TE4Q4TATG5002F Overview

fixed inductors toroid 50k MH 1%

TE4Q4TATG5002F Parametric

Parameter Name	Attribute value
Manufacture	Vishay
Product Category	Fixed Inductors
RoHS	N
Inductance	50 mH
Maximum DC Resistance	2.1 Ohms

Preview

Download Datasheet

View All

TE, TD

Vishay Dale

Filter Inductors, Toroid, Radial Leaded

FEATURES

• Choice of encapsulated (TE) or dipped (TD) styles

• TD style combines low cost with excellent

performance in commercial applications

• High Q and wide selection of Q vs. frequency

ranges in one small package. Large number of

standard inductance values

• Compliant to RoHS directive 2002/95/EC

STANDARD ELECTRICAL SPECIFICATIONS

(applies to core only)

MODEL

TE-3

TD-3

TE-4

TD-4

TE-5

TD-5

CODE

(1)

TEMPERATURE

COEFFICIENT

0%±1%

0 % ± 0.1 %

+ 40 ppm/°C to + 110 ppm/°C

+ 85 ppm/°C to + 185 ppm/°C

0 ± 0.25 %

50 ppm/°C (typical)

0 % ± 0.25 %

TEMPERATURE

RANGE

- 55 °C to + 125 °C

0 °C to + 55 °C

- 55 °C to + 25 °C

+ 25 °C to + 85 °C

- 65 °C to + 125 °C

- 55 °C to + 85 °C

TC AVAILABILITY

Note

(1)

Inverse of typical temperature coefficient of polystyrene capacitor

ELECTRICAL SPECIFICATIONS

INDUCTANCE RANGE

CODE

TE-3

TD-3

50 μH to 15 mH

500 μH to 487 mH

1 mH to 1 H

TE-4

TD-4

1 mH to 2 H

2 mH to 5 H

TE-5

TD-5

5 mH to 2 H

10 mH to 5 H

150 μH to 20 mH 1 mH to 100 mH

Tolerance:

TE-3, TD-3 = ± 1 % > 2 mH, ± 2 % 154 μH to 2 mH, ± 5 % < 150 μH

TE-4, TD-4 = ± 1 % > 2 mH, ± 2 % < 2 mH

TE-5, TD-5 = ± 1 % > 2 mH, ± 2 % < 2 mH

Insulation Resistance:

1000 M minimum

Dielectric Strength:

1000 V minimum (TE)

500 V minimum (TD)

DIMENSIONS

in inches [millimeters]

A Dia.

Max.

F Dia. Max.

C Min.

Min.

A Dia.

Max.

0.375 ± 0.125

[9.53 ± 3.18]

MECHANICAL SPECIFICATIONS

Terminal Strength:

2 pounds pull test (TE)

Vibration:

per MIL-T-27 (TE)

Shock:

per MIL-T-27 (TE)

Weight:

TE-3 = 5.1 g, TD-3 = 4.9 g typical

TE-4 = 20 g, TD-4 = 17 g typical

TE-5 = 53 g, TD-5 = 52 g typical

F Min.

Dia.

MODEL

TE-3

TD-3

TE-4

TD-4

TE-5

TD-5

MATERIAL SPECIFICATIONS

Coating:

vinyl (TD), non-flammable, abrasion and moisture

resistant. Resists most cleaning agents (consult factory for

chemicals which may be used)

Standard Terminals:

tinned copper (TE), stranded, tinned

copper, teflon insulated (TD)

Encapsulant:

epoxy (TE)

Gauge:

TE-3 = 22 AWG, TD-3 = 26 AWG

TE-4 = 20 AWG, TD-4 = 24 AWG

TE-5 = 20 AWG, TD-5 = 24 AWG

Document Number: 34078

Revison: 04-Nov-09

0.685 0.385

[17.40] [9.78]

0.685 0.320

[17.40] [8.13]

1.0

0.025 0.500 0.093 0.250

[25.40] [0.635] [12.70] [2.36] [6.35]

3.0

[76.20]

0.125

[3.18]

1.06 0.500

1.0

0.032 0.900 0.120 0.450

[26.92] [12.70] [25.40] [0.813] [22.86] [3.05] [11.43]

1.06 0.437

4.0

[26.92] [11.10] [101.60]

0.220

[5.59]

1.33 0.735

1.0

0.032

1.0 0.144 0.500

[33.78] [18.67] [25.40] [0.813] [25.40] [3.66] [12.70]

1.32 0.688

6.0

[33.53] [17.48] [152.40]

0.220

[5.59]

www.vishay.com

For technical questions, contact:

magnetics@vishay.com
