350W Single Output with PFC Function
Features :
USP-350
series
Universal AC input / Full range
Built in active PFC circuit compliance to EN61000-3-2
Protections: Short circuit / Overload / Over voltage / Over temperature
Free air convection for 300W and 350W with 23.5CFM forced air
High power density 6.3w/in
3
ZVS technology to reduce power dissipation
Active AC surge current limiting
U-bracket low profile:38mm
3 years warranty
SPECIFICATION
MODEL
DC VOLTAGE
RATED CURRENT
USP-350-3.3
3.3V
70A
USP-350-5
5V
70A
0 ~ 50A
0 ~ 70A
250W
350W
80mVp-p
4.5 ~ 5.5V
2.0%
0.5%
2.0%
16ms/230VAC
127 ~ 370VDC
0.95/230VAC
84%
2A/230VAC
44A/230VAC
0.98/115VAC at full load
88%
88%
88%
89%
USP-350-12
12V
29.2A
0 ~ 25A
0 ~ 29.2A
300W
350.4W
100mVp-p
10.8 ~ 13.2V
2.0%
0.5%
1.0%
4000ms, 100ms/115VAC at full load
16ms/115VAC at full load
USP-350-15
15V
23.4A
0 ~ 20A
0 ~ 23.4A
300W
351W
100mVp-p
13.5 ~ 16.5V
2.0%
0.5%
1.0%
USP-350-24
24V
14.6A
0 ~ 12.5A
0 ~ 14.6A
300W
350.4W
150mVp-p
21.6 ~ 26.4V
2.0%
0.5%
1.0%
USP-350-48
48V
7.3A
0 ~ 6.25A
0 ~ 7.3A
300W
350.4W
150mVp-p
43.2 ~ 52.8V
2.0%
0.5%
1.0%
CURRENT RANGE (convection)
0 ~ 50A
CURRENT RANGE (23.5CFM FAN)
0 ~ 70A
RATED POWER (convection)
165W
RATED POWER (23.5CFM FAN)
231W
OUTPUT
RIPPLE & NOISE (max.)
Note.2
80mVp-p
VOLTAGE ADJ. RANGE
VOLTAGE TOLERANCE
Note.3
LINE REGULATION
LOAD REGULATION
SETUP, RISE TIME
HOLD UP TIME (Typ.)
VOLTAGE RANGE
FREQUENCY RANGE
POWER FACTOR (Typ.)
INPUT
EFFICIENCY (Typ.)
AC CURRENT (Typ.)
INRUSH CURRENT (Typ.)
LEAKAGE CURRENT
OVERLOAD
PROTECTION OVER VOLTAGE
OVER TEMPERATURE
WORKING TEMP.
WORKING HUMIDITY
ENVIRONMENT STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
SAFETY STANDARDS
WITHSTAND VOLTAGE
SAFETY &
EMC
(Note 4)
2.97 ~ 3.6V
2.0%
0.5%
2.0%
12ms/230VAC
Note.5
90 ~ 264VAC
2000ms, 100ms/230VAC
47 ~ 63Hz
0.94/230VAC
78%
4A/115VAC
22A/115VAC
<2mA / 240VAC
105 ~ 120% rated output power
105 ~ 130% rated output power
Protection type : Constant current limiting, recovers automatically after fault condition is removed
3.7 ~ 4.6V
5.7 ~ 7V
13.5 ~ 16.3V
17 ~ 21V
26.7 ~ 32.4V
Protection type : Hiccup mode, recovers automatically after fault condition is removed
80
5 (TSW1) detect on heatsink of power transistor
Protection type : Shut down o/p voltage with auto-recovery
-10 ~ +65
-40 ~ +85
(Refer to output load derating curve)
, 10 ~ 95% RH
20 ~ 90% RH non-condensing
0.03%/ (0 ~ 45
10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes
UL60950-1, TUV EN60950-1 approved
I/P-O/P:3KVAC
I/P-FG:1.5KVAC
O/P-FG:0.5KVAC
/ 70% RH
80
5
53 ~ 64.8V
(TSW2 ) detect on heatsink of power diode
I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25
EMI CONDUCTION & RADIATION
Compliance to EN55022 (CISPR22) Class B
HARMONIC CURRENT
EMS IMMUNITY
MTBF
DIMENSION
PACKING
ISOLATION RESISTANCE
Compliance to EN61000-3-2,-3
Compliance to EN61000-4-2,3,4,5,6,8,11; ENV50204, light industry level, criteria A
106.3K hrs min. MIL-HDBK-217F (25
235.2*101.5*38mm (L*W*H)
1.1Kg; 16pcs/18Kg/0.72CUFT
)
OTHERS
NOTE
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets
EMC directives. For guidance on how to perform these EMC tests, please refer to EMI testing of component power supplies.
(as available on http://www.meanwell.com)
5. Derating may be needed under low input voltages. Please check the derating curve for more details.
File Name:USP-350-SPEC 2010-10-18
