QPDF-320-32 datasheet, PDF - EEWORLD Datasheet

QPDF-320-32: Description320Watts Single Output; File Size442KB，2 Pages; ManufacturerQualtek

Download Datasheet View All

QPDF-320-32 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	QPDF-320-32	-	-	View	Buy Now

QPDF-320-32 Overview

320Watts Single Output

Preview

Download Datasheet

View All

320Watts Single Output

ualtek

P C

Electronics Corporation

QPDF-320 Series

Features:

Universal AC input/ Full range

Built-in active PFC function, PF>0.93

High Efficiency, and High Reliability

Output Protections: OLP/OTP/OVP/SCP

Wide operating ambient temperature (-20°C~65°C)

All using 105°C long life electrolytic capacitors.

100% full load burn-in test

Model

DC Output

Rated Current

Current Range

Ripple and

Noise

0~65°C

-20~0°C

QPDF-320-3.3 QPDF-320-5 QPDF-320-7.5 QPDF-320-12 QPDF-320-24 QPDF-320-32 QPDF-320-36 QPDF-320-48

Output Characteristics

3.3V

60A

0~60A

150mV

180mV

±2.0%

±0.5%

±1.0%

60A

0~60A

150mV

±2.0%

±0.5%

±1.0%

7.5V

40A

0~40A

150mV

±2.0%

±0.5%

±1.0%

12V

25A

0~25A

150mV

±1.0%

±0.3%

±0.5%

24V

13A

0~13A

150mV

±1.0%

±0.5%

32V

10A

0~10A

200mV

±1.0%

±0.2%

±0.5%

36V

8.8A

0~8.8A

200mV

±1.0%

±0.2%

±0.5%

48V

6.7A

0~6.7A

240mV

±1.0%

±0.2%

±0.5%

Voltage ADJ. Range

Voltage Accuracy

Line Regulation

Load Regulation

Set-up Time

Hold-up Time

Temperature Coefficient

Overshoot and Undershoot

±10% of rated output voltage

<2.5s (115VAC input, full load) <1.2s(230VAC input, full load)

5V >14ms (230VAC input, full load) 7.5V/15V/24V/32V/36V/48V >16ms (230VAC input, full load)

±0.05%/°C

<5.0%

88VAC~264VAC

47Hz-63Hz

PF>0.98/115VAC PF>0.93/230VAC

74%

4.0A

<23A@115VAC Cold start <45A@230VAC Cold Start

Input-Output: <0.1mA Input-PG: <0.75mA

105%~135% of rated output current, hiccup mode, auto recovery

85°C ± 5°C (heatsink of power transistor); shut down, auto recover after the temperature decreases

110%~150% of rated output voltage, shut down, re-power on to recover

Long-term mode, auto recovery

-20°C~65°C; 20%~90% RH Non-Condensing

-40°C~85°C: 10%-95% RH Non-Condensing

GB4943-2001; EN60950-1: 2006

Primary-Secondary: 3.0KVAC;≤10mA. Primary-PG: 1.5KVAC;≤10mA. Secondary-PG: 0.5KVDC;≤10mA

≥100M ohms

Compliance to EN55022(CISPR22) Class B

Compliance to EN61000-3-2, 17625.1-2003

Compliance to EN61000-4-2, 3, 4, 5, 6, 8, 11; ENV50204, light industry level, criteria A

More than 100,000Hrs (25°C, Full load)

226.5x115x50mm

12PCS/CTN. G.W: 14kgs

Forced air cooling (built-in DC fan)

Page 1 of 2

Input Characteristics

Voltage Range

Frequency Range

Power Factor (Typical)

Efficiency (Typical)

AC Current (max)

Inrush Current (Typical)

Leakage Current

79%

83%

86%

87%

88%

Protection

Over Load (OLP)

Over Temperature (OTP)

Over Voltage (OVP)

Short Circuit (SCP)

Operating Amb. Temp. & Hum

Storage Temp. & Hum

Safety Standards

Withstand Voltage

Isolation Resistance

EMI Conduction & Radiation

Harmonic Current

EMS Immunity

MTBF (MIL-HDBK-217F)

Dimension (LxWxH)

Packing

Cooling Method

Rev. B
