54LS11FMQB datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > logic> logic> 54LS11FMQB

54LS11FMQB: DescriptionLS SERIES, TRIPLE 3-INPUT AND GATE, CDFP14, CERAMIC, FP-14; Categorylogic logic; File Size802KB，7 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

54LS11FMQB Overview

LS SERIES, TRIPLE 3-INPUT AND GATE, CDFP14, CERAMIC, FP-14

54LS11FMQB Parametric

Parameter Name	Attribute value
Maker	Rochester Electronics
Parts packaging code	DFP
package instruction	DFP,
Contacts	14
Reach Compliance Code	unknown
series	LS
JESD-30 code	R-GDFP-F14
Logic integrated circuit type	AND GATE
Number of functions	3
Number of entries	3
Number of terminals	14
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	CERAMIC, GLASS-SEALED
encapsulated code	DFP
Package shape	RECTANGULAR
Package form	FLATPACK
propagation delay (tpd)	18 ns
Certification status	COMMERCIAL
Filter level	MIL-STD-883 Class B
Maximum seat height	2.032 mm
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	4.5 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	TTL
Temperature level	MILITARY
Terminal surface	NOT SPECIFIED
Terminal form	FLAT
Terminal pitch	1.27 mm
Terminal location	DUAL
width	6.2865 mm
Base Number Matches	1
