33,32
+ 0,13
- 0,12
n
3,1
`
0,1
(2x)
6
+ 0,18
-
0,12
P.C.B. HOLE DRILLINGS
5,33
+ 0,32
- 0,28
D
(5:1)
D
0,9
8,26
+ 0,22
- 0,03
39,22
+ 0,3
- 0,46
0,33
12,6
+ 0,43
-
33,32
+ 0,13
- 0,12
25,17
+ 0,2
- 0,05
C
C
10°
1003W3PXX99A30X CONEC ABC
4-40 UNC
B
B
see note 7
REF. 2,55
NOTES:
1. METALSHELLS: COPPER ALLOY; min. 315µin TIN over 40-80µin NICKEL
2. INSULATORS: PBT GF UL 94 V-0; GREEN
3. NO CONTACTS ON POS A1-A3
4. THREADED INSERT: COPPER ALLOY; min. 200µin TIN over 80µin NICKEL
5 COLLAR: COPPER ALLOY; min. 200µin TIN over 80µin NICKEL
6. MAXIMUM TORQUE VALUE FOR THREAD: 6 in.LB
7. CONNECTOR IS PART MARKED: 1003W3PXX99A30X CONEC ABC
THIS DRAWING MAY NOT BE COPIED OR
REPRODUCED IN ANY WAY, AND MAY NOT
BE PASSED ON TO A THIRD PARTY WITHOUT
WRITTEN PERMISSION.
OWNERSHIP AND COPYRIGHT OF CONEC GmbH
APPROVAL # FREIGABE # DEBLOCAGE # AUTORIZACION
APPROVAL # FREIGABE # DEBLOCAGE # AUTORIZACION # APPROVAL
CUSTOMER APPROVAL DATE:
DO NOT ALTER CAD DRAWING BY HAND
tolerance
dim. in mm
date
drawn
appd.
norm
d-old
R
scale:
material:
title:
2:1 (5:1)
APPROVAL # FREIGABE # DEBLOCAGE # AUTORIZACION
see notes
A
A
name
NAME:
TITLE:
18.11.08
18.11.08
Schmidt
Mickenbecker
D-SUB COMBINATION MALE
3W3P
with threaded insert
dwg no:
COMPANY NAME:
Inventor 10
a
Origin
13K1A2684
part no:
B
A
DIN-
A3
sh:
1
APPROVAL # FREIGABE # DEBLOCAGE # AUTORIZACION # APPROVAL
rev. description
D
date
name
C
1003W3PXX99A30X
F
E
