FKP3J022204J00JJ

Description
Film Capacitor, Polypropylene, 630V, 5% +Tol, 5% -Tol, -200ppm/Cel TC, 0.022uF, 7135,
CategoryPassive components    capacitor
File Size876KB，9 Pages
ManufacturerWIMA
Websitehttps://www.wima.de/
Environmental Compliance
Download Datasheet Parametric View All

FKP3J022204J00JJ Overview

Film Capacitor, Polypropylene, 630V, 5% +Tol, 5% -Tol, -200ppm/Cel TC, 0.022uF, 7135,

FKP3J022204J00JJ Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
Objectid899490487
package instruction, 7135
Reach Compliance Codecompliant
Country Of OriginGermany
ECCN codeEAR99
YTEOL7.2
capacitance0.022 µF
Capacitor typeFILM CAPACITOR
dielectric materialsPOLYPROPYLENE
high16 mm
JESD-609 codee3
length18 mm
negative tolerance5%
Number of terminals2
Maximum operating temperature100 °C
Minimum operating temperature-55 °C
Package formRadial
method of packingTR
positive tolerance5%
Rated (AC) voltage (URac)300 V
Rated (DC) voltage (URdc)630 V
seriesFKP3
size code7135
Temperature Coefficient-200ppm/Cel ppm/°C
Terminal surfaceTin (Sn)
Terminal pitch15 mm
width9 mm

FKP3J022204J00JJ Preview

WIMA FKP 3
Polypropylene (PP) Film and Foil
Capacitors for Pulse Applications
PCM 7.5 mm to 15 mm
Special Features
˜
Pulse duty construction
˜
Very low dissipation factor
˜
Negative capacitance change
versus temperature
˜
Very low dielectric absorption
˜
According to RoHS 2011/65/EC
D
Electrical Data
Capacitance range:
100 pF to 0.22
m
F (E12-values on request)
Rated voltages:
63 VDC, 100 VDC, 250 VDC, 400 VDC,
630 VDC, 1000 VDC
Capacitance tolerances:
±20%, ±10%, ±5%
Operating temperature range:
–55+ C to +100+ C
Test specifications:
In accordance with IEC 60384-13
Climatic test category:
55/100/56 in accordance with IEC
Insulation resistance
at +20+ C:
5 x 10
5
M¸
(mean value: 1 x 10
6
M¸)
Measuring voltage:
U
r
= 63 V: U
test
= 50 V/1 min.
U
r
100 V: U
test
= 100 V/1 min.
Test voltage:
2 U
r
, 2 sec.
Maximum pulse rise time:
1000 V/
m
sec for pulses equal to the
rated voltage
Dielectric absorption:
0.05 %
Temperature coefficient:
–200 x 10
-6
/+ C (general guide)
Dissipation factors
at +20+ C: tan
d
at f
C0.1
mF
0.1
mF
P
C
0.22
mF
3 x 10
-4
6 x 10
-4
–
Typical Applications
For high frequency applications e.g.
˜
Sample and hold
˜
Timing
˜
LC-Filtering
˜
Oscillating circuits
˜
Audio equipment
1 kHz
4 x 10
-4
10 kHz
5 x 10
-4
100 kHz
10
x 10
-4
Construction
Dielectric:
Polypropylene (PP) film
Capacitor electrodes:
Metal foil
Internal construction:
Voltage derating:
A voltage derating factor of 1.35 % per K
must be applied from +85+ C for DC
voltages and from +75+ C for AC
voltages.
Reliability:
Operational life 300 000 hours
Failure rateP 5 fit (0.5 x U
r
and 40+ C)
Plastic film
Metal foil electrode
Terminating wire
Mechanical Tests
Pull test on pins:
10 N in direction of pins according to
IEC 60068-2-21
Vibration:
6 hours at 10 ... 2000 Hz and 0.75 mm
displacement amplitude or 10 g in
accordance with IEC 60068-2-6
Low air density:
1kPa = 10 mbar in accordance with
IEC 60068-2-13
Bump test:
4000 bumps at 390 m/sec
2
in
accordance with IEC 60068-2-29
Packing
Available taped and reeled.
Detailed taping information and graphs
at the end of the catalogue.
Encapsulation:
Solvent-resistant, flame-retardant plastic
case with epoxy resin seal, UL 94 V-0
Terminations:
Tinned wire.
Marking:
Colour: Red. Marking: Black.
Epoxy resin seal: Yellow
For further details and graphs please
refer to Technical Information.
42
11.12
WIMA FKP 3
Continuation
D
General Data
Capacitance
100
150
220
330
470
680
1000
1500
2200
3300
4700
6800
0.01
0.015
0.022
0.033
0.047
0.068
pF
„
„
„
„
„
pF
„
„
„
„
„
mF
„
„
„
„
„
4
4
4
5
6
6
8
9
9
9.5
9.5
11
12
12.5
15
16
10
13
13
13
13
18
18
18
7.5
10
10
10
10
15
15
15
FKP3C021502C00_ _ _ _
FKP3C022203D00_ _ _ _
FKP3C023303D00_ _ _ _
FKP3C024703F00_ _ _ _
FKP3C026803G00_ _ _ _
FKP3C031004C00_ _ _ _
FKP3C031504F00_ _ _ _
FKP3C032204J00_ _ _ _
W
H
63 VDC/40 VAC*
L
PCM**
Part number
W
3
3
3
3
3
3
3
3
3
3
3
4
4
4
5
6
5
6
7
9
H
8.5
8.5
8.5
8.5
8.5
8.5
8.5
8.5
8.5
8.5
8.5
9
9
9.5
11
12
11
12.5
14
16
100 VDC/63 VAC*
L PCM**
Part number
10
10
10
10
10
10
10
10
10
10
10
10
10
13
13
13
18
18
18
18
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
10
10
10
15
15
15
15
FKP3D001002B00_ _ _ _
FKP3D001502B00_ _ _ _
FKP3D002202B00_ _ _ _
FKP3D003302B00_ _ _ _
FKP3D004702B00_ _ _ _
FKP3D006802B00_ _ _ _
FKP3D011002B00_ _ _ _
FKP3D011502B00_ _ _ _
FKP3D012202B00_ _ _ _
FKP3D013302B00_ _ _ _
FKP3D014702B00_ _ _ _
FKP3D016802C00_ _ _ _
FKP3D021002C00_ _ _ _
FKP3D021503D00_ _ _ _
FKP3D022203F00_ _ _ _
FKP3D023303G00_ _ _ _
FKP3D024704B00_ _ _ _
FKP3D026804C00_ _ _ _
FKP3D031004D00_ _ _ _
FKP3D031504J00_ _ _ _
0.1
mF
0.15 „
0.22 „
Capacitance
100
150
220
330
470
680
pF
„
„
„
„
„
W
3
3
3
3
3
3
3
3
4
3
4
5
5
6
5
6
7
8
9
H
8.5
8.5
8.5
8.5
8.5
8.5
8.5
8.5
9
9
9.5
11
11
12
11
12.5
14
15
16
250 VDC/160 VAC*
L
PCM**
Part number
10
10
10
10
10
10
10
10
10
13
13
13
13
13
18
18
18
18
18
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
10
10
10
10
10
15
15
15
15
15
FKP3F001002B00_ _ _ _
FKP3F001502B00_ _ _ _
FKP3F002202B00_ _ _ _
FKP3F003302B00_ _ _ _
FKP3F004702B00_ _ _ _
FKP3F006802B00_ _ _ _
FKP3F011002B00_ _ _ _
FKP3F011502B00_ _ _ _
FKP3F012202C00_ _ _ _
FKP3F013303A00_ _ _ _
FKP3F014703D00_ _ _ _
FKP3F016803F00_ _ _ _
FKP3F021003F00_ _ _ _
FKP3F021503G00_ _ _ _
FKP3F021504B00_ _ _ _
FKP3F022204C00_ _ _ _
FKP3F023304D00_ _ _ _
FKP3F024704F00_ _ _ _
FKP3F026804J00_ _ _ _
W
3
3
3
3
3
3
3
4
4
4
4
5
6
5
6
7
8
9
H
8.5
8.5
8.5
8.5
8.5
8.5
8.5
9
9
9.5
9.5
11
12
11
12.5
14
15
16
400 VDC/250 VAC*
L PCM**
Part number
10
10
10
10
10
10
10
10
10
13
13
13
13
18
18
18
18
18
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
10
10
10
10
15
15
15
15
15
FKP3G001002B00_ _ _ _
FKP3G001502B00_ _ _ _
FKP3G002202B00_ _ _ _
FKP3G003302B00_ _ _ _
FKP3G004702B00_ _ _ _
FKP3G006802B00_ _ _ _
FKP3G011002B00_ _ _ _
FKP3G011502C00_ _ _ _
FKP3G012202C00_ _ _ _
FKP3G012203D00_ _ _ _
FKP3G013303D00_ _ _ _
FKP3G014703F00_ _ _ _
FKP3G016803G00_ _ _ _
FKP3G021004B00_ _ _ _
FKP3G021504C00_ _ _ _
FKP3G022204D00_ _ _ _
FKP3G023304F00_ _ _ _
FKP3G024704J00_ _ _ _
1000 pF
1500 „
2200 „
3300 „
4700 „
6800 „
0.01
mF
0.015 „
0.022
0.033
0.047
0.068
„
„
„
„
* AC voltage: f
1000 Hz; 1.4 x U
rms
+ UDC
U
r
** PCM = Printed circuit module = pin spacing
Dims. in mm.
Part number completion:
Tolerance:
Packing:
Pin length:
20 % = M
10 % = K
5%=J
bulk = S
6-2 = SD
11.12
Taped version see page 148.
Rights reserved to amend design data without prior notification.
Continuation page 44
43
WIMA FKP 3
Continuation
D
General Data
Capacitance
100
150
220
330
470
680
1000
1500
2200
3300
4700
6800
0.01
0.015
0.022
0.033
pF
„
„
„
„
„
pF
„
„
„
„
„
mF
„
„
„
W
3
3
3
3
3
3
4
4
4
5
6
5
6
8
9
9
H
8.5
8.5
8.5
8.5
8.5
8.5
9
9.5
9.5
11
12
11
12.5
15
16
16
630 VDC/300 VAC*
L
PCM**
Part number
10
10
10
10
10
10
10
13
13
13
13
18
18
18
18
18
7.5
7.5
7.5
7.5
7.5
7.5
7.5
10
10
10
10
15
15
15
15
15
FKP3J001002B00_ _ _ _
FKP3J001502B00_ _ _ _
FKP3J002202B00_ _ _ _
FKP3J003302B00_ _ _ _
FKP3J004702B00_ _ _ _
FKP3J006802B00_ _ _ _
FKP3J011002C00_ _ _ _
FKP3J011503D00_ _ _ _
FKP3J012203D00_ _ _ _
FKP3J013303F00_ _ _ _
FKP3J014703G00_ _ _ _
FKP3J016804B00_ _ _ _
FKP3J021004C00_ _ _ _
FKP3J021504F00_ _ _ _
FKP3J022204J00_ _ _ _
FKP3J023304J00_ _ _ _
W
3
3
3
3
3
3
4
4
4
5
6
5
6
8
9
H
8.5
8.5
8.5
8.5
8.5
8.5
9
9.5
9.5
11
12
11
12.5
15
16
1000 VDC/300 VAC*
L PCM**
Part number
10
10
10
10
10
10
10
13
13
13
13
18
18
18
18
7.5
7.5
7.5
7.5
7.5
7.5
7.5
10
10
10
10
15
15
15
15
FKP3O101002B00_ _ _ _
FKP3O101502B00_ _ _ _
FKP3O102202B00_ _ _ _
FKP3O103302B00_ _ _ _
FKP3O104702B00_ _ _ _
FKP3O106802B00_ _ _ _
FKP3O111002C00_ _ _ _
FKP3O111503D00_ _ _ _
FKP3O112203D00_ _ _ _
FKP3O113303F00_ _ _ _
FKP3O114703G00_ _ _ _
FKP3O116804B00_ _ _ _
FKP3O121004C00_ _ _ _
FKP3O121504F00_ _ _ _
FKP3O122204J00_ _ _ _
* AC voltage: f
1000 Hz; 1.4 x U
rms
+ UDC
U
r
** PCM = Printed circuit module = pin spacing
Dims. in mm.
W
H
L
Part number completion:
Tolerance:
Packing:
Pin length:
20 % = M
10 % = K
5%=J
bulk = S
6-2 = SD
d = 0.5
P
if W = 3
PCM 7.5 and 10
d = 0.6
P
if W
4
d = 0.8
P
if PCM = 15
6
-2
d
Taped version see page 148.
PCM
at the pin exit points
(
±
0.4)
Rights reserved to amend design data without prior notification.
U
rms
V
5
2
10
2
63
5
2
10
1
10
4
2
5
0.
1
0.
0.
02
2
µF
47
0.
µF
00
10
00
22
00
0 100
pF p
F
47
0
pF
Permissible AC voltage
in relation to frequency
at 10) C internal temperature rise
(general guide).
100 VDC
µF
15
µF
0.
04
pF
pF
7
01
µF
22
pF
10
5
2
5
10
6
2
5 f 10
7
Hz
44
11.12
D
Recommendation for Processing
and Application of
Through-Hole Capacitors
Soldering Process
A preheating of through-hole WIMA
capacitors is allowed for temperatures
T
max
P
100 ° C.
In practice a preheating duration of
t
P
5 min. has been proven to be best.
Single wave soldering
Soldering bath temperature: T
P
260 ° C
Immersion time:
t
P
5 sec
Double wave soldering
Soldering bath temperature: T
P
260 ° C
Immersion time:
2 x t
P
3 sec
Due to different soldering processes and
heat requirements the graphs are to be
regarded as a recommendation only.
Wave soldering
T
260
240
220
200
180
160
140
120
100
80
60
40
20
[°C]
see detail-
enlargement
2s
3s
10 s
t
30
60
90
120
150
180
210
240 [sec]
Typical temperature/time graph for double wave soldering
WIMA Quality and Environmental Philosophy
ISO 9001:2008 Certification
ISO 9001:2008 is an international basic
standard of quality assurance systems for
all branches of industry. The approval
according to ISO 9001:2008 of our
factories by the VDE inspectorate certifies
that organisation, equipment and moni-
toring of quality assurance in our factories
correspond to internationally recognized
standards.
WIMA Environmental Policy
All WIMA capacitors, irrespective of
whether through-hole devices or SMD,
are made of environmentally friendly
materials. Neither during manufacture
nor in the product itself any toxic
substances are used, e.g.
–
–
–
–
–
Lead
PCB
CFC
Hydrocarbon chloride
Chromium 6+
–
–
–
–
–
PBB/PBDE
Arsenic
Cadmium
Mercury
etc.
RoHS Compliance
According to the RoHS Directive 2011/65/EC
certain hazardous substances like e.g. lead,
cadmium, mercury must not be used any
longer in electronic equipment as of July 1st,
2006. For the sake of the environment WIMA
has refraind from using such substances since
years already.
WIMA WPCS
The WIMA Process Control System (WPCS)
is a quality surveillance and optimization
system developed by WIMA. WPCS is a
major part of the quality-oriented WIMA
production. Points of application of WPCS
during production process:
”
incoming material inspection
”
metallization
”
film inspection
”
schoopage
”
pre-healing
”
attachment
pin
”
cast resin preparation/
encapsulation
”
100% final inspection
”
AQL check
We merely use pure, recyclable materials
for packing our components, such as:
”
carton
”
cardboard
”
adhesive tape made of paper
”
polystyrene
We almost completely refrain from using
packing materials such as:
”
foamed polystyrene (Styropor®)
”
adhesive tapes made of plastic
”
metal clips
WIMA Kondensatoren sind bleifrei
konform RoHS 2011/65/EC
WIMA capacitors are lead free
in accordance with RoHS 2011/65/EC
Tape for lead-free WIMA capacitors
DIN EN ISO 14001:2004
WIMA’s environmental management has
been established in accordance with the
guidelines of DIN EN ISO 14001:2004 to
optimize the production processes with
regard to energy and resources.
14
11.12
D
Typical Dimensions for
Taping Configuration
P
2
P
Vh
H
H
1
W
2
P
1
Diagram 1:
PCM 2.5/5/7.5mm
W
0
D
0
F
P
0
P
d
P
W
W
1
H
1
t
P
1
P
1
H
d
F
P
0
P
2
F
P
2
d
P
0
Diagram 2: PCM 10/15 mm
Diagram 3: PCM 22.5 and 27.5*mm
*PCM 27.5 taping possible with two feed holes between components
Dimensions for Radial Taping
Designation
Carrier tape width
Hold-down tape width
Hole position
Hold-down tape position
Feed hole diameter
Pitch of component
Feed hole pitch
Feed hole centre
to pin
Hole centre to
component centre
Feed hole centre to bottom
edge of the component
Feed hole centre to top
edge of the component
Pin spacing at
upper edge of carrier tape
Pin diameter
Component alignment
Total tape thickness
Package
(see also page 149)
Unit
Dims in mm.
„
Symbol
PCM 2.5 taping
W
W
0
W
1
W
2
D
0
P
P
0
P
1
P
2
H
H
1
F
d
Dh
t
18.0
p0.5
6.0
for hot-sealing
adhesive tape
PCM 5 taping
18.0
p0.5
6.0
for hot-sealing
adhesive tape
PCM 7.5 taping
18.0
p0.5
12.0
for hot-sealing
adhesive tape
PCM 10 taping*
18.0
p0.5
12.0
for hot-sealing
adhesive tape
PCM 15 taping*
18.0
p0.5
12.0
for hot-sealing
adhesive tape
PCM 22.5 taping
18.0
p0.5
12.0
for hot-sealing
adhesive tape
PCM 27.5 taping
18.0
p0.5
12.0
for hot-sealing
adhesive tape
9.0
p0.5
0.5 to 3.0 max.
4.0
p0.2
12.7
p1.0
12.7
cumulative pitch
p0.3
error max.
1.0 mm/20 pitch
9.0
p0.5
0.5 to 3.0 max.
4.0
p0.2
12.7
p1.0
12.7
cumulative pitch
p0.3
error max.
1.0 mm/20 pitch
9.0
p0.5
0.5 to 3.0 max.
4.0
p0.2
12.7
p1.0
12.7
cumulative pitch
p0.3
error max.
1.0 mm/20 pitch
9.0
p0.5
0.5 to 3.0 max.
4.0
p0.2
25.4
p1.0
12.7
cumulative pitch
p0.3
error max.
1.0 mm/20 pitch
9.0
p0.5
0.5 to 3.0 max.
4.0
p0.2
25.4
p1.0
12.7
cumulative pitch
p0.3
error max.
1.0 mm/20 pitch
9.0
p0.5
0.5 to 3.0 max.
4.0
p0.2
38.1
p1.5
12.7
p0.3
7.8
p0.7
19.05
p1.3
16.5
p0.5
18.5
p0.5
H+H
component
< H
1
30.0 to 43.0
22.5
p0.8
0.8
–0.05
p
3.0 max.
0.7
p0.2
54
p2
B 60
p2
68
p2
depending
on PCM and
component dimensions
+0,08
cumulative pitch
error max.
1.0 mm/20 pitch
9.0
p0.5
0.5 to 3.0 max.
4.0
p0.2
*
38.1
p1.5
or 50.8
p1.5
12.7
p0.3
5.3
p0.7
19.05
p1.3
16.5
p0.5
18.5
p0.5
H+H
component
< H
1
35.0 to 45.0
27.5
p0.8
0.8
–0.05
p
3.0 max.
0.7
p0.2
+0.08
cumulative pitch
error max.
1.0 mm/20 pitch
5.1
p0.5
6.35
p1.3
16.5
p0.3
18.5
p0.5
H+H
component
< H
1
32.25 max.
2.5
p0.5
0.4
p0.05
p
2.0 max.
0.7
p0.2
3.85
p0.7
6.35
p1.3
16.5
p0.3
18.5
p0.5
H+H
component
< H
1
32.25 max.
5.0
+0.8
–0.2
2.6
p0.7
6.35
p1.3
16.5
p0.5
18.5
p0.5
H+H
component
< H
1
24.5 to 31.5
7.5
p0.8
„
7.7
p0.7
12.7
p1.3
16.5
p0.5
18.5
p0.5
H+H
component
< H
1
25.0 to 31.5
10.0
p0.8
+0.06
„
5.2
p0.7
12.7
p1.3
16.5
p0.5
18.5
p0.5
H+H
component
< H
1
26.0 to 37.0
15
p0.8
+0,06
0.5
p0.05
p
2.0 max.
0.7
p0.2
ROLL/AMMO
0.5
p0.05
or
0.6
–0.05
0.5
p0.05
or
0.6
–0.05
0.8
–0.05
p
3.0 max.
0.7
p0.2
AMMO
+0,08
p
3.0 max.
0.7
p0.2
p
3.0 max.
0.7
p0.2
52
p2
B 58
p2
or
66
p2
REEL
P
360 max.
P
30
p1
B
52
p2
58
p2
depending on
comp. dimensions
REEL
P
360 max.
P
30
p1
REEL
P
500 max.
P
25
p1
see details page 150.
Please clarify customer-specific deviations with the manufacturer.
Diameter of pins see General Data.
148
11.12
*
PCM 10 and PCM 15 can be crimped to PCM 7.5.
Position of components according to PCM 7.5 (sketch 1). P
0
= 12.7 or 15.0 is possible
More (Only the first 5 pages are displayed. Please Download Datasheet to view the full content.) >

Recommended Resources

Control circuit with multiple buttons to start and stop a motor

Thermocouple ISO212P isolation transmitter

High voltage power supply circuit diagram composed of LM317T

Quadrature oscillator circuit diagram

Multiplier circuit composed of multi-function converter 4302

555 voltage/frequency converter counting display circuit

[EEWORLD University TI Classroom] The third phase (May 26-June 1) winners list announced
As of June 1, the netizens who have studied for a long time and have the highest comprehensive scores in after-class exercises, learning tests, and certification tests will be announced. As a token of...
EEWORLD社区 Microcontroller MCU
Help: One of the two Zigbee temperature measurement nodes is always 0
The infinite temperature sensing network I designed consists of a routing device and two temperature measurement nodes . Should the programs of the two temperature measurement nodes be the same? I use...
wwh19910609 RF/Wirelessly
ARM interrupt processing and SWI parameter issues
I now know that in ARM, software interrupts (SWI call) are used to switch the mode to super user mode (SVC mode). Then, the parameters of SWI can be stored in R0 using these two sentences: LDR R0, [LR...
scuahui ARM Technology
[Technical Application] Working Principle of Microwave Oven Magnetron
Working principle of microwave oven magnetron In addition to generating the required electromagnetic oscillation, the anode resonance system of the magnetron can also generate a variety of electromagn...
dontium RF/Wirelessly
The stream driver SRB.NumberOfPhysicalPages clock is 0
I want to modify the camera driver made by testcap in DDK and use DMA to get data. The DDK document says that SRB's ScatterGatherBuffer is used as DMA, and NumberOfPhysicalPages is the number of eleme...
beck17 Embedded System
A beginner is asking for help. The source code of two different LPC1768 chips, the QEIPOS register is not used
There are two projects, one has the define value of QEIPOS register in the header file lpc1700.h, and the other has only a typedef struct in LPC17xx.h. I don't quite understand how to use this registe...
yunhai14 NXP MCU
Shortcut:   00 01 02 03 04 05 06 07 08 09 0A 0C 0F 0J 0L 0M 0R 0S 0T 0Z 10 11 12 13 14 15 16 17 18 19 1A 1B 1C 1D 1E 1F 1H 1K 1M 1N 1P 1S 1T 1V 1X 1Z 20 21 22 23 24 25 26 27 28 29 2A 2B 2C 2D 2E 2F 2G 2K 2M 2N 2P 2Q 2R 2S 2T 2W 2Z 30 31 32 33 34 35 36 37 38 39 3A 3B 3C 3D 3E 3F 3G 3H 3J 3K 3L 3M 3N 3P 3R 3S 3T 3V 40 41 42 43 44 45 46 47 48 49 4A 4B 4C 4D 4M 4N 4P 4S 4T 50 51 52 53 54 55 56 57 58 59 5A 5B 5C 5E 5G 5H 5K 5M 5N 5P 5S 5T 5V 60 61 62 63 64 65 66 67 68 69 6A 6C 6E 6F 6M 6N 6P 6R 6S 6T 70 71 72 73 74 75 76 77 78 79 7A 7B 7C 7M 7N 7P 7Q 7V 7W 7X 80 81 82 83 84 85 86 87 88 89 8A 8D 8E 8L 8N 8P 8S 8T 8W 8Y 8Z 90 91 92 93 94 95 96 97 98 99 9A 9B 9C 9D 9F 9G 9H 9L 9S 9T 9W

Popular Components

  1. 177-710-1-15CS4K7-24BAN
  2. 50645-1141E
  3. DCPL37S6GTLF
  4. DPX3ME-40S-40P-40P-34-0001
  5. RNC60J4532BPB14
  6. 73MI2150JE00K
  7. RIAN16TTE151GCDY
  8. WF10T12R0BVLQ
  9. AME8500BEETBF21
  10. BZX84C5V6T/R7
  11. BZX55C75C-35T/B
  12. A3961WVA-11P-V0-BK-C2096D437

Popular Articles

  1. Teledyne e2v launches industry’s smallest 2 and 1.5 megapixel CMOS sensors
  2. Application of radar level meter in large chemical storage tanks
  3. 35-Pulse meter (heart rate meter) based on 51 single chip microcomputer
  4. Intel reflects on Vietnam's escalation of lockdown: impact on production expansion
  5. How to use the ground resistance tester
  6. Precautions for dust detector
  7. Japanese media: The Japanese government cabinet will set up a special department to focus on supply security of semiconductors, etc.
  8. OPPO's first self-developed chip is released
  9. MCU 74LS138 extended interrupt
  10. Zhezhong Shares: Guojing Semiconductor produces 12-inch silicon wafer automatic production line for integrated circuits

Technical ResourceMore

  1. Design and simulation of octave electronic piano based on Multisim
  2. Sound program based on LPC2292
  3. Study on judging SCR fault
  4. ASP.NET Programming Basics and Applications Electronic Lesson Plan
  5. Common system maintenance tools
  6. Design of Bluetooth temperature sensor
  7. Graduation Project Management Platform Based on SSH
  8. Displacement Calculation of Statically Determined Structures
  9. Liquid level constant value control scheme
  10. Frequency calculation method analysis and error analysis

EEWorld
subscription
account

EEWorld
service
account

Automotive
development
circle

Robot
development
community

About Us Customer Service Contact Information Datasheet Sitemap LatestNews
Index Files: 1521  27  1137  634  2501  31  1  23  13  51
Datasheet   0 1 2 3 4 5 6 7 8 9 A B C D E F G H I J K L M N O P Q R S T U V W X Y Z
Room 1530, 15th Floor, Building B, No. 18 Zhongguancun Street, Haidian District, Beijing Telephone: (010) 82350740 Postal Code: 100190
Copyright © 2005-2026 EEWORLD.com.cn, Inc. All rights reserved 京ICP证060456号 京ICP备10001474号-1 电信业务审批[2006]字第258号函 京公网安备 11010802033920号
