Module no:3026667 LabelId:3026667 Operator:Phoenix
19:01:04, Donnerstag, 28. Juni 2001
ZFKKB 2,5-PE
Z
Terminal width 5.2
(IEC)
[mm ]
IEC 947-7-2
2
rigid
solid
0.2-4
flexible
stranded AWG
0.2-2.5
24-12
For current carrying capacity of mounting rails, (see
info)
Dimensions
Spring cage terminal
block,
for mounting on
3
Accessories
(1)
End cover
gray
D-ZFKKB 2,5
30 02 82 7
50
Color
green-
yellow
Type
ZFKKB 2,5-PE
Order No.
30 26 66 7
Pcs.
Pkt.
50
(2)
Insulating stop sleeve,
prevents
unintentional clamping of insulation in
the case of smaller cross sections
Cross section
range:
0.2 mm
0.25-0.5 mm
0.75-1 mm
(8)
Screwdriver,
for
actuating the tension spring
(9)
Actuation tool,
for
actuating the tension spring
(10)
Zack marker sheet,
flat,
100 or 120-section, for labeling
the outer marker grooves
(11)Zack
strip,
10-section, for
labeling in the terminal center
and on the plug-in bridges
Technical data
Dimensions
Width / length / end cover width
Height (NS 35:7.5 / NS 35:15)
Rated surge voltage / contamination class
Surge voltage category / insulation material
group
[mm]
[mm]
[kV] / –
–/–
5.2 / 96 / 2
49 / 56.5
6/3
III / I
white
2-pos.
3-pos.
2
2
2
white
gray
black
ISH 2,5/0,2
ISH 2,5/0,5
ISH 2,5/1
SZF 1 - 0,6 x 3,5
ZFK-BW 2-5
ZFK-BW 3-5
ZBFM 5
(see
info)
30 02 84 3
30 02 85 6
30 02 86 9
12 04 51 7
30 24 28 7
30 24 29 0
50
50
50
10
1
1
ZB 5
(see
info)
Technical data in accordance with IEC / DIN VDE
Phoenix Contact Elektronischer Katalog
Page 1 / 2
Module no:3026667 LabelId:3026667 Operator:Phoenix
Connection capacity
Stranded with ferrule with plastic sleeve
Stranded with ferrule without plastic sleeve
Stranded with TWIN ferrule with plastic
sleeve
Stripping length
Internal cylindrical gauge (IEC 60 947-1)
Insulation material
Inflammability class acc. to UL 94
[mm ]
[mm ]
[mm ]
[mm]
2
2
2
19:01:04, Donnerstag, 28. Juni 2001
0.25 - 2.5
0.25 - 2.5
0,5
10
A3
PA
V0
Phoenix Contact Elektronischer Katalog
Page 2 / 2
