Terminals
Nylon Insulated Fork – Insulation Grip
Cat.
No.
RA18-6F
RA1103
RA18-8F
RA1123
RA18-10F
RA1153
RA18-14F
RA1163
RB14-6F
RB1113
RB14-8F
RB1123
RB14-10F
RB1153
RB14-14F
RB1163
RB1103
RB1124
RB1154
RC10-6F
RC1113
RC10-8F
RC1123
RC10-10F
RC1153
RC10-14F
RC1163
RC1124
RC1154
Pkg.
Qty.
100
1000
100
1000
100
1000
100
1000
100
1000
100
1000
100
1000
100
1000
1000
1000
1000
50
500
50
500
50
500
50
500
500
500
Wire
Range
22-16
22-16
22-16
22-16
22-16
22-16
22-16
22-16
18-14
18-14
18-14
18-14
18-14
18-14
18-14
18-14
18-14
18-14
18-14
12-10
12-10
12-10
12-10
12-10
12-10
12-10
12-10
12-10
12-10
Max.
Ins.
.136
.136
.136
.136
.136
.136
.136
.136
.162
.162
.162
.162
.162
.162
.162
.162
.162
.190
.190
.210
.210
.210
.210
.210
.210
.210
.210
.250
.250
Bolt
Hole
#6
#6
#8
#8
#10
#10
1/4"
1/4"
#6
#6
#8
#8
#10
#10
1/4"
1/4"
#6
#8
#10
#6
#6
#8
#8
#10
#10
1/4"
1/4"
#8
#10
Wt./Lbs.
Per
1000
3
3
3
3
3
3
4
4
3-1/2
3-1/2
3-1/2
3-1/2
4
4
4
4
6
6
6
6
6
6
6
6
6
6
6
6
6
Dimensions
A
.83
.83
.86
.86
.86
.86
.95
.95
.87
.87
.87
.87
.87
.87
.95
.95
.74
.95
.95
.97
.97
1.00
1.00
1.00
1.00
1.12
1.12
1.10
1.10
B
.25
.25
.31
.31
.31
.31
.44
.44
.31
.31
.31
.31
.38
.38
.44
.44
.28
.31
.31
.31
.31
.37
.37
.37
.37
.50
.50
.37
.37
C
.25
.25
.25
.25
.25
.25
.31
.31
.25
.25
.25
.25
.25
.25
.28
.28
.16
.25
.25
.27
.27
.27
.27
.27
.27
.27
.27
.27
.27
M
.71
.71
.71
.71
.71
.71
.70
.70
.71
.71
.71
.71
.71
.71
.74
.74
.60
.79
.79
.81
.81
.81
.81
.81
.81
.86
.86
.91
.91
Fork terminals with nylon insulation sleeves,
recommended for temperatures up to 105°C. Inner
bronze insulation grip sleeve lengthens flex radius
of conductor and eliminates conductor creep. Nylon
jacket is color-coded.
Stock thickness same as ring terminal of same size.
Most standard bulk catalog numbers can be put on
Mylar Tape for reel fed applications (i.e. 12050 tool
and application dies). See pages 190-191.
Please put the suffix M for Mylar Tape RA2573M.
(Bulk number 1000 and 500 packages.)
U.L. Listed E9809
Installing tools: WT145C, WT2000, WT112M, ERG-2001, ERG-2003, WT145A
147
Terminals
Nylon Insulated Fork Flanged Tongue – Insulation Grip
Cat.
No.
RA18-6FS
RA1203
RA18-8FS
RA1223
RA18-10FS
RA1253
RB14-6FS
RB1203
RB14-8FS
RB1223
RB14-10FS
RB1253
RB1204
RB1224
RC10-8FS
RC1223
RC10-10FS
RC1253
RC1224
RC1254
Pkg.
Qty.
100
1000
100
1000
100
1000
100
1000
100
1000
100
1000
1000
1000
50
500
50
500
1000
1000
Wire
Range
22-16
22-16
22-16
22-16
22-16
22-16
18-14
18-14
18-14
18-14
18-14
18-14
18-14
18-14
12-10
12-10
12-10
12-10
12-10
12-10
Max.
Ins.
.136
.136
.136
.136
.136
.136
.162
.162
.162
.162
.162
.162
.190
.190
.210
.210
.210
.210
.250
.250
Bolt
Hole
#6
#6
#8
#8
#10
#10
#6
#6
#8
#8
#10
#10
#6
#8
#8
#8
#10
#10
#8
#10
Wt./Lbs.
Per
1000
3
3
3
3
3
3
4
4
4
4
4
4
4
4
5
5
5
5
5
5
Dimensions
A
.75
.75
.89
.89
.93
.93
.74
.74
.89
.89
.94
.94
.79
.94
.97
.97
1.00
1.00
1.08
1.12
B
.28
.28
.31
.31
.38
.38
.28
.28
.31
.31
.38
.38
.28
.31
.34
.34
.38
.38
.34
.38
C
.16
.16
.23
.23
.26
.26
.16
.16
.23
.23
.27
.27
.16
.23
.23
.23
.26
.26
.23
.26
M
.62
.62
.65
.65
.68
.68
.60
.60
.66
.66
.69
.69
.67
.71
.73
.73
.74
.74
.80
.86
Fork terminals allow easy installation because
screw needs only to be loosened. Suffix S
indicates a flanged-tongue fork with turned up
tips for extra holding protection.
Stock thickness same as ring terminal of same
size.
Most standard bulk catalog numbers can be put on
Mylar Tape for reel fed applications (i.e. 12050 tool
and application dies).
See pages 190-191.
Please put the suffix M for Mylar Tape RA2573M.
(Bulk number 1000 and 500 packages.)
U.L. Listed E9809
Installing tools: WT145C, WT2000, WT112M, ERG-2001, ERG-2003, WT145A, WT2130A(RC)
148
