287-0022-01300

Description
16 CONTACT(S), FEMALE, STRAIGHT SINGLE PART CARD EDGE CONN, PRESS FIT
CategoryThe connector    The connector
File Size116KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric Compare View All

287-0022-01300 Overview

16 CONTACT(S), FEMALE, STRAIGHT SINGLE PART CARD EDGE CONN, PRESS FIT

287-0022-01300 Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
Objectid1495661857
Reach Compliance Codeunknown
Other featuresCROWN EDGE
Connector typeCARD EDGE CONNECTOR
Contact to complete cooperationNOT SPECIFIED
Contact point genderFEMALE
Contact materialNOT SPECIFIED
DIN complianceNO
Filter functionNO
IEC complianceNO
MIL complianceNO
Mixed contactsNO
Installation methodSTRAIGHT
Installation typeBOARD
Number of rows loaded2
OptionsGENERAL PURPOSE
Terminal pitch2.5 mm
Termination typePRESS FIT
Total number of contacts16
UL Flammability Code94V-0
My Account
Tyco Electronics
(C hange)
Se a rch by Ke yword or Pa rt #
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Power Products (>10 Amps/C ontact)
>
Product Feature Selector
> Product Details
287-0022-01300 Product Details
Live Product Chat
CROWN EDGE Modular Card Edge Power Distribution
Connectors
5 of 6 EU R oHS/ELV C om plia nt
(
Find R oHS C om plia nt
Alte rna te s
/
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
287-0022-01300
(1650534-1)
T E I nternal N umber: 1 6 5 0 5 3 4 - 1
Product Highlights:
l
Module Type = Signal Only
l
Module Length = 26.80 mm
l
16 Signal Positions
l
Not Hot Pluggable
l
Post Type = Press-Fit
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Active
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Additional Product Images:
l
Line Drawing
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Post Type = Press-Fit
l
PC B Thickness (mm [in]) = 3.18 [0.125]
Mechanical Attachment:
l
Module Type = Signal Only
l
Module Length (mm [in]) = 26.80 [1.055]
Electrical Characteristics:
l
Hot Pluggable
= No
Body Related Features:
l
Number of Signal Positions = 16
l
PC B Tail Length (mm [in]) = 5.08 [0.200]
Industry Standards:
l
RoHS/ELV C ompliance
= ELV compliant, 5 of 6 C ompliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C , Wave
solder capable to 260?C , Wave solder capable to 265?C
Other:
l
Brand = Elcon
