BGR10TY240J

Description
Fixed Resistor, Wire Wound, 10W, 24ohm, 5% +/-Tol, 250ppm/Cel, Through Hole Mount, RADIAL LEADED
CategoryPassive components    The resistor
File Size361KB,5 Pages
ManufacturerKOA
Environmental Compliance
Download Datasheet Parametric View All

BGR10TY240J Overview

Fixed Resistor, Wire Wound, 10W, 24ohm, 5% +/-Tol, 250ppm/Cel, Through Hole Mount, RADIAL LEADED

BGR10TY240J Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
Objectid720359938
package instructionRADIAL LEADED
Reach Compliance Codecompliant
ECCN codeEAR99
YTEOL7
Other featuresFLAME PROOF
structureRectangular
JESD-609 codee3
lead spacing35 mm
Installation featuresTHROUGH HOLE MOUNT
Number of terminals2
Maximum operating temperature275 °C
Minimum operating temperature-40 °C
Package height9.5 mm
Package length48 mm
Package formRadial
Package width9.5 mm
method of packingBULK
Rated power dissipation(P)10 W
Rated temperature70 °C
resistance24 Ω
Resistor typeFIXED RESISTOR
surface mountNO
technologyWIRE WOUND
Temperature Coefficient250 ppm/°C
Terminal surfaceTin (Sn)
Terminal shapeFLAT
Tolerance5%
Operating Voltage15.492 V
BGR, BWR, BSR
rectangular type wirewound resistors with glass core
rectangular type wirewound resistors with ceramic core
rectangular type metal oxide film resistors
features
EU
High power resistor
Use flame-retardant insulated ceramic case
Products with lead-free terminations meet
EU RoHS requirements. EU RoHS regulation
is not intended for Pb-glass contained in electrode,
resistor element and glass.
Excellent with anti-pulse and inrush current
leaded
resistors
applications and ratings
Type
BWR1
BWR2
BWR3
BWR5
BWR7
BWR10
BWR15
BWR20
BGR5
BGR7
BGR10
BGR15
BGR20
BGR30
BGR40
BSR2
BSR3
BSR5
BSR7
BSR10
BSR15
BSR20
Power
Rating
1W
2W
3W
5W
7W
10W
15W
20W
5W
7W
10W
15W
20W
30W
40W
2W
3W
5W
7W
10W
15W
20W
Resistance Range (Ω) E24
F±1%
1~56
1~160
1~300
1~300
1~360
1~390
1~390
1~390
G±2%
0.22~75
0.22~200
0.22~390
0.22~390
0.22~390
0.22~390
0.22~390
0.22~390
J±5%
0.1~75
0.1~200
0.1~390
0.1~390
0.1~390
0.1~390
0.1~390
0.1~390
10~390
10~390
10~390
10~390
10~390
10~390
10~390
430~13k
430~27k
430~51k
430~56k
430~75k
430~56k
430~56k
K±10%
0.39~9.1
0.39~9.1
0.39~9.1
0.51~9.1
0.51~9.1
2.2~9.1
2.2~9.1
S
1.3
2.1
3.9
5.1
7.5
10.2
18.8
23.3
2.1
3.9
5.1
7.4
10.2
18.8
23.3
N
3.9
5.9
7.2
10.8
15.0
3.8
5.9
7.2
10.8
15.0
E
5.7
5.7
P
5.6
X
Style & Weight (g/1 piece)
Y
YS
Z
7.6
9.1
11.4
20.5
24.0
7.6
9.1
11.4
20.5
24.0
H
9.9
18.4
21.9
59.3
70.4
10.9
18.4
21.9
Q
6.2
7.8
10.7
18.6
22.1
59.6
70.6
6.2
7.8
10.7
18.6
22.1
HA
13.6
24.4
27.9
73.9
85.0
13.7
24.4
27.9
HB
27.5
31.0
73.5
84.6
27.5
31.0
QA
14.5
24.6
28.1
74.2
85.2
14.5
24.6
28.1
QB
27.7
31.3
73.8
84.8
27.7
31.3
6.1 7.6 6.6
8.2 9.1 7.8
11.0 12.4 10.4
18.8 —
22.3 —
6.1 7.6 6.6
8.2 9.1 7.8
11.0 12.4 10.4
18.5 —
22.0 —
Type
BWR1
B R2
B R3
B R5
B R7
B R10
B R15
B R20
BGR30
BGR40
Power
Rating
1W
2W
3W
5W
7W
10W
15W
20W
30W
40W
Max. Working Voltage
(V)
BSR
BGR,BWR
250
300
350
500
E=√P•R
700
700
750
Max. Overload Voltage
(V)
BGR,BWR
BSR
500
600
700
1000
E=√P•R•10
1400
1400
1500
T.C.R. (x10
-6
/K)
BWR
BSR
BGR
Rated
Operating
Ambient Temperature
Temperature
Range
+70°C
±100
±300
±250
+25°C
-40°C
to
+155°C
Rated voltage=
√Power
Rating × Resistance value or Max. working voltage, whichever is lower.
Represents the space to designate product type via character G, W, or S.
Please consult with us in advance about custom-made products.
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
6/26/20
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
183
