TLE 5226 G

Smart Quad Channel Low-Side Switch

Features

•

Low ON-resistance 2 x 0.2

Ω

, 2 x 0.35

Ω

(typ.)

•

Power - SO 20 - Package with integrated

cooling area

•

Overload shutdown

•

Selective thermal shutdown

•

Status monitoring

•

Overvoltage protection

•

Shorted circuit protection

•

Standby mode with low current consumption

•

µC compatible input

•

Electostatic discharge

(ESD) protection

Product Summary

Supply voltage

Drain source voltage

On resistance

Output current

DS(AZ)max

ON(typ) 1,2

ON(typ) 3,4

D 1,2

D 3,4

4.8 - 32

0.2

0.35

2x5

2x3

Ω

Application

•

All kinds of resistive and inductive loads (relays,electromagnetic valves)

•

µC compatible power switch for 12 and 24 V applications

•

Solenoid control switch in automotive and industrial control systems

P-DSO-20-10

General description

Quad channel Low-Side-Switch (2x5A/2x3A) in Smart Power Technology (SPT) with four seperate in-

puts and four open drain DMOS output stages. The TLE 5226 is fully protected by embedded protecti-

on functions and designed for automotive and industrial applications.

Pin Description

Symbol

GND

OUT1

ST1

IN4

STBY

IN3

ST2

OUT2

GND

OUT3

ST3

IN2

GND

ENA

IN1

ST4

OUT4

GND

Function

Ground

Power Output channel 1

Status Output channel 1

Control Input channel 4

Supply Voltage

Standby

Control Input channel 3

Status Output channel 2

Power Output channel 2

Ground

Power Output channel 3

Status Output channel 3

Control Input channel 2

Ground Logic

Enable Input for all four channels

Control Input channel 1

Status Output channel 4

Power Output channel 4

Ground

Pin Configuration (Top view)

P - DSO - 20 - 10

Semiconductor Group

Page

1998-02-04
