SI8460AA-B-IS1: DescriptionLOW POWER SIX-CHANNEL DIGITAL ISOLATOR; File Size424KB，36 Pages; ManufacturerSILABS; Websitehttp://www.silabs.com

Download Datasheet View All

SI8460AA-B-IS1 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	SI8460AA-B-IS1	-	-	View	Buy Now

SI8460AA-B-IS1 Overview

LOW POWER SIX-CHANNEL DIGITAL ISOLATOR

Preview

Download Datasheet

View All

Si8460/61/62/63

O W

O W E R

I X

- C

H A N N E L

I G I TA L

S O L A T O R

Features



High-speed operation





Up to 2500 V

RMS

isolation



4 mA per channel at 100 Mbps



High electromagnetic immunity

Applications



Industrial automation systems



Hybrid electric vehicles



Isolated switch mode supplies

Safety Regulatory Approvals



UL 1577 recognized



to 2500 V

RMS

for 1 minute

CSA component notice 5A

approval



IEC

60950-1, 61010-1

(reinforced

insulation)

Description

Silicon Lab's family of ultra-low-power digital isolators are CMOS

devices offering substantial data rate, propagation delay, power, size,

reliability, and external BOM advantages when compared to legacy

isolation technologies. The operating parameters of these products

remain stable across wide temperature ranges throughout their

service life. For ease of design, only VDD bypass capacitors are

required.

Data rates up to 150 Mbps are supported, and all devices achieve

worst-case propagation delays of less than 10 ns. All products are

safety certified by UL, CSA, and VDE and support withstand voltages

of up to 2.5 kVrms. These devices are available in a 16-pin narrow-

body SOIC package.

Rev. 1.5 9/13

fo R

r N ec

D e

e s nd

ig e

ns d



SOIC-16

60-year life at rated working

No start-up initialization required

voltage

Wide Operating Supply Voltage:



Precise timing (typical)

2.70–5.5 V



<10 ns worst case

Wide Operating Supply Voltage:



1.5 ns pulse width distortion

2.70–5.5V



0.5 ns channel-channel skew



2 ns propagation delay skew

Ultra low power (typical)



6 ns minimum pulse width

5 V Operation:



Transient Immunity 25 kV/µs



< 1.6 mA per channel at 1 Mbps



< 6 mA per channel at 100 Mbps



Wide temperature range

2.70 V Operation:



–40 to 125 °C at 150 Mbps



< 1.4 mA per channel at 1 Mbps



RoHS-compliant packages

narrow body

to 150 Mbps

Ordering Information:

See page 29.



Isolated ADC, DAC



Motor control



Power inverters



Communications systems



VDE certification conformity



IEC

60747-5-2

(VDE0884 Part 2)

Si8460/61/62/63

Si8460/61/62/63

ABLE O F

ONTENTS

Section

Page

fo R

r N ec

D e

e s nd

ig e

ns d

Rev. 1.5

1. Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

2. Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

2.1. Theory of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

2.2. Eye Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

2.3. Device Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

2.4. Layout Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

2.5. Typical Performance Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

3. Errata and Design Migration Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

3.1. Power Supply Bypass Capacitors (Revision A and Revision B) . . . . . . . . . . . . . . . . 27

3.2. Latch Up Immunity (Revision A Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

4. Pin Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

5. Ordering Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

6. Package Outline: 16-Pin Narrow Body SOIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

7. Land Pattern: 16-Pin Narrow Body SOIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

8. Top Marking: 16-Pin Narrow Body SOIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

8.1. 16-Pin Narrow Body SOIC Top Marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

8.2. Top Marking Explanation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Document Change List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
