PC SCREW TERMINALS
LOW PROFILE VERTICAL TYPE
6-32 X .250 [6.3] L.
SCREW
SPECIFICATIONS
.343 [8.7]
.250 [6.3]
Rated:
15 Amps
Terminal:
.032 (.81) Brass, Matte Tin
Plate
Binding Head Screw:
Brass, Nickel Plate
.310 [7.9]
6-32 x .250 [6.3] L.
SCREW
.310
[7.9]
7778-7
.250 [6.4]
.134 [3.4]
7775-2
•
Color coded screws
available (add color
screw suffix to Cat. No.)
.312
[7.9]
.055 [1.4]
(2) PLS
.187 [4.7]
.276
[7.0]
.197 [5.0]
.059 [1.5]
(4) PLS
.197 [5.0]
•
Color coded screws
available (add color
screw suffix to
Cat. No.)
Mounting Detail
.197 [5.0]
.276
[7.0]
.144 [3.7]
DIA.
Mounting Detail
.312 [7.9]
CAT. NO. 7784
(No Screw Supplied)
CAT. NO. 8198
(Screw Supplied Unassembled)
CAT. NO. 7778
(Screw Installed & Captivated)
CAT. NO. 7785
(No Screw Supplied)
CAT. NO. 8195
(Screw Supplied Unassembled)
CAT. NO. 7775
(Screw Installed & Captivated)
.067 [1.7] DIA.
(2) PLS
.062 [1.57] DIA. (4) PLS
VERTICAL TYPE
EXTENDED
.310 [7.9]
6-32 x .250 [6.3] L.
SCREW
SPECIFICATIONS
Rated:
15 Amps
Terminal:
.032 (.81) Brass, Mattte Tin Plate
Binding Head Screw:
Brass, Nickel Plate
10-32 X .375 [9.5] L.
SCREW
HEAVY DUTY
.375 [9.5]
.310 [7.9]
.382 [9.7]
SCREW TERMINALS
7699-6
.718
[18.3]
8174
.947
[24.1]
.383 [9.7]
PC MOUNT
•
Color coded screws
available (add color
screw suffix to Cat. No.)
.197 [5.0]
.276
[7.0]
.209 [5.3]
Mounting Detail
.197
[5.0]
.341 [8.7]
Mounting Detail
.197 [5.0]
.341 [8.7]
.060
[1.5]
.197
[5.0]
.197 [5.0]
CAT. NO. 7789
(No Screw Supplied)
CAT. NO. 7697
(Screw Supplied Unassembled)
.060 [1.52]
(4) PLS
.276 [7.0]
CAT. NO. 7791
(No Screw Supplied)
.073 [1.85] DIA.
(4) PLS
CAT. NO. 7699
(Screw Installed & Captivated)
CAT. NO. 8174
(Screw Supplied Unassembled)
.073 [1.85] DIA.
(4) PLS
30 AMP - VERTICAL
PRINCIPAL FEATURES
.060 [1.5] (6) PLS
6-32 x .250 [6.3] L.
SCREW
HEAVY DUTY
.060 [1.5] (6) PLS
•
Compact, heavy duty design
•
Six snap-in legs for total stability
•
Serrated top surface secures connection
.310 [7.9]
.470 [11.9]
.507 [12.9]
.250 [6.3]
10-32 x .375 [9.5] L.
SCREW
8199-6
•
Combination drive, binding
head screw
•
Color coded screws
available (add color
screw suffix to Cat. No.)
.470 [11.9]
8196
.210 [5.3]
.276
7.0
.197
[5.0]
.394
[10.0]
.453 [11.5]
Mounting Detail
.226 [5.7]
SPECIFICATIONS
Rated:
30 Amps
Terminal:
.032 (.81) Brass, Matte Tin Plate
Binding Head Screw:
Brass, Nickel Plate
CAT. NO. 7786
(No Screw Supplied)
Mounting Detail
.394
[10.0]
.276
[7.0]
.197
[5.0]
SPECIFICATIONS
.425
[10.8]
Rated:
30 Amps
Terminal:
.045 (1.14) Brass, Matte Tin Plate
Screw:
Stainless Steel
.205
[5.2]
.410 [10.4]
.425
10.8
.410
[10.4]
.205
[5.2]
CAT. NO. 8197
(Screw Supplied Unassembled)
CAT. NO. 8199
(Screw Installed & Captivated)
.076 [1.93] DIA. (6) PLS
CAT. NO. 7787
(No Screw Supplied)
CAT. NO. 8196
(Screw Supplied Unassembled)
.101 [2.6] DIA. (6) PLS
COLOR CODED SCREW TERMINAL SELECTION GUIDE
Color Coded Screw Terminals
provide:
•
Quick identification
•
Visibility for field service
troubleshooting
SPECIFICATIONS
Combination Binding Head:
Standard screw is Brass,
Nickel Plate. For painted,
color head, add suffix as
shown.
•
Available for screw terminals where noted.
COLOR SELECTION:
Select desired screw terminal
and add color suffix to the
screw terminal Cat. No.
HEAD COLOR
RED
BLACK
WHITE
BLUE
GREEN
YELLOW
NICKEL
SUFFIX
-2
-3
-4
-5
-6
-7
none
CAT. NO. COLOR SUFFIX
Ex:
XXXX
-X
7699-6
8199-2
7692-7
6-32 x
.250 [6.3] L.
THREAD
7775-4
7701
7693-5
7700-3
Refer to page 133 for color screws only
®
Tel (718) 956-8900
•
Fax (718) 956-9040
(800) 221-5510
•
kec@keyelco.com
RoHS COMPLIANT
~
ISO 9001 CERTIFIED
www.keyelco.com
31-07 20th Road – Astoria, NY 11105-2017
