Contents
Introduction.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Technical Specifications
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Multi-Line Module Connectors for CompactPCI
Series 7200
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Sequential Mating and Contact Length
Series 7200 – Types A, B, C
. . . . . . . . . . . . . . . . . . . . . . . 7
Part Number Format Male/Female
. . . . . . . . . . . . . . . . . . . . 8
Right Angle Female,
Series 7200 – Shield Types and Selection
. . . . . . . . . . . 9
J1/J4 Right Angle Female
Series 7200 – Style A 25, 110 Contacts
. . . . . . . . . . . . 10
J2/J5 Type B Right Angle Female, Series 7200
. . . . . . . . . 12
Right Angle Female
Style B 22, 110 Contacts
. . . . . . . . . . . . . . . . . . . . . . . . 13
J3 Right Angle Female
Series 7200 – Style B 19, 95 Contacts
. . . . . . . . . . . . . 14
Right Angle Female
Series 7200 – Style B 25, 125 Contacts
. . . . . . . . . . . . 16
Right Angle Female
Series 7200 – Style C 11, 55 Contacts
. . . . . . . . . . . . . 18
J4 Type A Right Angle Female with Split Shield
(Computer Telephony) Series 7200.
. . . . . . . . . . . . . . . 20
Right Angle Female with Split Shield
(Computer Telephony)
. . . . . . . . . . . . . . . . . . . . . . . . . . 21
Type D Right Angle Female for Daughter Cards,
Series 8077
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Type E Right Angle Female for Daughter Cards,
Series 8077
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Type F Right Angle Female for Daughter Cards,
Series 8077
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Type AB Right Angle Female for Daughter Cards,
Series 8071
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Type L Right Angle Female for Daughter Cards,
Series 8074
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Type M Right Angle Female for Daughter Cards,
Series 8075
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Type A Vertical Female for Backplanes, Series 8072
. . . . 30
Type B Vertical Female for Backplanes, Series 8072
. . . . 31
Vertical Male Style A 25, 154 Contacts, Series 7200
. . . . . 32
Vertical Male Style B 25, 175 Contacts, Series 7200
. . . . . 34
Vertical Male Style B 22, 154 Contacts, Series 7200
. . . . . 36
Connectors Type D, E, F, 2mm Hard-Metric Custom
Design Worksheet – Series 8075/8077.
. . . . . . . . . . . . 58
Part Number Index
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Series 8072
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Type B Right Angle Male for Daughter Cards,
Series 8072
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Type C Right Angle Male for Daughter Cards,
Series 8072
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Press-fit Tools
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Shroud, Type B for Midplane and Rear I/O Assemblies
. . 50
Shroud, Type A and C for Midplane
and Rear I/O Assemblies
. . . . . . . . . . . . . . . . . . . . . . . . 51
Coding Keys Type A Male (Backplane) /
Female (Daughter Card).
. . . . . . . . . . . . . . . . . . . . . . . . 52
High Power Contacts for L, M and N Connectors,
Series 8489
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Coax Contacts for L and M Connectors,
Series 8489
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Special Contacts for L, M and N Connectors
. . . . . . . . . . 56
Connectors Type A, B, C, 2mm Hard-Metric Custom
Design Worksheet – Series 7200
. . . . . . . . . . . . . . . . . 57
®
Vertical Male Style B 19, 133 Contacts, Series 7200
. . . . . 38
Vertical Male Style C 11, 77 Contacts, Series 7200
. . . . . . 40
Type D Vertical Male for Backplanes, Series 8077.
. . . . . . 42
Type E Vertical Male for Backplanes, Series 8077.
. . . . . . 43
Type L Vertical Male for Backplanes, Series 8074
. . . . . . . 44
Type M Vertical Male Feed-To for Backplanes,
Series 8075
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Type A Right Angle Male for Daughter Cards,
NOTICE: Specifications are subject to change without notice. Contact your nearest AVX Sales Office for the latest specifications. All statements, information and data given
herein are believed to be accurate and reliable, but are presented without guarantee, warranty, or responsibility of any kind, expressed or implied. Statements
or suggestions concerning possible use of our products are made without representation or warranty that any such use is free of patent infringement and are not
recommendations to infringe any patent. The user should not assume that all safety measures are indicated or that other measures may not be required. Specifications are
typical and may not apply to all applications.
© AVX Corporation
Introduction
Connectors according to IEC 61076-4-101
The 2.0mm hard metric connectors made by AVX are devel-
oped and produced in accordance to the international engi-
neering standards IEC 61076-4-101. Because of this users all
over the world have a standard for the connection of printed
circuit boards with high density connectors. The boards can be
changed from one system to another without any problems.
Important parameters like alignment, shielding and coding
remain compatible beyond the application. This specification
has been selected as the CompactPCI
®
bus architecture by the
PCI Industrial Computer Manufacturers Group (PICMG). AVX
connectors have been specifically designed to fit in Position
P1/P4, J1/J4 and P2/P5; J2/J5 for CompactPCI
®
applications
and P0/J0 in the VME 64 extension format. AVX also offers full
custom connector service to meet the specific needs of given
markets and systems.
THE AVX ADVANTAGE
• Modular connector system with 2.0mm grid for
CompactPCI
®
backplane and daughter cards.
• Insulators are beveled at each end to guarantee
accurate positioning on the printed circuit board.
• Five, seven and eight signal rows plus two shield rows
for optimum transmission performance.
MODULAR SHIELDING
Modular shielding of female connectors enables high speed
data transmission in high frequency application. Reduces the
crosstalk level and allows an increase of the performance
to subnanosecond pulse rise time if used in a differential
pair application.
12 different contact sizes for custom configurations
AVX vertical male hard metric connectors have 3 different
lengths at the mating side and 4 lengths at the terminal side.
The different lengths are required for certain earliest make
last break connections on signal or group contacts.
CODING
To avoid mixing printed circuit boards Type A connectors use
coding keys in accordance with IEC61076-4-101. Coding
keys are inserted into the multi-function cavity by hand.
APPROVALS AND SPECIFICATIONS
AVX hard metric connector system meets the requirements
of IEC 61076-4-101.
TYPE A MULTI-FUNCTION CAVITY &
PRE-ALIGNMENT GUIDES
Type A connectors are equipped with a multi-function cavity
and pre-alignment guides. The guides ensure proper align-
ment between the boards during mating. The cavity accepts
coding keys in accordance with IEC61076-4-101 to prevent
mis-mating of boards.
TELCORDIA (
FORMERLY
GR-1217-CORE
BELLCORE
)
AVX hard metric connectors are designed to meet the
requirements of Telcordia Technologies (formerly BellCore),
GR-1217-Core.
ISO9001
The complete hard metric connector system is manufactured
in fully approved ISO9001 and QS9000 facilities.
PICMG
®
The hard metric connector system meets the requirements
of the CompactPCI
®
specification as defined by the PCI
Industrial Computer Manufacturers Group.
PCI Industrial Computer Manufacturers Group, (PICMG), is a consortium of Industrial
Computer Product vendors with the mission of designing specifications for PCI-based
systems and boards to be used in industrial and telecommunications applications.
For more information on PICMG visit their website at www.picmg.org
1
