-XX-04-0
Press-fit in .057 mounting hole
5342
5342-0-15-XX-35-XX-10-0
Solder mount in .051 min. mounting hole
Also available on 8mm wide carrier tape:
6,000 parts per 13” reel.
Order as: 5342-0-57-XX-35-XX-10-0
8857
8857-X-15-XX-32-XX-04-0
Press-fit in .057 mounting hole
Basic Part
Number
Length
A
8857-0
8857-1
8857-2
8857-3
8857-4
.311
.448
.589
.731
.871
8862/8877
88XX-0-15-XX-30-XX-04-0
Press-fit in .056 mounting hole
1334
1334-0-15-XX-30-XX-04-0
Press-fit in .057 mounting hole
8855
8855-0-15-XX-30-XX-04-0
Press-fit in .057 mounting hole
.071 DIA.
.059 DIA.
.053 DIA.
Basic Part
Number
Length
A
.031
.028 .100
.161 .167
8862-0
8877-0
.300
.350
.020 DIA.
.144
2954
.072 DIA.
.058 DIA.
2954-0-18-XX-30-XX-10-0
Press-fit in .057 mounting hole
Accepts wire sizes up to .028” Dia.
.031
.100
.150
.053 DIA.
.290
9363
9363-0-15-XX-35-XX-10-0
Solder mount in .057 min. mounting hole
1023
1023-0-15-XX-30-XX-04-0
Press-fit in .061 mounting hole
1701
1701-0-15-XX-30-XX-10-0
Press-fit in .057 mounting hole
.060
.038 DIA.
HOLE
.090
SPECIFICATIONS:
Shell Material:
Brass Alloy 360, 1/2 Hard
Contact Material:
Beryllium Copper Alloy 172, HT
Dimension in Inches:
Tolerances On:
Lengths:
± .005
RoHS - 2
2011/65/EU
ORDER CODE: XXXX - X - 1X - XX -
XX
- XX - 10 - 0
BASIC PART #
SPECIFY SHELL FINISH:
01
200
”
TIN/LEAD OVER NICKEL
80
200
”
TIN OVER NICKEL (RoHS)
15
10
”
GOLD OVER NICKEL (RoHS)
SPECIFY CONTACT FINISH:
02
100
”
TIN/LEAD OVER NICKEL
84
100
”
TIN OVER NICKEL (RoHS)
27
30
”
GOLD OVER NICKEL (RoHS)
Diameters: ± .002
Angles:
±2°
SELECT CONTACT:
#30, #32 or #35
CONTACT (DATA ON PAGE 253 & 254)
(Contact specified above may be interchanged with any group B or C contact on page 248)
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
PAGE 171 | PIN RECEPTACLES
