Data Sheet
PT8A2611/2621
PIR Sensor Light Switch Controller
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pin Assignment
PT8A2611P/PT8A2611W
GND
TRIAC
OSCD
OSCS
ZC
CDS
MODE
V
CC
1
2
3
4
5
6
7
8
16
15
14
13
12
11
10
9
OP2O
OP2N
OP2P
OP1O
OP1N
OP1P
RST
V
EE
PT8A2621P/PT8A2621W
GND
RELAY
OSCD
OSCS
ZC
CDS
MODE
V
CC
1
2
3
4
5
6
7
8
16
15
14
13
12
11
10
9
OP2O
OP2N
OP2P
OP1O
OP1N
OP1P
RST
V
EE
Top view
Top view
Pin Description
Pin
Name
2611 2621
1
1
2
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
3
4
5
6
7
8
9
10
11
12
13
14
15
16
GND
RELAY
TRIAC
OSCD
OSCS
ZC
CDS
MODE
V
CC
V
EE
RST
OP1P
OP1N
OP1O
OP2P
OP2N
OP2O
Ground Ground
O
O
I/O
I/O
I
I
I
Power
O
I
I
I
O
I
I
O
RELAY drive output through an external NPN transistor, active high
TRIAC drive two-pulse output, active negative pulse.
Output timing oscillator I/O, connected to an external RC to adjust output duration.
System oscillator I/O, connected to an external RC to set the system frequency. The system
frequency = 16kHz for normal application.
Schmitt input for AC zero crossing detection.
Connected to a CDS voltage divider for daytime/night auto-detection. Low input to this pin
can disable PIR input. CDS is a schmitt trigger input with 5-second input debounce time.
Mode select, connecting to V
CC
- output always on, connection GND - output always off,
open - auto detection
Power supply
Internal voltage regulator output, 3.6V with respect to ground. Connected to the drain of
PIR sensor
Chip reset input, active low, kept floating or connected an RC network
Non-inverted input of first operational amplifier, connected directly to source of PIR sensor
Inverted input of first operational amplifier
Output of first operational amplifier
Non-inverted input of second operational amplifier.
Inverted input of second operational amplifier
Output of second operational amplifier
Type
Description
PT0091(04/03)
4
Ver:3
Data Sheet
PT8A2611/2621
PIR Sensor Light Switch Controller
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Functional Descriptions
The PT8A2611 and PT8A2621 are CMOS LSI chips designed
for automatic PIR lamp control. They can operate in 2-wire
configuration for triac applications or in 3-wire configuration
for relay applications.
The PIR sensor detects infrared power variations caused by
motion of a human body and transfer to a voltage variation. If
the PIR output voltage variation conforms to criteria, the lamp
is turned on for an adjustable duration. The PT8A2611 (or
2621) offers three operating modes (ON, AUTO, OFF) which
can be set through a MODE pin. When the device is working
in AUTO mode, the user can override the mode to switch it to
TEST mode or manual ON mode, or return to the AUTO mode
by switching power switch.
OSCS and OSCD Pins
OSCS is a system oscillator I/O pin connected to an external
RC to generate system frequency of 16kHz. OSCD is an output
timing oscillator I/O pin. It’s connected to an external RC to
obtain the desired turn-on duration by selecting various val-
ues of RC or using a variable resistor.F
OSCD
is the frequency of
OSCD pin, output timing can be caculated as the formula:
T
D
= 21504/F
OSCD
CDS Input Circuit
CDS is a CMOS schmitt trigger input pin. It is used to distin-
guish between day time and night time. When the input volt-
age of CDS is high the PIR input is enabled, when CDS low the
PIR input disabled. The input disable-to-enable debounce
time is 5 seconds. Connect this pin to V
CC
when not using it.
The CDS input is ignored by PT8A2611when the TRIAC out-
put is active, however, PT8A2621’s CDS can not be ignored
anytime.
Figure 2. Output Timing Oscillator
T
D
= 21504 / F
OSCD
Figure 1. System Oscillator
R
S
560K
OSCS PT8A2611
/2621
200P
R
D
OSCD PT8A2611
/2621
C
S
C
D
Figure 3. CDS Input Circuit
V
CC
Rp
Schmitt
Driver
CDS
Control
CDS Circuit
PT8A2611/2621
Figure 4. CDS Enable Debounce
CDS
< 5s
> 5s
PIR Enable
Disable
Enable
CDS
Table 1. CDS Pin Function
CDS
LOW
HIGH
PT0091(04/03)
Status
Day Time
Night
PIR
Disabled
Enabled
5
Ver:3
