D Subminiature
40 A High power straight – European solder pins, sizes DE – DC
Part numbers with straight contacts
Shell
size
Layout
with standoff M3
with standoff M3 with pushfit
standoff, M3 post and pushfit
Combo D
®
/European Version
with M3 clinch nut
with through hole 3,05 mm
DE
DA
DA
DA
DA
DB
DB
DB
DB
DB
DC
DC
DC
DC
DC
DC
5W1
7W2
11W1
3W3
3WK3
5W5
9W4
13W3
17W2
21W1
8W8
13W6
17W5
21WA4
25W3
27W2
DEMT-5H1S-OL4-A191-A197
DAMT-7H2S-OL4-A191-A197
DAMT-11H1S-OL4-A191-A197
DAMT-3H3S-OL4-A191-A197
DAMT-3HK3S-OL4-A191-A197
DBMT-5H5S-OL4-A191-A197
DBMT-9H4S-OL4-A191-A197
DBMT-13H3S-OL4-A191-A197
DBMT-17H2S-OL4-A191-A197
DBMT-21H1S-OL4-A191-A197
DCMT-8H8S-OL4-A191-A197
DCMT-13H6S-OL4-A191-A197
DCMT-17H5S-OL4-A191-A197
DCMT-21HA4S-OL4-A191-A197
DCMT-25H3S-OL4-A191-A197
DCMT-27H2S-OL4-A191-A197
DEMQ-5H1S-OL4-A191-A197
DAMQ-7H2S-OL4-A191-A197
DAMQ-11H1S-OL4-A191-A197
DAMQ-3H3S-OL4-A191-A197
DAMQ-3HK3S-OL4-A191-A197
DBMQ-5H5S-OL4-A191-A197
DBMQ-9H4S-OL4-A191-A197
DBMQ-13H3S-OL4-A191-A197
DBMQ-17H2S-OL4-A191-A197
DBMQ-21H1S-OL4-A191-A197
DCMQ-8H8S-OL4-A191-A197
DCMQ-13H6S-OL4-A191-A197
DCMQ-17H5S-OL4-A191-A197
DCMQ-21HA4S-OL4-A191-A197
DCMQ-25H3S-OL4-A191-A197
DCMQ-27H2S-OL4-A191-A197
DEMU-5H1S-OL4-A191-A197
DAMU-7H2S-OL4-A191-A197
DAMU-11H1S-OL4-A191-A197
DAMU-3H3S-OL4-A191-A197
DAMU-3HK3S-OL4-A191-A197
DBMU-5H5S-OL4-A191-A197
DBMU-9H4S-OL4-A191-A197
DBMU-13H3S-OL4-A191-A197
DBMU-17H2S-OL4-A191-A197
DBMU-21H1S-OL4-A191-A197
DCMU-8H8S-OL4-A191-A197
DCMU-13H6S-OL4-A191-A197
DCMU-17H5S-OL4-A191-A197
DCMU-21HA4S-OL4-A191-A197
DCMU-25H3S-OL4-A191-A197
DCMU-27H2S-OL4-A191-A197
DEMX-5H1S-OL4-A191-A197
DAMX-7H2S-OL4-A191-A197
DAMX-11H1S-OL4-A191-A197
DAMX-3H3S-OL4-A191-A197
DAMX-3HK3S-OL4-A191-A197
DBMX-5H5S-OL4-A191-A197
DBMX-9H4S-OL4-A191-A197
DBMX-13H3S-OL4-A191-A197
DBMX-17H2S-OL4-A191-A197
DBMX-21H1S-OL4-A191-A197
DCMX-8H8S-OL4-A191-A197
DCMX-13H6S-OL4-A191-A197
DCMX-17H5S-OL4-A191-A197
DCMX-21HA4S-OL4-A191-A197
DCMX-25H3S-OL4-A191-A197
DCMX-27H2S-OL4-A191-A197
DEM-5H1S-OL4-A191-A197
DAM-7H2S-OL4-A191-A197
DAM-11H1S-OL4-A191-A197
DAM-3H3S-OL4-A191-A197
DAM-3HK3S-OL4-A191-A197
DBM-5H5S-OL4-A191-A197
DBM-9H4S-OL4-A191-A197
DBM-13H3S-OL4-A191-A197
DBM-17H2S-OL4-A191-A197
DBM-21H1S-OL4-A191-A197
DCM-8H8S-OL4-A191-A197
DCM-13H6S-OL4-A191-A197
DCM-17H5S-OL4-A191-A197
DCM-21HA4S-OL4-A191-A197
DCM-25H3S-OL4-A191-A197
DCM-27H2S-OL4-A191-A197
For performance class 1 replace A191 with A190.
For performance class 3 delete A191.
For standoff 4-40 UNC thread replace T with V.
For standoff, 4-40 UNC thread post and pushfit replace U
with N.
For 4-40 UNC thread standoff with pushfit replace Q
with Z.
For captive nut 4-40 UNC replace X with E.
Socket
A
C
B
Ø 0,6
6,15
±0,3
A2
2
1
A1
D
7W2S
5
ITT
4
3
CANNON
q
q
q
q
For contact cavity arrangements, see page 53.
For pcb hole pattern, see page 72 – 75.
For mounting methods, see page 86 – 87.
For panel cut-outs, see our D Subminiature
catalogue.
10
°
E
Ø 3,18
L
Dimensions
Shell
size
A
±
0,38
B
±
0,13
C
±
0,13
D
±
0,13
E
±
0,13
F
±
0,25
10,9
10,9
10,9
10,9
L
+
0,2
W
±
0,4
DE
DA
DB
DC
30,8
39,15
53,05
69,3
16,35
24,65
38,4
54,85
25
33,3
47.05
63,5
7,9
7,9
7,9
7,9
12,55
12,55
12,55
12,55
0,8
0,8
0,8
0,8
6,95
6,95
6,95
6,95
W
F
27
