Customer Specification

PART NO. 5010/15C

Construction

Diameters (In)

1) Component 1

a) Conductor

b) Insulation

(1) Color Code

Cond

2) Cable Assembly

a) Twists:

b) Core Wrap

3) Jacket

a) Color(s)

b) Ripcord

Color

BLACK

BROWN

RED

ORANGE

YELLOW

15 X 1 COND

22 (7/30) AWG TC

0.010" Wall, Nom. PVC, Semi Rigid

Alpha Wire Color Code E

Cond

15 Components Cabled

4.4 Twists/foot (min)

Nonwoven Polyester Tape, 25% Overlap, Min.

0.032" Wall, Nom.,PVC

0.299 (0.315 Max.)

Color

GREEN

BLUE

VIOLET

SLATE

WHITE

Cond

Color

WHITE/BLACK

WHITE/BROWN

WHITE/RED

WHITE/ORANGE

WHITE/YELLOW

0.030

0.050

Slate, Black, Yellow, Orange, Blue, Green, Red, Sand Beige, White

1 End 810 Denier Nylon

ALPHA WIRE-* P/N 5010/15C 15C 22 AWG

XTRAGUARD(R) 1 (UL) TYPE CM 105C OR AWM 2464 VW-1

--- LLXXXXXX CSA 105C TYPE CMG FT4 CE

ROHS (SEQ FOOTAGE)

* = Factory Code

[Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.]

c) Print

Applicable Specifications

1) UL

a) Component 1

b) Overall

AWM/STYLE 10002

AWM/STYLE 2464

VW-1

2) CSA International

CMG

FT4

3) CE:

EU Low Voltage Directive 2006/95/EC

105°C

105°C / 300 VRMS

80°C / 300 VRMS

105°C

Environmental

1) EU Directive 2002/95/EC(RoHS):

All materials used in the manufacture of this part are in compliance with EU Directive

2002/95/EU regarding the restriction of use of certain hazardous substances in electrical and

electronic equipment. Consult Alpha Wire's web site for compliance Date of Manufacture.

2) REACH Regulation (EC 1907/2006):

This product does not contain Substances of Very High Concern (SVHC) listed on the European

Union's REACH candidate list in excess of 0.1% mass of the item. For up-to-date information,

please see Alpha's REACH SVHC Declaration.

3) California Proposition 65:

The outer surface materials used in the manufacture of this part meet the requirements of

California Proposition 65.

Properties

Physical & Mechanical Properties

1) Temperature Range

2) Bend Radius

3) Pull Tension

4) Sunlight Resistance

Electrical Properties

1) Voltage Rating

2) Capacitance

3) Inductance

4) Conductor DCR

-30 to 105°C

10X Cable Diameter

82 Lbs, Maximum

Yes

(For Engineering purposes only)

300 VRMS

23.5 pf/ft @1 kHz, Nominal Conductor to Conductor

0.18 µH/ft, Nominal

16.5 /1000ft @20°C, Nominal

Other

Packaging

a) 1000 FT

b) 500 FT

c) 100 FT

d) Bulk(Made-to-order)

[Spool dimensions may vary slightly]

Flange x Traverse x Barrel (inches)

16 x 11 x 8 Continuous length

12 x 10 x 5 Continuous length

10 x 4 x 3.5 Continuous length
