High Current Inductor SMD
Type 3615 Series
Type 3615 Series
Characteristics -
Electrical Style
Core
Body
Marking
uH10-K
uH12-K
uH15-K
uH18-K
uH22-K
uH27-K
This is a high current, wound
inductor, based on phenolic, iron or
ferrite cores (depending on the
value required). The terminations
are of solder coated copper. Values
from 0.1µH to 2.7µH have a
phenolic core, 3.3µH to 100µH an
iron core and 120 µH to 1000 µH a
ferrite core.
We can also offer custom design
solutions in the 3615 package.
Please enquire.
Inductance
(µH)
Q
±10%
Min
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
50
50
50
50
50
50
50
50
50
50
50
50
50
35
35
35
35
35
35
35
35
35
35
35
35
50
55
55
55
55
55
55
55
55
55
55
55
60
60
60
60
60
60
60
60
60
60
60
60
Test
Freq.
(MHz)
25
25
25
25
25
25
25
25
25
25
25
25
25
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
Self
Resonant
Freq. (MHz)
550
550
510
460
415
380
350
320
300
270
250
220
200
180
170
150
140
120
70
65
60
50
50
48
42
35
30
30
24
22
20
18
16
15
13
10
8.0
6.8
6.4
6.0
5.8
5.6
5.0
4.5
4.0
3.6
3.4
3.1
2.5
DC Resistance
@ 20°C
(Max Ohms)
0.027
0.028
0.030
0.033
0.035
0.043
0.050
0.065
0.080
0.10
0.12
0.18
0.25
0.40
0.48
0.74
0.90
1.10
0.14
0.16
0.21
0.28
0.37
0.40
0.60
0.85
1.2
1.8
2.0
2.7
3.4
3.8
3.4
3.7
4.0
4.4
4.9
5.6
6.2
6.9
7.5
8.2
9.1
10.0
11.0
12.3
13.7
15.1
16.5
Direct Current
@ 70°C
(Max mA)
3500
2870
2770
2640
2570
2310
2150
1880
1700
1520
1385
1130
960
760
690
555
505
455
1280
1200
1050
905
785
760
620
520
438
358
340
290
259
245
259
249
239
228
216
202
192
182
175
167
159
151
144
136
129
123
118
uH33-K
uH39-K
Phenolic
uH47-K
uH56-K
uH68-K
uH82-K
1uH0-K
1uH2-K
1uH5-K
1uH8-K
2uH2-K
2uH7-K
3uH3-K
3uH9-K
4uH7-K
5uH6-K
6uH8-K
8uH2-K
10uH-K
12uH-K
15uH-K
Iron
18uH-K
22uH-K
27uH-K
33uH-K
39uH-K
47uH-K
56uH-K
68uH-K
82uH-K
mH10-K
mH12-K
mH15-K
mH18-K
mH22-K
mH27-K
Ferrite
mH33-K
mH39-K
mH47-K
mH56-K
mH68-K
mH82-K
1mH0-K
Key Features
■
■
■
■
■
■
■
High Current Winding
Versatile Size -
11.4mm x 5mm
Temperature Range
-55°C to +100°C
Supplied in Standard
Carrier Tape
Suitable for Dip and
Wave Solder
Insulation 1000 M Ohms
Minimum
Available from Stock
Literature No. 1773144
Issued: 12-08
Dimensions are shown for
reference purposes only.
Dimensions are in
millimetres unless
otherwise specified.
Specifications subject to
change.
tycoelectronics.com
passives.tycoelectronics.com
High Current Inductor SMD
Type 3615 Series
Characteristics -
Electrical
Operating Temperature:
Temperature Rise:
Power Dissipation at 70°C ambient:
Environmental classification:
Weight:
-55°C to +100°C
30°C maximum
0.3 Watts
55/100/56
0.7 grams maximum
Packaging
Parts are supplied Taped and Reeled on 13" Reels in quantities of 1500 pieces
Dimensions
Pad Layout
How to Order
3615
Common Part
A
Style
1R5
Inductance
Value Code
See Table
K
Tolerance
3615
A - Standard Part
K - ±10%
Literature No. 1773144
Issued: 12-08
Dimensions are shown for
reference purposes only.
Dimensions are in
millimetres unless
otherwise specified.
Specifications subject to
change.
tycoelectronics.com
passives.tycoelectronics.com
