HIGH VOLTAGE CERAMIC CHIP (+125ºC)

Military Equivalent

FEATURES

1. The ceramic chip capacitors described in this section are the types used

in our other high voltage ceramic multilayer product lines.

2. Types BP, BR and BZ available as described in MIL-PRF-49467.

3. Group A and B screening per MIL-PRF-49467 available.

4. Ceramic chip capacitors are extremely sensitive to thermal shock damage

during installation. Wherever possible, processes involving infrared or

vapor phase soldering systems should be utilized.

5. Higher voltages available upon request

6. Where nickel barrier termination is required, end band length dimensions

may exceed the standard dimension listed.

CERAMIC CHIP OUTLINE DRAWING

DIMENSIONS

Style

1515

1812

1825

2020

2225

2520

3333

3530

4040

4540

5440

5550

6560

Length (L)

Inches (mm)

.150 ±.015 (3.81 ±.38)

.180 ±.020 (4.57 ±.51)

.200 ±.020 (5.08 ±.51)

.220 ±.020 (5.59 ±.51)

.250 ±.020 (6.35 ±.51)

.330 ±.030 (8.38 ±.76)

.350 ±.030 (8.89 ±.76)

.400 ±.030 (10.2 ±.76)

.450 ±.030 (11.43 ±.76)

.540 ±.030 (13.7 ±.76)

.550 ±.030 (14.0 ±.76)

.650 ±.030 (16.5 ±.76)

.150

.120

.250

.200

.250

.200

.330

.300

.400

.500

.600

Width (W)

Inches (mm)

±.015

±.020

±.030

(3.81

(3.05

(6.35

(5.08

(6.35

(5.08

(8.38

(7.62

(10.2

(12.7

(15.2

±.38)

±.51)

±.76)

Thickness (T) max

Inches (mm)

.140

.100

.160

.180

.200

.180

.220

(3.55)

(2.54)

(4.07)

(3.55)

(5.08)

(4.57)

(5.59)

Bandwidth (BW)

Inches

.010

.030

.030”

.040”

.060”

RECOMMENDED SOLDER PAD PATTERN DIMENSIONS

1515

1812

1825

2020

2225

2520

3333

3530

4040

4540

5440

5550

6560

5.20

5.90

6.50

7.00

8.68

10.91

11.51

12.88

14.21

16.51

18.92

19.80

0.205

0.232

0.256

0.276

0.342

0.430

0.453

0.507

0.559

0.650

0.745

0.780

1.90

2.30

2.80

3.30

4.98

7.11

7.61

8.88

10.15

10.41

12.82

13.20

0.075

0.091

0.110

0.130

0.196

0.280

0.300

0.350

0.400

0.410

0.505

0.520

4.34

3.70

6.90

5.62

6.80

5.62

9.27

8.51

11.05

13.59

16.13

0.171

0.146

0.272

0.221

0.268

0.221

0.365

0.335

0.435

0.535

0.635

1.65

1.80

1.85

1.90

1.95

2.00

2.03

3.05

3.30

0.065

0.071

0.073

0.075

0.077

0.079

0.080

0.120

0.130

PART NUMBER AND ORDERING INFORMATION

4540

Style

1515, 2020, etc.

472

202

Group A Screening*

Add to part number if required

*MIL-PRF-49467

(subgroup 1)

except Corona

Dielectric

B or R = X7R

N = C0G (NP0)

Terminal Material

Capacitance Value

First two digits are significant,

last digit is number of zeros,

i.e., 472=4700pF

P = PdAg

S = Ag

E = Ag/Ni/SnPb Plate

C = Ag/Ni/Sn Plate

Tolerance

J = ±5% C0G (NP0)

K = ±10%

M = ±20%

P = 0/+100%

Z = -20%/+80%

Voltage

MARKING

Not applicable

As required by customer only.

First two digits are significant,

last digit is number of zeros,

i.e., 202=2000V
