PSN1100A Overview

LOW COST - HIGH PERFORMANCE PHASE LOCKED LOOP

PSN1100A Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Z-Communications, Inc.
package instruction	,
Reach Compliance Code	compli
Humidity sensitivity level	1

Preview

Download Datasheet

View All

PSN1100A

9939 Via Pasar • San Diego, CA 92126

TEL (858) 621-2700 FAX (858) 621-2722

PHASE LOCKED LOOP

Rev A1

PHASE NOISE (1 Hz BW, typical)

-60

-80

-100

FEATURES

• Frequency Range: 1076 - 1130 MHz

• Step Size:

50 KHz

• PLL - Style Package

APPLICATIONS

• Basestations

• Mobile Radios

• Satellite Communications

PERFORMANCE SPECIFICATIONS

Frequency Range

-120

-140

-160

100 Hz

1 kHz

VALUE

1076

1130

-105

-15

-70

3±2

1000

-40 to +85

PLL

Vdc

10 kHz

UNITS

MHz

dBc/Hz

dBc

dBm

100 kHz

Phase Noise @ 10 kHz offset (1 Hz BW, typ.)

Harmonic Suppression (2nd, typ.)

Sideband Spurs (typ.)

Power Output

Load Impedance

Step Size

Charge Pump Output Current

Switching Speed (typ., adjacent channel)

Startup Lock Time (typ.)

Operating Temperature Range

Package Style

Ω

KHz

µΑ

mSec

°C

POWER SUPPLY REQUIREMENTS

Supply Voltage (Vcc, nom.)

Supply Current (Icc, typ.)

All specifications are typical unless otherwise noted and subject to change without notice.

APPLICATION NOTES

•

AN-107

•

AN-200

•

AN-201

: How to Solder Z-COMM VCOs / PLLs

: Mounting and Grounding of Z-COMM PLLs

: PLL Fundamentals

AN-202 : PLL Functional Description

NOTES:

Reference Oscillator Signal: 5 MHz<

o s c

<40 MHz

Frequency Synthesizer: National Semiconductor - LMX2316

Page 1
