A
B
C
SOCKET
240-033-2-25PSCDP
GLENAIR 06324 0608
Micro-D
Connectors
Series
Shell Finish (See Table I)
Number of Contacts
9,15,21,25,31,37
Contact Type
P/S - Pin/Socket
Filter Type
C = C Filter
P = Pi Filter
D
E
F
© 2006 Glenair, Inc.
Pin-Socket In-Line Filter Adapters
240-033-2-25 PS C D P
Filter Class
A, B, C, D, E, F, or G (See Table III)
Hardware
N = No Hardware
P = Combination Jackscrew and Jackpost
(See photograph on this page)
240-033
Micro-D Filter Connectors
PIN
J
G
H
#2-56 UNC THDS
K
Avoid Costly Redesign with Micro-D Filter Adapters.
Upgrade your existing cables and boxes to meet EMI
requirements. These pin-socket adapters can be
plugged into any standard M83513 connectors. Simply
unplug your existing cable, install the filter adapter, and
plug the cable into the adapter.
In-Line Filter Adapters
feature gold plated TwistPin
contacts, machined aluminum shells, and either Pi or C
filter elements. These environmentally sealed adapters
are designed to meet the requirements of
MIL-DTL-83513.
CAGE Codes 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
E-Mail: sales@glenair.com
www.glenair.com
D-10
Pin-Socket In-Line Filter Adapters
240-033
Micro-D Filter Connectors
TABLE I: SHELL FINISH
SYM
1
2
3
4
5
6
MATERIAL
Aluminum
Aluminum
Stainless
Steel
Aluminum
Aluminum
Aluminum
FINISH DESCRIPTION
Cadmium
Nickel
Passivated
Black Anodize
Gold
Chem Film
TABLE lll: CAPACITOR ARRAY CODE
CAPACITANCE RANGE*
CLASS
A
B
C
D
E
F
G
PI - SECTION (pF)
38,000 - 56,000
32,000 - 45,000
18,000 - 33,000
8,000 - 12,000
3,300 - 5,000
800 - 1,300
400 - 600
C - SECTION (pF)
19,000 - 28,000
16,000 - 22,500
9,000 - 16,500
4,000 - 6,000
1,650 - 2,500
400 - 650
200 - 300
MICRO-D IN-LINE FILTER ADAPTER CONTACT ARRANGEMENTS
1
2
3
4
5
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
9 10 11
1
2
3
4
5
6
7
8
9 10 11 12 13
9
6
7
8
9
1
2
3
4
5
6
7
8
15
9 10 11 12 13 14 15
9 10 11 12 13 14 15 16
21
12 13 14 15 16 17 18 19 20 21
1
2
3
4
5
6
7
8
25
14 15 16 17 18 19 20 21 22 23 24 25
9 10 11 12 13 14 15 16 17 18 19
31
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
37
20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37
Mating Face View of Pin Connector. Socket connectors have reversed cavity numbers.
MICRO-D FILTER INLINE DIMENSIONS
A Max.
Layout
9PS
15PS
21PS
25PS
31PS
37PS
In.
.785
.935
1.085
1.185
1.335
1.485
In. mm.
mm.
± .003 ± 0.08
19.94
.565 14.35
23.75 .715 18.16
27.56 .865 21.97
30.01 .965 24.51
33.91 1.115 28.32
37.72 1.265 32.13
B
C Max.
In.
.333
.483
.633
.733
.883
1.033
D Max.
In.
.250
.250
.250
.250
.250
.250
E Max.
In.
.310
.310
.310
.310
.310
.310
mm.
8.46
12.27
16.08
18.62
22.43
26.24
mm.
6.35
6.35
6.35
6.35
6.35
6.35
In. mm.
mm.
± .004 ± 0.10
7.87
7.87
7.87
7.87
7.87
7.87
.195
.195
.195
.195
.195
.195
4.95
4.95
4.95
4.95
4.95
4.95
F
G Max.
In.
1.400
1.400
1.400
1.400
1.400
1.400
In. mm.
mm.
± .004 ± 0.10
35.56
35.56
35.56
35.56
35.56
35.56
.183
.183
.183
.183
.183
.183
4.65
4.65
4.65
4.65
4.65
4.65
H
J Max.
In.
.333
.483
.633
.733
.883
1.033
K Max.
In.
.184
.184
.184
.184
.184
.184
mm.
8.46
12.27
16.08
18.62
22.43
26.24
mm.
4.67
4.67
4.67
4.67
4.67
4.67
© 2006 Glenair, Inc.
CAGE Codes 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
E-Mail: sales@glenair.com
www.glenair.com
D-11
