NEW
FIXED THICK FILM CHIP RESISTORS; RECTANGULAR TYPE & PRECISION
KAMAYA OHM
RGC
•
Features
1. Suitable for precision applications.
2. High stabilized characteristics and Performance equivalent to thin-
film chip resistors.
3. Precise Dimension by Laser-scriber method (RGC1/20).
4. Press Pocket Taping Package (RGC1/20).
5. Please contact KAMAYA for Halogen and Antimony free product of
RGC series.
6. Stability Class : 5%
•
Dimensions
L
W
c
c
H
Rated resistance value marking is with 3-digit (E24) or
4-digit (E96) on the over coating.
RGC1/16 : only 3-digit marking is available.
RGC1/16S,1/20 : only No marking is available.
d
d
Unit : mm
Style
RGC1/20
RGC1/16S
RGC1/16
RGC1/10
RGC1/8
Metric
0603
1005
1608
2012
3216
Inch
0201
0402
0603
0805
1206
L
0.6
1.0
1.6
2.0
3.2
0.03
0.05
0.1
0.1
0.15
W
0.3
0.03
0.05
0.5
e0.15
0.8
0.05
1.25 0.10
0.15
1.6
H
0.23
0.35
0.45
0.6
0.6
0.03
0.05
0.10
0.1
0.1
0.1
0.2
0.25
0.4
0.5
c
0.05
0.1
0.10
0.2
0.25
0.15
0.25
0.3
0.4
0.5
d
0.05
e0.05
0.10
0.1
0.2
0.25
*Unit weight/pc.
0.16mg
0.6mg
2mg
5mg
9mg
*Values for reference
•
Part Number Description
Example
Style
RGC
1/16
C
473
D
TP
Product Type
Rated Dissipation & Size
Code Rated Dissipation Metric
1/20
0.05W
1/16S 0.063W
0.1W
1/16
(0.063W)
0.125W
1/10
(0.1W)
0.25W
1/8
(0.125W)
0603
1005
1608
2012
3216
Inch
0201
0402
0603
0805
1206
Tolerance on Rated Resistance
D
0.5%
F
1.0%
Rated Resistance
E24 Series
e.g. : 473=47k ohm
3-Digit
* Packaging & Standard Qty. (Min.)
1,000pcs. All Styles
B Bulk (Loose Package)
Press-Pocket
PA
15,000pcs. RGC1/20
Paper Tape (2mm pitch)
TH Paper Tape (2 mm pitch) 10,000pcs. RGC1/16S
RGC1/16
5,000pcs. RGC1/10
TP Paper Tape
RGC1/8
25,000pcs. RGC1/16
10,000pcs. RGC1/10
BA Bulk Case
5,000pcs. RGC1/8
*Refer to Tape and Packaging information on pages 54 and 55.
*Please contact Kamaya sales department for 1mm pitch taping of RGC1/16s, 1/20.
E96 Series
e.g. : 7152=71.5k ohm 4-Digit
Temperature Coefficient of Resistance
C
50×10
-6
/°C
K
100×10
-6
/°C
If Category Temperature Range is
"–55~+155", Rated Dissipation is
applied to in ( ).
4
Product specifications contained in this catalogue are subject to change at any time without notice. Please confirm specifications with your order.
【RoHS】
KAMAYA OHM
FIXED THICK FILM CHIP RESISTORS; RECTANGULAR TYPE & PRECISION
RGC
•
Ratings
Style
RGC1/20
Size Rated Dissipation
at 70°C
Metric
W
(Inch)
0603
0.05
(0201)
1005
(0402)
0.063
Rated Resistance Range
10
100
1k
1M
51 976
1k 1M
Tolerance on
Rated Resistance
D( 0.5%)
D( 0.5%)
F( 1%)
F( 1%)
Temperature Coefficient
Limiting Element
of Resistance
Voltage
Code
K
C
K
C
K
K
C
K
C
C
10
-6
/°c
100
50
100
50
100
100
50
100
50
50
V
25
Isolation Category Temperature
Voltage
Range
V
°C
50
55
55
125
155
10 97.6
100 1M
1.02M 3.3M
3.3 9.76
RGC1/16S
50
100
1
RGC1/16
1608
(0603)
2012
(0805)
3216
(1206)
1
0.1
(0.063)
3.3 9.76
10 97.6
100 1M
1.02M 3.3M
D( 0.5%)
F( 1%)
F( 1%)
D ( 0.5%), F ( 1%)
F( 1%)
D ( 0.5%), F ( 1%)
RGC1/10
RGC1/8
0.125
1
(0.1)
0.25
1
(0.125)
10 3.3M
3.3 9.76
10 4.7M
150
200
55
125
( 55 155)
1
If Category Temperature Range is "–55~+155", Rated Dissipation is applied to in ( ).
Note1.
Note2.
Note3.
Note4.
E24, E96 are avaialable for "F"(1%) and "D"(0.5%)
Rated Voltage = (Rated Dissipation)×(Rated Resistance). (d.c. or a.c. r.m.s. Voltage)
Limiting Element Voltage can only be applied to resistors when the resistance value is equal to or higher than the critical resistance value.
Critical Resistance Value is the resistance value at which the rated voltage is equal to the limiting element voltage.
The derated values of dissipation for temperatures in excess of 70°C
shall be indicated by the following Curve.
100
•
Derating Curve
•
Climatic Category
55/125/56
2
(55/155/56)
Percentage of the rated dissipation(%)
Lower Category Temperature
−55°C
Upper Category Temperature
+125°C
Duration of the Damp heat,
Steady-State Test
56 days
2
(–55°C)
2
(+155°C)
2
(56 days)
Area of recommended operation
0
55
70
125
155
2
Ambient Temperature (°C)
•
Performance Characteristics
Description
Voltage proof
Variation of resistance with temperature See Ratings Table
Overload
Solderability
Resistance to soldering heat
Rapid change of temperature
Climatic sequence
Damp test, steady state
Endurance at 70°C
Endurance at the upper category temperature
Adhesion
Bend strength of the face plating
∆R≤±(1%+0.05
ohm)
No visible damage, legible marking
In accordance with Clause 4.17.4.5
∆R≤±(1%+0.05
ohm)
JIS C 5201-1 : 1998
Test Methods
Clause 4.7
Clause 4.8
RGC1/20
RGC1/16S, 1/16, 1/10, 1/8
50Va.c.,60s
100Va.c.,60s
Requirements
No breakdown or flashover
R≥1G ohm
Measuring temperature :
+20°C/+125°C
2
(+155°C) /+20°C
Clause 4.13 The applied voltage shall be 2.5 times of the rated voltage or twice of the limiting
element voltage, whichever is the less severe, 2s.
Clause 4.17 235°C, 2s
Clause 4.18 After immersion into the flux, the immersion into solder shall be carried out in Solder bath at 260°C for 5s.
Clause 4.19 5 cycles between
−55°C
and
+125°C
2
(+155°C).
Clause 4.23 Dry/Damp heat (12+12h cycle), first cycle./
Cold/Damp heat (12+12h cycle), remaining
cycle. /D.C.Load.
Clause 4.24 40°C, 95%R.H., 56 days, test a) and b) of Clause 4.24.2.1
Clause 4.25.1 Rated voltage, 1.5h"ON", 0.5h"OFF", 70°C, 1,000h.
Clause 4.25.3 125°C
2
(155°C), no-load, 1,000h.
Clause 4.32 5N, 10s (RGC1/20 : 3N)
Clause 4.33 Amount of bend : 3 mm
∆R≤±(1%+0.05
ohm) No visible damage
∆R≤±(5%+0.1
ohm) No visible damage
∆R≤±(5%+0.1
ohm) No visible damage, legible marking
∆R≤±(5%+0.1
ohm) No visible damage
∆R≤±(5%+0.1
ohm) No visible damage
No visible damage
∆R≤±(1%+0.05
ohm)
2
( ) on Derating Curue, Climatic Category, and Test Methods will be applied, when Upper Category Temperature is +155°C.
Product specifications contained in this catalogue are subject to change at any time without notice. Please confirm specifications with your order.
【RoHS】
5
