MCS 0402, MCT 0603, MCU 0805, MCA 1206 - Precision
Vishay Beyschlag
Precision Thin Film Chip Resistors
FEATURES
•
•
•
•
•
•
•
•
•
•
Approved according to EN 140401-801
Low TCR: ± 10 ppm/K to ± 25 ppm/K
Precision tolerance of value: ± 0.1 % and ± 0.25 %
Superior overall stability: Class 0.1 and 0.25
Lead (Pb)-free solder contacts
Compliant to RoHS directive 2002/95/EC
APPLICATIONS
Thin Film Flat Chip Resistors combine the proven reliability
of the professional products with an advanced level of
precision and stability. Therefore they are perfectly suited for
applications in the fields of test and measuring equipment
together with industrial and medical electronics.
Automotive
Test and measuring equipment
Medical equipment
Industrial equipment
METRIC SIZE
INCH:
METRIC:
0402
RR 1005M
0603
RR 1608M
0805
RR 2012M
1206
RR 3216M
TECHNICAL SPECIFICATIONS
DESCRIPTION
Metric size
Resistance range
Resistance tolerance
Temperature coefficient
Operation mode
Climatic category (LCT/UCT/days)
Rated dissipation,
P
70 (1)
Operating voltage,
U
max.
AC/DC
Film temperature
Max. resistance change at
P
70
for resistance range,
|ΔR/R|
max., after:
1000 h
8000 h
225 000 h
Specified lifetime
Insulation voltage:
1 min;
U
ins
Continuous
Failure rate: FIT
observed
Note
(1)
The
MCS 0402
RR 1005M
100
Ω
to 221 kΩ
MCT 0603
RR 1608M
39
Ω
to 511 kΩ
MCU 0805
RR 2012M
39
Ω
to 1.5 MΩ
MCA 1206
RR 3216M
39
Ω
to 2 MΩ
± 0.25 %; ± 0.1 %
± 25 ppm/K; ± 15 ppm/K; ± 10 ppm/K
Precision
10/85/56
0.016 W
12.5 V
85 °C
Standard
55/125/56
0.063 W
50 V
125 °C
Precision
10/85/56
0.032 W
25 V
85 °C
Standard
55/125/56
0.1 W
75 V
125 °C
Precision
10/85/56
0.050 W
35 V
85 °C
Standard
55/125/56
0.125 W
150 V
125 °C
Precision
10/85/56
0.1 W
50 V
85 °C
Standard
55/125/56
0.25 W
200 V
125 °C
100
Ω
to 221 kΩ
≤
0.1 %
≤
0.2 %
≤
0.5 %
≤
0.2 %
≤
0.4 %
≤
1.0 %
39
Ω
to 511 kΩ
≤
0.1 %
≤
0.2 %
≤
0.5 %
≤
0.2 %
≤
0.4 %
≤
1.0 %
39
Ω
to 1.5 MΩ
≤
0.1 %
≤
0.2 %
≤
0.5 %
≤
0.2 %
≤
0.4 %
≤
1.0 %
39
Ω
to 2 MΩ
≤
0.05 %
≤
0.1 %
≤
0.25 %
≤
0.1 %
≤
0.25 %
≤
0.5 %
225 000 h
225 000 h
225 000 h
225 000 h
75 V
75 V
≤
0.1 x 10
-9
/h
100 V
75 V
≤
0.1 x 10
-9
/h
200 V
75 V
≤
0.1 x 10
-9
/h
300 V
75 V
≤
0.1 x 10
-9
/h
power dissipation on the resistor generates a temperature rise against the local ambient, depending on the heat flow support of the
printed-circuit board (thermal resistance). The rated dissipation applies only if the permitted film temperature is not exceeded.
For technical questions, contact:
thinfilmchip@vishay.com
Document Number: 28700
Revision: 18-Dec-09
www.vishay.com
208
MCS 0402, MCT 0603, MCU 0805, MCA 1206 - Precision
Precision Thin Film Chip Resistors
Vishay Beyschlag
PART NUMBER AND PRODUCT DESCRIPTION
PART NUMBER: MCT06030D4641BPW00
(1)
M
MODEL/SIZE
MCS0402
MCT0603
MCU0805
MCA1206
C
T
0
6
0
3
TCR
0
D
4
VALUE
6
4
1
B
P
W
0
0
SPECIAL
Up to 2 digits
00
= Standard
SPECIAL CHARACTER
0
= Neutral
TOLERANCE
B
= ± 0.1 %
C
= ± 0.25 %
PACKAGING
P1
P5
PW
E1
E0
F
= ± 10 ppm/K
E
= ± 15 ppm/K
D
= ± 25 ppm/K
3 digit value
1 digit
multiplier
MULTIPLIER
7
= *10
-3
2
= *10
2
8
= *10
-2
3
= *10
3
9
= *10
-1
4
= *10
4
0
= *10
0
5
= *10
5
1
= *10
1
6
= *10
6
PRODUCT DESCRIPTION: MCT 0603 - 25 0.1 % PW 4K64
MCT
MODEL
MCS
MCT
MCU
MCA
0603
SIZE
0402
0603
0805
1206
- 25
TCR
±
10
ppm/K
±
15
ppm/K
±
25
ppm/K
0.1 %
TOLERANCE
±
0.1
%
±
0.25
%
PW
PACKAGING
P1
P5
PW
E1
E0
4K64
RESISTANCE VALUE
47K
= 47 kΩ
50R1
= 50.1
Ω
Note
(1)
Products can be ordered using either the PRODUCT DESCRIPTION or the PART NUMBER
TEMPERATURE COEFFICIENT AND RESISTANCE RANGE
DESCRIPTION
TCR
± 25 ppm/K
± 15 ppm/K
± 10 ppm/K
(3)
TOLERANCE
± 0.25 %
± 0.1 %
± 0.25 %
± 0.1 %
± 0.25 %
± 0.1 %
MCS 0402
100
Ω
to 221 kΩ
150
Ω
to 221 kΩ
100
Ω
to 150 kΩ
150
Ω
to 150 kΩ
100
Ω
to 130 kΩ
150
Ω
to 130 kΩ
RESISTANCE VALUE
(2)
MCT 0603
39
Ω
to 511 kΩ
47
Ω
to 511 kΩ
39
Ω
to 332 kΩ
47
Ω
to 332 kΩ
39
Ω
to 221 kΩ
47
Ω
to 221 kΩ
MCU 0805
39
Ω
to 1.5 MΩ
47
Ω
to 1.5 MΩ
39
Ω
to 1 MΩ
47
Ω
to 1 MΩ
39
Ω
to 511 kΩ
47
Ω
to 511 kΩ
MCA 1206
39
Ω
to 2 MΩ
47
Ω
to 2 MΩ
39
Ω
to 1.5 MΩ
47
Ω
to 1.5 MΩ
39
Ω
to 1 MΩ
47
Ω
to 1 MΩ
Notes
(2)
Resistance values to be selected from E96 and E192 series, other values are available on request
(3)
TCR 10 is specified over the temperature range from - 10 °C to 85 °C
Resistance ranges printed in bold are preferred TCR/tolerance combinations with optimized availability.
PACKAGING
REEL
MODEL
PIECES/
PAPER TAPE ON REEL
1000
10 000
1000
5000
20 000
1000
5000
20 000
1000
5000
For technical questions, contact:
thinfilmchip@vishay.com
CODE
E1
E0
P1
P5
PW
P1
P5
PW
P1
P5
www.vishay.com
209
MCS 0402
MCT 0603
MCU 0805
MCA 1206
Document Number: 28700
Revision: 18-Dec-09
MCS 0402, MCT 0603, MCU 0805, MCA 1206 - Precision
Precision Thin Film Chip Resistors
DESCRIPTION
Production is strictly controlled and follows an extensive
set of instructions established for reproducibility. A
homogeneous film of metal alloy is deposited on a high grade
Al
2
0
3
ceramic substrate and conditioned to achieve the
desired temperature coefficient. Specially designed inner
contacts are deposited on both sides. A special laser is used
to achieve the target value by smoothly fine trimming the
resistive layer without damaging the ceramics. A further
conditioning is applied in order to stabilize the trimming
result. The resistor elements are covered by a blue
protective coating designed for electrical, mechanical and
climatic protection. The terminations receive a final pure tin
on nickel plating.
The result of the determined production is verified by an
extensive testing procedure and optical inspection
performed on 100 % of the individual chip resistors. Only
accepted products are laid directly into the paper tape in
accordance with
IEC 60286-3
(3)
.
Vishay Beyschlag
APPOVALS
The resistors are approved within the IECQ-CECC Quality
Assessment System for Electronic Components to the detail
specification
EN 140401-801
which refers to
EN 60115-1,
EN 140400
and the variety of environmental test procedures
of the
IEC 60068
(3)
series.
Conformity is attested by the use of the
CECC
Logo (
the Mark of Conformity on the package label.
) as
Vishay BEYSCHLAG has achieved
“Approval of
Manufacturer”
in accordance with
IEC QC 001002-3,
clause 2.
The release certificate for
“Technology Approval
Schedule”
in accordance with
CECC 240001
based on
IEC QC 001002-3, clause 6
is granted for the
Vishay BEYSCHLAG manufacturing process.
RELATED PRODUCTS
On request, resistors are available with
established
reliability
in accordance with
EN 140401-801
version E.
Please refer to the special datasheet document no.
28744
for
information on failure rate level, available resistance ranges
and order codes.
For more information about products with higher rated power
and higher operation temperature please refer to the
Professional Thin Film Chip Resistor
datasheet document
no.
28705.
Precision
chip resistor arrays
may be used in voltage
divider applications or precision amplifiers where close
matching between multiple resistors is necessary. Please
refer to the ACAS 0612 - Precision datasheet document no.
28751.
ASSEMBLY
The resistors are suitable for processing on automatic SMD
assembly systems and for automatic soldering using wave,
reflow or vapour phase. The encapsulation is resistant to all
cleaning solvents commonly used in the electronics industry,
including alcohols, esters and aqueous solutions. The
suitability of conformal coatings, if applied, shall be qualified
by appropriate means to ensure the long-term stability of the
whole system.
The resistors are RoHS compliant, the pure tin plating
provides
compatibility
with
lead
(Pb)-free
and
lead-containing soldering processes. Solderability is
specified for 2 years after production or requalification. The
permitted storage time is 20 years. The immunity of the
plating against tin whisker growth has been proven under
extensive testing.
All products comply with the
GADSL
(1)
and the
CEFIC-EECA-EICTA
(2)
list of legal restrictions on
hazardous substances. This includes full compliance with
the following directives:
•
2000/53/EC End of Vehicle life Directive (ELV) an Annex II
(ELV II)
•
2002/95/EC Restriction of the
Substances Directive (RoHS)
use
of
Hazardous
•
2002/96/EC Waste Electrical and Electronic Equipment
Directive (WEEE)
Notes
(1)
(2)
(3)
Global Automotive Declarable Substance List, see
www.gadsl.org
CEFIC (European Chemical Industry Council), EECA (European Electronic Component Manufacturers Association), EICTA (European trade
organisation representing the information and communications technology and consumer electronics), see
www.eicta.org/index.php?id=995
→
issues
→
environment policy
→
chemicals
→
chemicals for electronics
The quoted IEC standards are also released as EN standards with the same number and identical contents
For technical questions, contact:
thinfilmchip@vishay.com
www.vishay.com
211
Document Number: 28700
Revision: 18-Dec-09
