SMT Power Inductor
SIS85 Type
Features
Low profile (5.0mm max. height), high current (6.8A, 1uH) SMD type.
Unshielded, suitable for high density mounting.
High energy storage and low DCR.
Provided with embossed carrier tape packing.
Ideal for power source circuits, DC-DC converter,
DC-AC inverters inductor application.
In addition to the standard versions shown here,
custom inductors are available to meet your exact requirements.
Mechanical Dimension:
Unit: mm
Recommended Pad
9.4 Max.
2.54 0.2
2.54 0.2
2.92
2.79
12.95 Max.
7.62 0.2
7.37
5.0 Max.
Electrical Characteristics:
PART NO.
SIS85-1R0
SIS85-1R5
SIS85-2R2
SIS85-3R3
SIS85-4R7
SIS85-6R8
SIS85-100
SIS85-150
SIS85-220
SIS85-330
SIS85-470
SIS85-680
SIS85-101
SIS85-151
SIS85-221
SIS85-331
SIS85-471
SIS85-681
SIS85-102
1000.00
L
(uH)
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
102
681
471
331
221
151
101
680
470
330
220
150
100
6R8
4R7
3R3
2R2
1R5
1R0
DCR
( ) MAX
0.009
0.010
0.012
0.015
0.018
0.027
0.038
0.046
0.085
0.100
0.140
0.200
0.280
0.400
0.610
1.020
1.270
2.020
3.000
Is
(Adc)
9.0
8.0
7.0
6.4
5.4
4.6
3.8
3.0
2.6
2.0
1.6
1.4
1.2
1.0
0.8
0.6
0.5
0.4
0.3
Ir
(Adc)
6.8
6.4
6.1
4.8
4.4
3.9
3.1
2.7
2.1
1.8
1.5
1.3
1.0
0.8
0.6
0.5
0.4
0.3
5.4
100.00
INDUCTANCE (uH)
10.00
100
150
220
330
470
680
1000
1.00
0.00
0.01
0.10
1.00
10.00
100.00
Tolerance of inductance
1.0~1000uH 20%
L<10% at I
S
T<45
o
C at Ir
Operating temperature: -20
o
C to 105
o
C (including self-temperature rise)
Test condition at 25
o
C: 100KHz, 0.1V
CURRENT (A)
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com
