M61520FP
6ch Electronic Volume with Tone Control
REJ03F0057-0100Z
Rev.1.0
Sep.19.2003
Features
Function names
Volume
Input selector
REC output
Gain control
Features
Six independent high-performance independent volumes on-chip (0 to 87 dB in 1 dB steps, -∞)
L/R ch: 6 inputs with muting and attenuation
Two-channel record output (one channel includes a mute switch)
Input gain control for FL, FR, C, SL, SR, and SW channels (0/3.6 dB)
Record-input gain control (+1/+3/+4.6/+6.6 dB)
Output gain control for SL, SR and C channels (0/+6 dB)
Output gain control for the SW channel (+6/+10 dB)
Output gain control for FL and FR channels (0/+2/+6.5/+10.5 dB) *1
Microphone-mix gain control (0/-2/+6.5/+10.5 dB) *1
On-chip bass-boost circuits for the FL and FR channels
Internal balanced outputs for the ADC
Bass boost
Balanced output
Note: 1 The microphone mix gain is coupled with output gain control for the FL and FR channels.
Application
Mini-component systems, TVs, etc.
Recommended Operating Conditions
Analog power-supply voltage range: 8.0 V to 10.0 V
Digital power-supply voltage range: 3.0 V to 5.5 V
Rev.1.0, Sep.19.2003, page 1 of 15
M61520FP
Absolute Maximum Ratings
Parameter
Max. power-supply voltage
Internal power dissipation
Ambient operating temperature
Storage temperature
Symbol
AVCC
DVDD
Pd
Topr
Tstg
Ratings
10.5
6.5
1.4
-20 to +75
-40 to +125
Unit
V
V
W
°C
°C
Conditions
Thermal derating curve
2.0
Internal power dissipation pd [W]
1.5
1.4
1.0
0.7
0.5
0
0
25
50
75
100
125
150
Ambient temperature Ta [°C]
Recommended Operating Condition
Limits
Item
Power-supply voltage
Input voltage (L level)
Input voltage (H level)
Symbol
AVCC
DVDD
VIL
VIH
Min.
8.0
3.0
0.0
2.0
Typ.
9.0
5.0
Max.
10.0
5.5
0.8
VDD
Unit
V
V
V
V
Pins 15, 16, and 17
Pins 15, 16, and 17
Condition
Electrical characteristics
Unless otherwise noted, Ta = 25°C, AVCC = 9.0 V, DVDD = 5.0 V, f = 1 kHz, and bass boosting is switched off.
(1) Power-supply characteristics
Limits
Item
Analog power-supply circuit
current
Digital power-supply circuit
current
Symbol
AICC
Dldd
Min.
Typ.
20
0.8
Max.
40
1.5
Unit
mA
mA
Condition
Current on pin 73 when AVCC = 5 V,
with no signal
Current on pin 24 when DVDD = 5 V,
with no signal
Rev.1.0, Sep.19.2003, page 4 of 15
M61520FP
(2) Input/output characteristics
Limits
Item
Input impedance
Input-selector max. input voltage
FL, FR OUT max. output voltage
Symbol
Rin
Vin
Vom
Min.
30
1.8
1.8
Typ.
60
2.2
2.2
Max.
90
Unit
KΩ
Vrms
Vrms
Condition
66pin, 74pin
66pin, 74pin
Input on pins 8 and 9, output on pins 46
and 53, RL = 10 kΩ, THD = 1%, bass
boost = on, fin = 80 Hz
Input on pins 2 and 3, output on pins 62
and 64, RL = 10 kΩ, THD = 1%, fin = 1
kHz
Input on pins 10 and 11, output on pins
36 and 40. RL = 10 kΩ, THD = 1%, fin =
1 kHz, gain = 6 dB
Gain from pins 4 to 74 and pins 6 to 66.
Gain from pins 8 to 53 and pins 9 to 46.
Vo = 1 Vrms, on pins 40 and 36, JIS-A
filter
JIS-A filter, when no signal is present, RG
= 10 kΩ, on pins 4 and 6, “normal
function” settings
JIS-A filter, when no signal is present, RG
= 10 kΩ, on pins 62 and 64, “normal
function” settings
JIS-A filter, when no signal is
present, Rg = 10 kΩ, volume
setting: 0 dB, “normal
function” settings
JIS-A filter, when no signal is
present, Rg = 10 kΩ, volume
setting: -∞ dB, “normal
function” setting
46, 53pin
40, 36pin
28pin
46, 53pin
40, 36pin
28pin
REC OUT max. output voltage
Vomrec
1.8
2.2
Vrms
C, SL, SR, SW max. output
voltage
Bypass gain 1
Bypass gain 2
Max. attenuation
ADOUT output noise voltage
Vomvol
1.8
2.2
Vrms
Gv1
Gv2
ATT
Vadno
-87
-8.0
0
-92
4.0
12.0
dB
dB
dB
µVrms
RECOUT output noise voltage
Vrecno
7.0
15.0
µVrms
FL, FROUT output noise voltage
C, SL, SRVOLOUT output noise
voltage
SW VOLOUT output noise
voltage
FL, FROUT output noise voltage
C, SL, SRVOLOUT output noise
voltage
SW VOLOUT output noise
voltage
Distortion on FL, FROUT
Distortion on REC OUT
Distortion on C, SL, SR,
SWVOLOUT
Crosstalk between channels
Vono1
Vvolno1
7.0
6.0
12.0
5.0
4.0
8.0
0.01
0.01
0.01
-70
-70
15.0
12.0
24.0
10.0
8.0
16.0
0.05
0.05
0.05
-55
-55
µVrms
µVrms
µVrms
µVrms
µVrms
µVrms
%
%
%
dB
dB
Vvolwno1
Vono2
Vvolno2
Vvolwno2
THD
THDrec
THDvol
CT
CTrec
On pins 46 and 53, BW = 400 to 30 kHz,
Vo = 300 mVrms, RL = 30 kΩ
On pins 62 and 64, BW = 400 to 30 kHz,
Vo = 300 mVrms, RL = 51 kΩ
On pins 40 and 36, BW = 400 to 30 kHz,
Vo = 300 mVrms, RL = 30 kΩ
Vo = 0.5 Vrms, RL = 10 kΩ, JIS-A, Rg =
10 kΩ, between pins 46 and 53
Vo = 0.5 Vrms, RL = 30 kΩ, JIS-A, Rg =
10 kΩ, between pins 62 and 64
Normal function settings:
•
•
•
•
•
Input attenuator: -8 dB
REC input gain amp: +1 dB
FL, FR, C, SL, SR, SW input gain amp: 0 dB
SL, SR, C output gain amp: 0 dB
SW output gain amp: +6 dB
Rev.1.0, Sep.19.2003, page 5 of 15
