Amphenol
Power Box Interconnects
G873H
Materials
Housing
Contacts
Finish
– 94V-0 Nylon
– P/B with 50µ” Ni
– Tin/Lead-30 Cycles
– Gold Flash-30 Cycles
4.2mm pitch Receptacle and Crimp Socket
Electrical
Current
– 9A @ 250VRMS
– G874A below
– G874H below
– Consult representative
Mating Half
B2W Headers
W2W Plug
Termination Info
Part Number System:
G873H XX X X
POWER CONNECTOR
4.2mm PITCH
Receptacle Crimp type
NUMBER OF POSITIONS
02 to 24 Positions
Suffix may be added to Part Number.
This Suffix is for Internal use mainly.
Additional Suffix ‘EU’ or ‘LF’ may be
added for RoHS compliant product.
COLOUR OF INSULATOR
1: White
2: Black
3: Beige
4: Brown
6
8.4
13.8
G873C024
G873C124
8
10
12.6
16.8
18.0
22.2
Tin/Lead, Left-Hand Feed, 10K Reel
Gold Flash, Left-Hand Feed, 10K Reel
12
14
16
18
20
22
21.0
25.2
29.4
33.6
37.8
42.0
26.4
30.6
34.8
39.0
43.2
47.4
24
46.2
51.6
Contact
18~24AWG
Positions
2
Dim A
Dim B
5.4
Part Number:
4
4.2
9.6
Dimensions in mm
PNS-873HC Rev. B/SKT-G873HCXX-16 Rev. A
G874H
Materials
Housing
Contacts
Finish
4.2mm pitch Plug and Crimp Pin
Electrical
– 94V-0 Nylon
– P/B with 50µ” Ni
– Tin/Lead-30 Cycles
– Gold Flash-30 Cycles
Current
– 9A @ 250VRMS
– G873H above
– Consult representative
Mating Half
W2W Receptacle
Termination
Part Number System:
G874H XX X X
POWER CONNECTOR
4.2mm PITCH
Pin Crimp type
NUMBER OF POSITIONS
02 to 24 Positions
Suffix may be added to Part Number.
This Suffix is for Internal use mainly.
Additional Suffix ‘EU’ or ‘LF’ may be
added for RoHS compliant product.
COLOUR OF INSULATOR
1: White
2: Black
3: Beige
4: Brown
G874C024
G874C124
8
12.6
18.0
10
16.8
22.2
Tin/Lead, Left-Hand Feed, 10K Reel
Gold Flash, Left-Hand Feed, 10K Reel
12
14
16
18
20
22
21.0
25.2
29.4
33.6
37.8
42.0
26.4
30.6
34.8
39.0
43.2
47.4
Contact
18~24AWG
Positions
2
Dim A
Dim B
5.4
Part Number:
4
4.2
9.6
6
8.4
13.8
24
46.2
51.6
Dimensions in mm
PNS-8740 Rev. A/SKT-G874HCXX-16 Rev. A
G874A
Materials
Housing
Contacts
Finish
4.2mm pitch PCB Header
Electrical
– 94V-0 Nylon
– P/B with 50µ” Ni
– Tin/Lead – 30 Cycles
– Gold Flash – 30 Cycles
Current
– 9A @ 600V
– G873H above
Straight
PCB Mount
Mating Half
B2W Receptacle
Part Number System:
G874A XX X X X X
POWER CONNECTOR
4.2mm PITCH Header
Dip type
NUMBER OF POSITIONS
02 to 24 Positions
CONNECTOR STYLE
1: Straight
2: Right Angle
Positions
Dim A
Dim B
Dim C
AMTA
Suffix may be added to Part Number.
This Suffix is for Internal use mainly.
Additional Suffix ‘EU’ or ‘LF’ may be
added for RoHS compliant product.
MOUNTING STYLES
0: None
1: with Board-locks (Straight Only)
2: with Mounting Ear (R/A Only)
CONTACT FINISH
0: Gold Flash
1: 100µ” Tin
6
8.4
13.8
17.8
8
12.6
18.0
22.0
10
16.8
22.2
26.2
12
21.0
26.4
30.4
14
25.2
30.6
34.6
16
29.4
34.8
38.8
18
33.6
39.0
43.0
20
37.8
43.2
47.2
22
42.0
47.4
51.4
24
46.2
51.6
55.6
Right Angle
PCB Mount
2
5.4
9.4
4
4.2
9.6
13.6
Dimensions in mm
PNS-874A Rev. A
PHD-G874AXX2-15 Rev. A/PHD-G874AXX1XX-15 Rev. A
L-3
