RM20DLN2403: DescriptionFixed Resistor, Metal Glaze/thick Film, 0.5W, 240000ohm, 200V, 0.5% +/-Tol, -100,100ppm/Cel, 2010,; CategoryPassive components The resistor; File Size310KB，10 Pages; ManufacturerTA-I Technology Co., Ltd.; Environmental Compliance

Download Datasheet Parametric View All

RM20DLN2403 Overview

Fixed Resistor, Metal Glaze/thick Film, 0.5W, 240000ohm, 200V, 0.5% +/-Tol, -100,100ppm/Cel, 2010,

RM20DLN2403 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	924201374
Reach Compliance Code	compliant
Country Of Origin	Taiwan
ECCN code	EAR99
YTEOL	7.9
structure	Chip
JESD-609 code	e3
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package height	0.6 mm
Package length	5 mm
Package form	SMT
Package width	2.5 mm
method of packing	Tape, Paper
Rated power dissipation(P)	0.5 W
resistance	240000 Ω
Resistor type	FIXED RESISTOR
series	RM20 (D TOL)
size code	2010
technology	METAL GLAZE/THICK FILM
Temperature Coefficient	100 ppm/°C
Terminal surface	Tin (Sn) - with Nickel (Ni) barrier
Tolerance	0.5%
Operating Voltage	200 V

RM20DLN2403 Preview

TA-I

1. Scope :

Thick Film Chip Resistors

(Lead-Free for RM20 Series)

page

TRM-200S008F

1/10

This specification applies for the RM20 series of thick film chip resistors made by TA-I.

Conductor :

(Lead-free or with lead )

2. Construction:

Over Coat (Color : Black)

Sn Plating

Resistive Element

Ceramic Substrate

Ni Plating

3. Type Designation:

Product Code

Size

Tolerance

Packaging

103

Nominal

RM : Chip Resistor

Power Rating

Resistance

+N: Lead-Free

TA-I TECHNOLOGY CO., LTD

43R2 = 43.2

B-

D-

0.5%

4 digits, e.g.,:

0.1%

(E-96) 1540 = 154

F-

0=0

G-

20-2010(5025)

1/2W

J-

E-Embossed Tape

3 digits, e.g.,:

(E-24) 103 = 10k

TA-I

4. Dimensions:

Thick Film Chip Resistors

(Lead-Free for RM20 Series)

page

TRM-200S008F

2/10

UNIT: mm

Type

RM20

5.00 0.15

2.50 0.15

0.60 0.30

0.50 0.25

0.60 0.10

Weight/pcs

23mg

5. Ratings & Characteristics :

Type

Power

Rating

at 70

Max.

Rated

Working

Voltage

Max.

T.C.R

Over- Load

(PPM/

Voltage

Resistance Range(

)

℃

)

J( 5%)

E-24

RM20

1/2W

200V

400V

Type

RM20

Rated Current

℃

〜 ℃

Note :

Except for the above standardized products, we also provide the

customized products.

℃

2. Operating Temp(

): : -55

+125

TA-I TECHNOLOGY CO., LTD

THICK FILM CHIP RESISTORS

Max Overload Current

Resistance Range

50m

MAX

Ω ≦＜

400

-9.1

10M R 20M

-9.1

Ω ≦＜

Refer

5.2

200

1M R 10M

100

-560k

-1M

-10M

B( 0.1%)

E-96

D( 0.5%)

E-96

F( 1%)

E-96

G( 2%)

E-24

℃

-10M

TA-I

5.1Derating Curve :

Thick Film Chip Resistors

(Lead-Free for RM20 Series)

page

TRM-200S008F

3/10

accordance with figure 1.

P max.

100

Power ratio ( % )

-55

100

125

Ambient

Figure 1

5.2 Rated Voltage:

The rated voltage is calculated by the following formula:

P*R

Rated Voltage(V)

Rated Power(W)

Resistance Value

(Ω)

E.G. : What is RM20JTN102 the rated voltage ?

RM20JTN102

P:1/2W

;

R:102 = 1K

= 1000

0.5(W) * 1000(

)

= 22.3 (V)

TA-I TECHNOLOGY CO., LTD

℃

For resistors operated at ambient temperature over 70

, power rating shall be derated in

Temp. (

C )

TA-I

Thick Film Chip Resistors

(Lead-Free for RM20 Series)

page

TRM-200S008F

4/10

6. Reliability Tests: (As specified in JIS C 5202)

Test Items

Temperature

Resistance

Coefficient

Reference

standard

〜

Condition of Test

℃

Test Limits

Refer 5.0

JIS-C5202-5.2

-55

+125

Short Time Overload

JIS-C5202-5.5

2.5 X rated voltage

for

5 sec

Intermittent Overload

JIS-C5202-5.8

Load Life

JIS-C5202-7.10

Load Life with Humidity

JIS-C5202-7.9

JIS-C5202-6.11

JIS-C5202—6.1 3mm deflection

Dielectric

Withstanding

JIS-C5202-5.7

Voltage (Voltage Proof)

Insulation Resistance

JIS-C5202-5.6

Applying voltage :

500V for a minute .

Applying voltage 100V for 1 minute.

No abnormalities such as

flashover,

burning

dielectric

breakdown shall appear.

TA-I TECHNOLOGY CO., LTD

℃ ±

Resistance to Solder Heat

JIS-C5202-6.10

270

solder , 10

1 sec dwell .

0.5%,1%: (0.5%+0.05 )

2%, 5%: (1.0%+0.05 )

0 :

50m

or less

℃ ±

Resistance to Dry Heat

JIS-C5202-7.2

125 5

for 96 4Hrs

0 :

50m

or less

0.5%,1% : (1.0%+0.05

2%,5% : (2.0%+0.1 )

0 :

50m

Robustness

(Bending)

Termination

or less

≧

℃ ±

Solderability

245 5

solder, 2 0.5 sec dwell.

Solder : Sn96.5 / Ag3.0 / Cu0.5

At least 95% of surface area

of electrode shall be covered

with new solder.

0.5%,1%: (0.5%+0.05 )

2%,5%: (1.0%+0.05 )

℃

Rapid Change of Temperature

JIS-C5202-7.4

-55

(30 min. ) / +155

(30 min. ) 5 cycles

0.5%,1% : (0.5%+0.05 )

2%, 5% : (1.0%+0.05 )

50m

or less

1000 hours at rated voltage , 40 2 ,

90~95% RH 1.5hours “ON “, 0.5hour “OFF”

℃ ±

0.5%,1%: (1.0%+0.05 )

2%, 5%: (3.0%+0.1 )

: 100m

or less

Without mechanical damage

100m

or less

℃

1000 hours at rated voltage, 70

“ON “, 0.5hour “OFF”

, 1.5hours

0.5%,1%: (1.0%+0.05

2%,5%: (3.0%+0.1 )

50m

3.0 X rated voltage or Max Overloading

voltage ,1sec “ON” , 25sec “OFF” , 10000 cycles

(5.0% + 0.1

)

or less

: 50m

(1% + 0.05

)

or les

)

TA-I

Thick Film Chip Resistors

(Lead-Free for RM20 Series)

page

TRM-200S008F

5/10

Component , Lead-Free Soldering part 8 :

Solder Heat Resistance Test for SMD. Lead-

Free Soldering “

Temp. Cycles :

-35

/ 125

, Keep 7 min

Testing duration : 500 4 hours

Temp. Humidity Chambers:

Temperature : 85

Humidity : 85% RH

Testing duration : 500 4 hours

℃

Whisker

SONY

SS-00254-8

Whisker formation :

50 um or less .

Component , Lead-Free Soldering part 5 :

Solder Heat Resistance Test for SMD. Lead-

Free Soldering “

Flow Solder :

Pre – heat : 100 to 105

30 5 sec

10 +1/ -0 sec

Temperature : 260 3

The entire sample shall be dipped in solder.

The specimen shall be stored at standard

atmospheric conditions for 1 hour .

Iron Solder :

Bit temperature : 350 10

Application time of soldering iron : 3 +1/- 0sec

Apply the soldering iron to the electrode .

The specimen shall be stored at standard

atmospheric conditions for 1 hour , after

which the measurements shall be made

℃

℃ ±

Resistance to Solder Heat

SONY

SS-00254-5

Electrical characteristics shall be

Satisfied .

Without distinct deformation in

appearance

Note* : RCWV : Rated continuous working voltage

7. Marking :

7.1

2% &

5%(E24)

Resistance value is expressed by 3 digits, the first two digits represent the significant figures of

nominal resistance value in

, and the third digit represents exponent for base of 10.

Resistance value is expressed by 4 digits or 3digits , the first three digits represent the significant

figures of nominal resistance value in

The resistance value by 3 digits is requirement for customer.

7.3

1%( E96/3digital )

E.G. :

7.2

1% (E96 )

4701 = 470 10

4700

E.G. :,

472

= 47 10

= 4700

= 4.7K

, and the fourth digit represents exponent for base of 10.

4.7K

TA-I TECHNOLOGY CO., LTD
