This document was generated on 03/27/2014
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
46012-1141
Active
Mini-Fit® Plus Connector System
Mini-Fit® Plus Crimp Terminal, 18-20 AWG, Reel, Tin (Sn) Plating
Documents:
Drawing (PDF)
Product Specification PS-45750-001 (PDF)
Packaging Specification PK-46012-001 (PDF)
RoHS Certificate of Compliance (PDF)
Series
Crimp Terminals
46012
Power
Current = 13A max. per circuit when header is mated
to a receptacle loaded with 45750 series terminals
crimped to 16 AWG wire. . See Molex product
specification PS-45750-001 for additional current de-
rating information.
Yes
Mini-Fit® Plus Connector System
46012-1142 (Loose)
Mini-Fit® Plus
822350570435
image - Reference only
EU RoHS
ELV and RoHS
Compliant
REACH SVHC
Not Reviewed
Low-Halogen Status
Low-Halogen
China RoHS
General
Product Family
Series
Application
Comments
Crimp Quality Equipment
Overview
Packaging Alternative
Product Name
UPC
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Physical
Durability (mating cycles max)
Gender
Material - Metal
Material - Plating Mating
Material - Plating Termination
Net Weight
Packaging Type
Plating min - Mating
Plating min - Termination
Termination Interface: Style
Wire Insulation Diameter
Wire Size AWG
Wire Size mm²
30
Male
Copper
Tin
Tin
0.145/g
Reel
2.540µm
2.540µm
Crimp or Compression
1.65-2.95mm
18, 20
N/A
Search Parts in this Series
46012Series
Mates With
45750 Mini-Fit® Plus Crimp Terminal
Use With
5559 Mini-Fit Jr.™ Plugs, 42475 Mini-Fit®
MBI Panel Mount Plugs, 30068 Mini-Fit®
TPA Plugs
Application Tooling
|
FAQ
Tooling specifications and manuals are
found by selecting the products below.
Crimp Height Specifications are then
contained in the Application Tooling
Specification document.
Global
Description
Product #
FineAdjust™
0639023900
Applicator for
Insulation OD
1.40-1.70mm - 18-24
AWG
Extraction Tool
0011030044
Electrical
Current - Maximum per Contact
Voltage - Maximum
13A
600V
Material Info
Reference - Drawing Numbers
Packaging Specification
Product Specification
Sales Drawing
PK-46012-001
PS-45750-001
SD-46012-001
