05091
PSLC03
thru
Only One Name Means ProT
ek’Tion™
PSLC24C
LOW CAPACIT
ANCE TVS ARRA
Y
APPLICA
TIONS
✔
Ethernet - 10/100 Base T
✔
Cellular Phones
✔
Audio & Video Inputs
✔
FireWire, SCSI & USB Interfaces
IEC COMPA
TIBILITY
(EN61000-4)
✔
61000-4-2 (ESD): Air - 15kV, Contact - 8kV
✔
61000-4-4 (EFT): 40A - 5/50ns
✔
61000-4-5 (Surge): 12A, 8/20µs - Level 1(Line-Gnd) & Level 2(Line-Line)
FEA
TURES
✔
350 Watts Peak Pulse Power per Line (tp=8/20µs)
✔
Unidirectional & Bidirectional Configurations
✔
Available in Multiple Voltage Types Ranging From 3V to 24V
✔
Protects One Line
✔
ESD Protection > 40 kilovolts
✔
Low Clamping Voltage
✔
LOW CAPACITANCE: 10pF
MECHANICAL CHARACTERISTICS
✔
Molded JEDEC SOT-143 Package
✔
Weight 10 milligrams (Approximate)
✔
Flammability rating UL 94V-0
✔
8mm Tape and Reel Per EIA Standard 481
✔
Marking: Marking Code
SOT-143
PIN CONFIGURA
TIONS
UNIDIRECTIONAL
BIDIRECTIONAL
1
4
1
4
2
3
2
3
05091.R5 8/03
1
www.protekdevices.com
PSLC03
thru
PSLC24C
DEVICE CHARACTERISTICS
MAXIMUM RATINGS @ 25°C Unless Otherwise Specified
PARAMETER
Peak Pulse Power (t
p
= 8/20µs) - See Figure 1
Operating Temperature
Storage Temperature
SYMBOL
P
PP
T
J
T
STG
VALUE
350
-55°C to 150°C
-55°C to 150°C
UNITS
Watts
°C
°C
ELECTRICAL CHARACTERISTICS PER LINE @ 25°C Unless Otherwise Specified
PART
NUMBER
(See Notes 1-2)
DEVICE
MARKING
RATED
STAND-OFF
VOLTAGE
MINIMUM
BREAKDOWN
VOLTAGE
MAXIMUM
CLAMPING
VOLTAGE
(See Fig. 2)
@ I
P
= 5A
V
C
VOLTS
9.0
9.0
11.0
11.0
16.6
16.6
24.0
24.0
30.0
30.0
N/A
N/A
MAXIMUM
CLAMPING
VOLTAGE
(See Fig. 2)
MAXIMUM
LEAKAGE
CURRENT
MAXIMUM
CAPACITANCE
V
WM
VOLTS
PSLC03
PSLC03C
PSLC05
PSLC05C
PSLC08
PSLC08C
PSLC12
PSLC12C
PSLC15
PSLC15C
PSLC24
PSLC24C
3U
3B
5U
5B
8U
8B
12U
12B
15U
15B
24U
24B
3.3
3.3
5.0
5.0
8.0
8.0
12.0
12.0
15.0
15.0
24.0
24.0
@ 1mA
V
(BR)
VOLTS
4.0
4.0
6.0
6.0
8.5
8.5
13.3
13.3
16.6
16.6
26.7
26.7
@8/20µs
V
C
@ I
PP
19.0V @ 20.0A
19.0V @ 20.0A
18.3V @ 17.0A
18.3V @ 17.0A
18.5V @ 17.0A
18.5V @ 17.0A
28.6V @ 11.0A
28.6V @ 11.0A
31.8V @ 10.0A
31.8V @ 10.0A
56.0V @ 6.0A
56.0V @ 6.0A
@V
WM
I
D
µA
125
125
20
20
10
10
1
1
1
1
1
1
0V @ 1 MHz
C
pF
10
10
10
10
10
10
10
10
10
10
10
10
Note 1:
Part numbers with an additional “C” suffix are bidirectional devices, i.e., PSLC05C.
Note 2:
Unidirectional Only:
Positive potential is applied from pin 2 to 1 or pin 3 to 4.
10,000
P
PP
- Peak Pulse Power - Watts
FIGURE 1
PEAK PULSE POWER VS PULSE TIME
I
PP
- Peak Pulse Current - % of I
PP
120
100
80
60
40
20
0
t
f
FIGURE 2
PULSE WAVE FORM
Peak Value I
PP
TEST
WAVEFORM
PARAMETERS
t
f
= 8µs
t
d
= 20µs
1,000
350W 8/20µs Waveform
e
-t
100
t
d
= t I /2
PP
10
0.1
1
10
100
t
d
- Pulse Duration - µs
1,000
10,000
0
5
10
15
t - Time - µs
20
25
30
05091.R5 8/03
2
www.protekdevices.com
PSLC03
thru
PSLC24C
GRAPHS
FIGURE 3
POWER DERATING CURVE
40
Peak Pulse Power
8/20µs
5 Volts per Division
100
80
% Of Rated Power
FIGURE 4
OVERSHOOT & CLAMPING VOLTAGE FOR PSLC03
30
60
20
40
20
Average Power
0
0
25
50
75
100
125
T
L
- Lead Temperature - °C
150
10
0
ESD Test Pulse: 5 kilovolt, 1/30ns (waveform)
FIGURE 5
INSERTION LOSS - PSLC05
FIGURE 6
RETURN LOSS - PSLC05
20 db
10 db per Division
10 db per Division
20 db
Ref 0 db
Ref 0 db
-20 db
-20 db
-50 db
100 MHz per Division
-50 db
100 MHz per Division
05091.R5 8/03
3
www.protekdevices.com
PSLC03
thru
PSLC24C
APPLICA
TION NOTE
The PSLC Series are TVS arrays designed to protect I/O or data lines from the damaging effects of ESD and EFT. This product series provides both
unidirectional and bidirectional protection, with a surge capability of 350 Watts P
PP
per line for an 8/20µs waveform and ESD protection > 40kV.
UNIDIRECTIONAL COMMON-MODE CONFIGURATION (Figure 1)
The two PSLC Series devices provide protection in a common-mode
configuration as depicted in Figure 1.
Circuit connectivity is as follows:
✔
TVS Device 1: Line 1(D+) is connected to Pins 2 & 3.
✔
TVS Device 2: Line 2(D-) is connected to Pins 2 & 3.
✔
Both TVS Devices: Pins 1 & 4 connected to ground.
Figure 1 - Unidirectional Configuration (Two TVS Devices)
Common-Mode USB Protection
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
1
4
1
4
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
GND
SOLDER PAD
2
USB OUTPUT CONNECTOR
3
2
3
USB IC
D+
D-
BIDIRECTIONAL DIFFERENTIAL-MODE CONFIGURATION (Figure 2)
The PSLCxxC Series provides protection in a differential-mode configuration
as depicted in Figure 2.
Circuit connectivity is as follows:
✔
Line 1(R
X
) is connected to Pins 1 & 4.
✔
Line 2(T
X
) is connected to Pins 2 & 3.
Figure 2 - Bidirectional Configuration
Differential-Mode Ethernet Protection
ETHERNET TRANSCEIVER
CIRCUIT BOARD LAYOUT RECOMMENDATIONS
Circuit board layout is critical for Electromagnetic
Compatibility (EMC) protection. The following
guidelines are recommended:
✔
The protection device should be placed near the
input terminals or connectors, the device will
divert the transient current immediately before it
can be coupled into the nearby traces.
The path length between the TVS device and the
protected line should be minimized.
All conductive loops including power and ground
loops should be minimized.
The transient current return path to ground
should be kept as short as possible to reduce
parasitic inductance.
Ground planes should be used whenever
possible. For multilayer PCBs, use ground vias.
R
X
R
1
4
RJ-45
R
2
T
X
3
✔
✔
✔
✔
05091.R5 8/03
4
www.protekdevices.com
PSLC03
thru
PSLC24C
PACKAGE OUTLINE & DIMENSIONS
PACKAGE OUTLINE
SOT-143
A
G
L
B
S
J
PACKAGE DIMENSIONS
DIM
MILLIMETERS
MIN
MAX
2.80
1.20
0.84
0.39
0.79
1.78
0.013
0.08
0.46
0.445
0.72
2.11
3.04
1.39
1.14
0.50
0.93
2.03
0.10
0.15
0.60
0.60
0.83
2.48
INCHES
MIN
MAX
0.110
0.047
0.033
0.015
0.031
0.070
0.0005
0.003
0.018
0.0175
0.028
0.083
0.0120
0.055
0.045
0.020
0.037
0.080
0.004
0.006
0.024
0.024
0.033
0.098
K
F
D
H
C
A
B
C
D
F
G
H
J
K
L
R
S
R
MOUNTING PAD
TYPICAL
DIM Millimeters
1
2
3
4
5
6
7
8
9
10
11
2.85
2.00
1.80
1.90
1.05
2.75
1.20
0.80
0.85
0.85
0.85
Inches
0.112
0.079
0.071
0.075
0.041
0.108
0.047
0.031
0.033
0.033
0.033
2
10
4
5
11
6
1
NOTES
1. Dimensioning and tolerances per ANSI Y14.5M, 1985.
2. Controlling Dimension: Inches
3. Dimensions are exclusive of mold flash and metal burrs.
TAPE & REEL ORDERING NOMENCLATURE
1. Surface mount product is taped and reeled in accordance
with EIA-481.
2. Suffix-T7 = 7 Inch Reel - 3,000 pieces per 8mm tape,
i.e.,
PSLC05-T7.
3. Suffix-T13 = 13 Inch Reel - 10,000 pieces per 8mm tape,
i.e.,
PSLC05-T13.
3
7
8
9
Outline & Dimensions: Rev 1 - 11/01, 06011
COPYRIGHT © ProTek Devices 2003
SPECIFICATIONS: ProTek reserves the right to change the electrical and or mechanical
characteristics described herein without notice (except JEDEC).
DESIGN CHANGES: ProTek reserves the right to discontinue product lines without notice, and that
the final judgement concerning selection and specifications is the buyer’s and that in furnishing
engineering and technical assistance, ProTek assumes no responsibility with respect to the
selection or specifications of such products.
ProTek Devices
2929 South Fair Lane, Tempe, AZ 85282
Tel: 602-431-8101 Fax: 602-431-2288
E-Mail:
sales@protekdevices.com
Web Site:
www.protekdevices.com
05091.R5 8/03
5
www.protekdevices.com
